NOCO Jump Starter GENPRO Series: The Ultimate Portable Powerhouse

Introduction

The NOCO Jump Starter GENPRO Series is a game-changing portable power source designed to jump-start 12-volt batteries, quickly and easily. Ideal for use with cars, trucks, boats, motorcycles, and more, this innovative device combines cutting-edge technology with user-friendly features, making it an essential tool for any driver. With an estimated price range of $150 to $300 and a launch date set for late 2022, the GENPRO Series is poised to revolutionize the way we think about battery jump starters.

Technical Specifications

How To Use

Charging Modes
The GENPRO Series has six (6) modes: Standby, 12V, 12V AGM, 12V LITHIUM, 12V REPAIR, and Force Mode. Some charge modes must be pressed and held for three (3) to five (5) seconds to enter the mode. These “Press and Hold” modes are advanced charging modes that require your full attention before selecting. It is important to understand the differences and purpose of each charge mode. Do not operate the charger until you confirm the appropriate charge mode for your battery. Below is a brief description:

Using 12V Lithium
12V Lithium charge mode is designed for 12-volt lithium-ion batteries only, including lithium iron phosphate.
CAUTION: USE THIS MODE WITH EXTREME CARE. THIS MODE SHOULD ONLY BE USED WITH 12-VOLT LITHIUM BATTERIES THAT HAVE A BUILT-IN BATTERY MANAGEMENT SYSTEM (BMS). LITHIUM-ION BATTERIES ARE MADE AND CONSTRUCTED IN DIFFERENT WAYS AND SOME MAY OR MAY NOT CONTAIN A BATTERY MANAGEMENT SYSTEM (BMS). CONSULT THE LITHIUM BATTERY MANUFACTURER BEFORE CHARGING AND ASK FOR RECOMMENDED CHARGING RATES AND VOLTAGES. SOME LITHIUM-ION BATTERIES MAY BE UNSTABLE AND UNSUITABLE FOR CHARGING.

Using 12V Repair. [From Standby Press and Hold 3 Seconds With Clamps Connected to the Battery]
12V Repair is an advanced battery recovery mode for repairing and storing, old, idle, damaged, stratified or sulfated batteries. Not all batteries can be recovered. Batteries tend to become damaged if kept at a low charge and/or never given the opportunity to receive a full charge. The most common battery problems are battery sulfation and stratification. Both battery sulfation and stratification will artificially raise the open circuit voltage of the battery, causing the battery to appear fully charged, while providing low capacity. Use 12V Repair in attempt to reverse these problems. For optimal results, take the 12-volt battery through a full charge cycle, bringing the battery to full charge, before using this mode. 12V Repair can take up to four (4) hours to complete the recovery process and will return to Standby when completed.
CAUTION: USE THIS MODE WITH CARE. THIS MODE IS FOR 12-VOLT LEAD-ACID BATTERIES ONLY. THIS MODE USES A HIGH CHARGING VOLTAGE AND MAY CAUSE SOME WATER LOSS IN WET (FLOODED) CELL BATTERIES. BE ADVISED, SOME BATTERIES AND ELECTRONICS MAY BE SENSITIVE TO HIGH CHARGING VOLTAGES. TO MINIMIZE RISKS TO ELECTRONICS, DISCONNECT THE BATTERY BEFORE USING THIS MODE.

Force Mode. [Press & Hold for 5 seconds]
Force mode allow the charger to manually begin charging when the connected battery’s voltage is too low to be detected. If battery voltage is too low for the charger to detect, press and hold the mode button for 5 seconds to activate Force Mode, then select the appropriate mode. All available modes will flash. Once a charge mode is selected, the Charge Mode LED and Charge LED will alternate between each other, indicating Force Mode is active. After five (5) minutes the charger will return to the normal charge operation and low voltage detection will be reactivated.
CAUTION: USE THIS MODE WITH EXTREME CARE. FORCE MODE DISABLES SAFETY FEATURES AND LIVE POWER IS PRESENT AT THE CONNECTORS. ENSURE ALL CONNECTIONS ARE MADE PRIOR TO ENTERING FORCE MODE, AND DO NOT TOUCH CONNECTIONS TOGETHER. RISK OF SPARKS, FIRE, EXPLOSION, PROPERTY DAMAGE, INJURY, AND DEATH.

Connecting to the Battery

Do not connect the AC power plug until all other connections are made. Identify the correct polarity of the battery terminals on the battery. Do not make any connections to the carburetor, fuel lines, or thin, sheet metal parts. The below instructions are for a negative ground system (most common). If your boat or vehicle is a positive ground system (very uncommon), follow the below instructions in reverse order.

1. Connect the positive (red) eyelet terminal connector to the positive (POS,P,+) battery terminal.
2. Connect the negative (black) eyelet terminal connector to the negative (NEG,N,-) battery terminal.
3. Connect the battery charger into a suitable electrical outlet. Do not face the battery when making this connection.
4. When disconnecting, disconnect in the reverse sequence, removing the negative first (or positive first for positive ground systems).

Begin Charging

1. Verify the voltage and chemistry of the battery.
2. Confirm that you have connected the battery clamps or eyelet terminal connectors properly and the AC power plug is plugged into an electrical outlet.
3. [First time use] The charger will begin in Standby mode, indicated by an orange LED. In Standby, the charger is not providing any power.
4. Press the mode button to toggle to the appropriate charge mode (press and hold for three seconds to enter an advanced charge mode) for the voltage and chemistry of your battery.
5. The mode LED will illuminate the selected charge mode and the Charge LEDs will illuminate (depending on the health of the battery) indicating the charging process has started.
6. The charger can now be left connected to the battery at all times to provide maintenance charging.
   Auto-Memory: The charger has built in auto-memory and will return to the last charge mode when connected. To change modes after the first use, press the mode button.

Charging Times

The estimated time to charge a battery is shown below. The size of the battery (Ah) and its depth of discharge (DOD) greatly affect its charging time. The charge time is based on an average depth of discharge to a fully charged battery and is for reference purposes only. Actual data may differ due to battery conditions. The time to charge a normally discharged battery is based on a 50% DOD. Temperature will also impact charging times. The GENPRO Series features thermal compensation that automatically adjusts charging profiles to maximize charging performance.

Understanding Charge LEDs

Understanding Error LEDs

Error Conditions will be indicated by the following LEDs.

Interface

(For GENPRO10X1/10X2/10X3/10X4, each bank is isolated and functions independently.)

1. Mode Button Push to cycle through charging Modes.
2. Overvoltage Error LED Illuminates solid Red; Battery Voltage is above Protect voltage.
3. Bad Battery Error LED Illuminates solid Red when connected battery will not hold a charge.
4. Reverse Polarity Error LED Illuminates solid Red when reverse polarity is detected.
5. Standby LED Illuminates when the charger is in Standby Mode, the charger is not charging or providing any power to the battery.
6. Charge LED indicates the connected battery(s) state-of-charge.
7. Mode LED Indicates the Charge Mode the charger is currently in. Push the MODE button to cycle through charge Modes.
8. «Press and Hold» Mode LED Mode button must be pressed and held for 3 seconds to enter the mode.

Description

The NOCO Jump Starter GENPRO Series is designed to provide a powerful and versatile solution for jump-starting 12-volt batteries. With its high-density lithium-ion battery, the GENPRO Series delivers up to 2000 amps of peak current, ensuring quick and reliable jump-starting for various vehicles. The integrated 12V, 16V, and 19V output allows users to power various devices, while the ultra-bright 1000-lumen LED flashlight features multiple modes, including SOS and emergency strobe, providing added convenience and safety.

The GENPRO Series is equipped with spark-proof technology and reverse polarity protection, ensuring safe and worry-free operation. Its water-resistant and rugged design makes it suitable for use in various environments, while the built-in carrying handle ensures easy transportation. The integrated LCD screen displays power levels and diagnostic information, providing users with real-time updates on the device's status.

Setup Guide

To operate the NOCO Jump Starter GENPRO Series, follow these steps:

1. Ensure the vehicle's battery is turned off.
2. Connect the GENPRO Series to the vehicle's battery using the included jumper cables, attaching the red clamp to the positive terminal and the black clamp to the negative terminal.
3. Turn on the GENPRO Series by pressing the power button.
4. Start the vehicle. If the vehicle does not start, wait a few minutes before attempting again.
5. Once the vehicle has started, disconnect the GENPRO Series by removing the black clamp first, followed by the red clamp.

Troubleshooting

Common problems and solutions for the NOCO Jump Starter GENPRO Series include:

• Problem: The vehicle does not start after multiple attempts.
  Solution: Check the battery connections for proper attachment and ensure the GENPRO Series is fully charged.
• Problem: The GENPRO Series does not turn on.
  Solution: Ensure the device is charged and the power button is pressed properly.
• Problem: The LED flashlight does not function.
  Solution: Ensure the device is charged and the flashlight button is pressed properly.

Warranty

NOCO warrants that this product (the “Product”) will be free from defects in material and workmanship for a period of Three (3) years from the date of purchase (the “Warranty Period”). For defects reported during the Warranty Period, NOCO will, at its discretion, and subject to NOCO’s technical support analysis, either repair or replace defective products. Replacement parts and products will be new or serviceably used, comparable in function and performance to the original part and warranted for the remainder of the original Warranty Period.

Pros & Cons

Pros

• High-density lithium-ion battery for long-lasting performance
• Integrated output for powering various devices
• Spark-proof and reverse polarity protection for safe operation
• Water-resistant and rugged design for durability
• Ultra-bright LED flashlight with multiple modes

Cons

• Higher price point compared to some competitors
• May not be suitable for larger vehicles requiring higher amperage

Customer Reviews

Customers have praised the NOCO Jump Starter GENPRO Series for its compact size, versatility, and ease of use. Common compliments include its long-lasting battery, bright LED flashlight, and durable design. However, some customers have noted that the device may not be suitable for larger vehicles requiring higher amperage, and its higher price point may be a deterrent for some users.
