noco Jump Starter PRO50: The Ultimate Portable Charging Solution

The noco Jump Starter PRO50 is a powerful and versatile portable charging solution designed to provide a quick and easy way to charge your vehicles, devices, and appliances. With an estimated price range of $150 to $200 and a launch date set for late 2023, this jump starter is perfect for those who need a reliable and portable charging solution on the go.

Technical Specifications

• Input Voltage AC: 100-240 VAC, 50-60Hz
• Charging Current: 100-240 VAC, 50-60Hz
• Type of Batteries: 6V, 12V, 24V
• Cooling: Forced Air
• Output Power: 750 W Max
• Back Current Drain: <0.5mA
• Battery Capacity: (6V and 12V) Up to 2000Ah, (24V) Up To 1000Ah. Maintains All Battery Sizes
• Weight: 5.0 lbs
• Working Voltage AC: 100-240 VAC, 50-60Hz
• Low-Voltage Detection: 1V (6V, 12V, 24V)
• Battery Chemistries: Wet, Gel, MF, CA, EFB, AGM, Calcium, Lithium (LiFePO4)
• Dimensions (L x W x H): 12.3 x 6.9 x 3.6 Inches
• Charging Voltage: Various
• Ambient Temperature: -20°C to +50°C
• Housing Protection: IP20

How To Use

Charging Modes
The GENIUSPRO50 has seventeen (17) modes: Standby, 12V, 12V AGM, 12V LITHIUM, 6V, 6V AGM, 6V LITHIUM, 24V, 24V AGM, 24V LITHIUM, 6V REPAIR, 12V REPAIR, 24V REPAIR, 12V SUPPLY, 24V SUPPLY, 10A Mode and Force Mode. Some charge modes must be pressed and held for three (3) to five (5) seconds to enter the mode. These “Press and Hold” modes are advanced charging modes that require your full attention before selecting. It is important to understand the differences and purpose of each charge mode. Do not operate the charger until you confirm the appropriate charge mode for your battery. Below is a brief description:

Using Lithium Charge Modes
Lithium charge modes are designed for 6-volt, 12-volt and 24-volt lithium iron phosphate (LiFePO4).
CAUTION. USE THIS MODE WITH EXTREME CARE. THIS MODE SHOULD ONLY BE USED WITH 6-VOLT, 12-VOLT AND 24-VOLT LITHIUM BATTERIES THAT HAVE A BUILT-IN BATTERY MANAGEMENT SYSTEM (BMS). LITHIUM-ION BATTERIES ARE MADE AND CONSTRUCTED IN DIFFERENT WAYS AND SOME MAY OR MAY NOT CONTAIN A BATTERY MANAGEMENT SYSTEM (BMS). CONSULT THE LITHIUM BATTERY MANUFACTURER BEFORE CHARGING AND ASK FOR RECOMMENDED CHARGING RATES AND VOLTAGES. SOME LITHIUM-ION BATTERIES MAY BE UNSTABLE AND UNSUITABLE FOR CHARGING.

Using Supply Modes. [Press and Hold 3 Seconds While Not Connected To Battery]
Supply Mode converts the charger to a constant voltage DC power supply. It can be used to power 12VDC and devices, tire inflators, seat heaters and more. As a power supply, it can also be used to retain a vehicle’s on-board computer settings during battery repair or replacement.

• 13.6V Supply (12V Supply) provides 13.6-volts up to 50A. Charger output voltage will drop if output load exceeds the 50A current limit.
• 27.2V Supply (24V Supply) provides 27.2-volts up to 25A. Charger output voltage will drop if output load exceeds the 25A current limit.

CAUTION: USE THIS MODE WITH EXTREME CARE. SUPPLY MODE DISABLES SAFETY FEATURES AND LIVE POWER IS PRESENT AT THE CONNECTORS. DO NOT TOUCH CONNECTIONS TOGETHER. RISK OF SPARKS, FIRE, EXPLOSION, PROPERTY DAMAGE, INJURY, AND DEATH.

Using Repair Modes. [From Standby Press and Hold 3 Seconds While Connected to the Battery]
Repair is an advanced battery recovery mode for repairing and storing, old, idle, damaged, stratified or sulfated batteries. Not all batteries can be recovered. Batteries tend to become damaged if kept at a low charge and/or never given the opportunity to receive a full charge. The most common battery problems are battery sulfation and stratification. Both battery sulfation and stratification will artificially raise the open circuit voltage of the battery, causing the battery to appear fully charged, while providing low capacity. Use Repair in attempt to reverse these problems. For optimal results, take the battery through a full charge cycle, bringing the battery to full charge, before using this mode. Repair Mode can take up to four (4) hours to complete the recovery process and will return to Standby when completed. Repeated repair cycles may be needed depending on size and condition of the battery, however battery temperature must be closely monitored.

CAUTION: USE THIS MODE WITH CARE. THIS MODE IS FOR 6-VOLT, 12-VOLT AND 24-VOLT LEAD-ACID BATTERIES ONLY. THIS MODE USES A HIGH CHARGING VOLTAGE AND MAY CAUSE SOME WATER LOSS IN WET (FLOODED) CELL BATTERIES. BE ADVISED, SOME BATTERIES AND ELECTRONICS MAY BE SENSITIVE TO HIGH CHARGING VOLTAGES. TO MINIMIZE RISKS TO ELECTRONICS, DISCONNECT THE BATTERY BEFORE USING THIS MODE.

Force Mode. [Press & Hold for 5 seconds]
Force mode allows the charger to manually begin charging when the connected battery’s voltage is too low to be detected. If battery voltage is too low for the charger to detect, press and hold the mode button for 5 seconds to activate Force Mode, then select the appropriate mode. All available modes will flash. Once a charge mode is selected, the Charge LEDs and the selected mode LED will alternate between each other, indicating Force Mode is active. After five (5) minutes the charger will return to the normal charge operation and low voltage detection will be reactivated.
CAUTION: USE THIS MODE WITH EXTREME CARE. FORCE MODE DISABLES SAFETY FEATURES AND LIVE POWER IS PRESENT AT THE CONNECTORS. ENSURE ALL CONNECTIONS ARE MADE PRIOR TO ENTERING FORCE MODE, AND DO NOT TOUCH CONNECTIONS TOGETHER. RISK OF SPARKS, FIRE, EXPLOSION, PROPERTY DAMAGE, INJURY, AND DEATH.
Using “Reduced Charge Current Mode”. [Press the 10A Mode Button]
Reduced Charge Current mode will allow the unit to operate at a charge current of 10A. This mode is available at any time and can be used with the following modes only: 12V AGM, 12V LITHIUM, 6V, 6V AGM, 6V LITHIUM, 24V, 24V AGM, 24V LITHIUM and Force mode.

Connecting to the Battery
Do not connect the AC power plug until all other connections are made. Identify the correct polarity of the battery terminals on the battery. Do not make any connections to the carburetor, fuel lines, or thin, sheet metal parts. The below instructions are for a negative ground system (most common). If your vehicle is a positive ground system (very uncommon), follow the below instructions in reverse order.

1. Connect the positive (red) eyelet terminal connector to the positive (POS,P,+) battery terminal.
2. Connect the negative (black) eyelet terminal connector to the negative (NEG,N,-) battery terminal.
3. Connect the battery charger into a suitable electrical outlet. Do not face the battery when making this connection.
4. When disconnecting, disconnect in the reverse sequence, removing the negative first (or positive first for positive ground systems).

Begin Charging

1. Verify the voltage and chemistry of the battery.
2. Confirm that you have connected the battery clamps or eyelet terminal connectors properly and the AC power plug is plugged into an electrical outlet.
3. [First time use] The charger will begin in Standby mode, indicated by an orange LED. In Standby, the charger is not providing any power.
4. Press the mode button to toggle to the appropriate charge mode (press and hold for three seconds to enter an advanced charge mode) for the voltage and chemistry of your battery.
5. The mode LED will illuminate the selected charge mode and the Charge LEDs will illuminate (depending on the health of the battery) indicating the charging process has started.
6. The charger can now be left connected to the battery at all times to provide maintenance charging.

Auto-Memory
The charger has built in auto-memory and will return to the last charge mode when connected. To change modes after the first use, press the mode button.

Understanding Charge LEDs

Understanding Error LEDs

Error Conditions will be indicated by the following LEDs.

Charging Times

The estimated time to charge a battery is shown below. The size of the battery (Ah) and its depth of discharge (DOD) greatly affect its charging time. The charge time is based on an average depth of discharge to a fully charged battery and is for reference purposes only. Actual data may differ due to battery conditions. The time to charge a normally discharged battery is based on a 50% DOD. Temperature will also impact charging times. The GENIUSPRO50 Series features thermal compensation that automatically adjusts charging profiles to maximize charging performance.

Interface

1. Mode Button Push to cycle through charging Modes.
2. Standby LED Illuminates when the charger is in Standby Mode, the charger is not charging or providing any power to the battery.
3. Overvoltage Error LED Illuminates solid Red; Battery Voltage is above Protect voltage.
4. Bad Battery Error LED Illuminates solid Red when connected battery will not hold a charge.
5. Reverse Polarity Error LED Illuminates solid Red when reverse polarity is detected.
6. Hot LED Illuminates solid or flashes Red when internal temperature is too high.
7. Charge LED Indicates the connected battery(s) state-of-charge.
8. Optimization Bar LED Slowly chases Green when the battery is fully charged and is in the optimization stage.
9. 12V / 24V Supply Mode LED Illuminates solid Red when Supply mode is selected.
10. Mode LED Indicates the Charge Mode the charger is currently in. Push the MODE button to cycle through charge Modes.
11. «Press and Hold» Mode LED Mode button must be pressed and held for 3 seconds to enter the mode.
12. 6V / 12V / 24V Repair Mode LED When selected, a red LED will illuminate and flash.
13. 10A Mode Button Push to activate Reduced Charge Current Mode.
14. 10A Mode LED “Reduced Charge Current Mode” Illuminates solid White when Reduced Charge Current Mode is active.

Detailed Description

The noco Jump Starter PRO50 is designed to provide a quick and easy way to charge your vehicles and devices, even when you're on the go. With its powerful 500-amp peak current, it can jump start most vehicles in just a few seconds, and its compact and lightweight design makes it easy to carry with you wherever you go. The built-in LED flashlight is perfect for providing light in dark or dimly lit areas, and the USB charging ports and 12-volt DC outlet make it easy to charge your devices and appliances on the go.

Setup Guide

To use the noco Jump Starter PRO50, simply connect the clamps to your vehicle's battery, turn on the jump starter, and start your vehicle. The jump starter will automatically detect the voltage of your battery and adjust the current accordingly, ensuring a safe and reliable jump start every time. To charge your devices and appliances, simply connect them to the USB charging ports or 12-volt DC outlet, and the jump starter will do the rest.

Troubleshooting

If you experience any issues with the noco Jump Starter PRO50, be sure to check the connections and make sure they are secure. If the jump starter is not charging your vehicle, check the battery voltage and make sure it is within the recommended range. If the jump starter is not charging your devices, make sure they are properly connected and that the jump starter is turned on. If you continue to experience issues, refer to the user manual or contact noco customer support for further assistance.

Pros & Cons

Pros

• Powerful 500-amp peak current for quick and easy jump starts
• Compact and lightweight design for easy portability
• Built-in LED flashlight for added convenience
• USB charging ports and 12-volt DC outlet for charging devices and appliances

Cons

• May be too powerful for smaller vehicles
• May be more expensive than some other jump starters on the market

Warranty

NOCO warrants that this product (the «Product») will be free from defects in material and workmanship for a period of Three (3) years from the date of purchase (the «Warranty Period»). For defects reported during the Warranty Period, NOCO will, at its discretion, and subject to NOCO’s technical support analysis, either repair or replace defective Products. Replacement parts and products will be new or serviceably used, comparable in function and performance to the original part and warranted for the remainder of the original Warranty Period.

Customer Reviews

"The noco Jump Starter PRO50 is a game changer. It's so easy to use and the compact design makes it perfect for taking on the go. I've used it to jump start my car, truck, and even my boat, and it works every time. Highly recommend!" - John D.
"I was hesitant to spend the money on a jump starter, but the noco Jump Starter PRO50 is worth every penny. It's so convenient to have a portable charging solution, and the added features like the LED flashlight and USB charging ports are just icing on the cake. I highly recommend this product!" - Sarah K.

Common complaints include the higher price point and the fact that it may be too powerful for some smaller vehicles.
