AIntroducing the Blood Pressure Monitor HEM-7132

Omron BP Monitor is a reliable device designed for accurate home blood pressure monitoring. Launched in 2018, this monitor is manufactured by Omron, a leading name in healthcare technology. Priced at approximately $49.99, the HEM-7132 features one-touch operation, a memory capacity for 60 readings, and advanced body movement detection, ensuring precise measurements. Its user-friendly design makes it an ideal choice for individuals looking to manage their health effectively.

The OMRON HEM-7132 is a compact, fully automatic blood pressure monitor, operating on the oscillometric principle. It measures your blood pressure and pulse rate simply and quickly. For comfortable controlled inflation without the need for pressure pre-setting or re-inflation, the device uses its advanced “IntelliSense” technology.

Intended Use
This product is designed to measure the blood pressure and pulse rate of people within the range of the designated arm cuff, following the instructions in this instruction manual. It is mainly designed for general household use. Please read the Important Safety Information in this instruction manual before using the unit.

Info: Please read this instruction manual thoroughly before using the unit. Please keep for future reference.

For specific information about your own blood pressure, CONSULT YOUR DOCTOR.

Technical Data

• Product Description: Automatic Blood Pressure Monitor
• Model: HEM-7132
• Display: LCD Digital Display
• Measurement Method: Oscillometric method
• Measurement Range
  • Pressure: 0 to 299 mmHg
  • Pulse: 40 to 180 beats/ min.
• Accuracy
  • Pressure: ±3 mmHg
  • Pulse: ±5% of display reading
• Inflation: Fuzzy-logic controlled by electric pump
• Deflation: Automatic pressure release valve
• Memory: 60 Measurements with date and time
• Rating: DC6V 4W
• Power Source: 4 “AA” batteries 1.5V or AC adapter (optional, INPUT AC100-240V 50/60Hz 0.12A)
• Battery Life: Approx. 1000 measurements (using new alkaline batteries)
• Applied Part: = Type BF
• Protection Against Electric Shock: Internally powered ME equipment (When using only the batteries)
  Class II ME equipment (Optional AC adapter)
• Operating temperature/ Humidity: +10 to +40°C / 30 to 85% RH
• Storage temperature/ Humidity/ Air pressure: -20 to +60°C / 10 to 95% RH / 700-1060 hPa
• Console Weight: Approx. 280g without batteries
• Cuff Weight: Approx. 170g
• Outer Dimensions: Approx. 107 (w) mm × 79 (h) mm × 141(l) mm
• Cuff Dimensions: Approx. 145 mm × 532 mm
  (Cuff: arm circumference 22 to 42 cm)
• Cuff/ Tube Material: Nylon, polyester, polyvinyl chloride
• Package Content: Main unit, arm cuff, instruction manual, battery set

Overview

Main unit

1. Display
2. Memory button
3. START/STOP button
4. Date/Time setting ( ) button
5. Cuff wrapping guide lamp
6. Up/Down ( ) buttons
7. Blood pressure colour indicator
8. Battery compartment
9. AC adapter jack (for optional
   • AC adapter)

10. Air Jack
    Arm cuff



11. Air plug
12. Air tube

13. Arm Cuff (Arm circumference 22 - 42 cm)
    Display



14. Average value symbol
15. Memory symbol
16. Irregular heartbeat symbol
17. Systolic blood pressure
18. Diastolic blood pressure
19. Low battery symbol
20. Cuff wrapping guide
21. Heartbeat symbol
    • Flashes during measurement.
22. Date/Time display
23. Movement error symbol
24. Blood pressure level indicator
25. Deflation symbol
26. Pulse display and Memory number

Description

The Omron HEM-7132 features a sleek and compact design, making it easy to store and transport. The large LCD display ensures that readings are clear and easy to read, even for those with vision impairments. The device comes with a pre-formed cuff that fits arms of various sizes, ensuring a comfortable and accurate fit. The automatic inflation and deflation mechanism simplifies the measurement process, reducing user error and discomfort.

The monitor also includes advanced features such as irregular heartbeat detection and alerts for high blood pressure, providing users with comprehensive insights into their cardiovascular health. The memory function allows users to track their readings over time, which can be invaluable for monitoring health trends and adjusting treatment plans as necessary.

Preparation

Installing/Replacing the Batteries

1. Remove the battery cover.
2. Insert four “AA” batteries as indicated in the battery compartment and then replace the battery cover.
   Notes:
   • If the low battery symbol () appears on the display, turn the monitor off then replace all batteries at the same time.
   • The measurement values continue to be stored in memory even after the batteries are replaced.
   • The supplied batteries may have a shorter life. Disposal of used batteries should be carried out in accordance with the national regulations for the disposal of batteries.

Setting the Date and Time

1. Press the button.

2. Set the monitor to the correct date and time before taking a measurement for the first time.



3. Press the START/STOP button to store the setting.
   Notes:
   • If the batteries have been replaced, the date and time setting will need to be reset.
   • If the date and time are not set, “-:--” appears during or after measurement.

Using the Unit

Applying the Arm Cuff

Remove tight-fitting clothing or tight rolled up sleeve from your upper arm. Do not place the arm cuff over thick clothes.

1. Insert the air plug into the air jack securely.



2. Apply the arm cuff to your upper arm.
   The bottom edge of the arm cuff should be 1 to 2 cm above the elbow. The air tube is centred on the middle of your inner arm.



3. Close the fabric fastener FIRMLY.



   Notes:

   • When you take a measurement on the right arm, the air tube will be at the side of your elbow. Be careful not to rest your arm on the air tube.
   • The blood pressure can differ between the right arm and the left arm, and therefore also the measured blood pressure values can be different. OMRON recommends to always use the same arm for measurement. If the values between both arms differ substantially, please check with your doctor which arm to use for your measurement.

How to Sit Correctly

To take a measurement, you need to be relaxed and comfortably seated, under comfortable room temperature. No bathing, drinking alcohol or caffeine, smoking, exercising or eating 30 minutes before taking a measurement.

• Sit on a chair with your feet flat on the floor.
• Sit upright with your back straight.
• The arm cuff should be at the same level as your heart.

Taking a Reading

Notes:

• To cancel a measurement, press the START/STOP button to release the air in the arm cuff.
• Remain still while taking a measurement.

1. Press the START/STOP button.
   The arm cuff will start to inflate automatically.



   If your systolic pressure is more than 210 mmHg After the arm cuff starts to inflate, press and hold the START/STOP button until the monitor inflates 30 to 40 mmHg higher than your expected systolic pressure.
   Notes:

   • The monitor will not inflate above 299 mmHg.
     • Do not apply more pressure than necessary.
       Note: Wait 2-3 minutes before taking another blood pressure measurement. Waiting between readings allows the arteries to return to the condition prior to taking the blood pressure measurement.
       WARNING: Always consult your doctor. Self-diagnosis of measurement results and self-treatment are dangerous.
       Cuff Wrapping Guide Lamp: The cuff wrapping guide lamp lights in green, the cuff is correctly wrapped tightly enough on the arm and the reading is accurate and reliable. If it does not light, the reading is not reliable due to the incorrect wrapping of the cuff. Please wrap the cuff again, taking care to wrap it correctly and take the measurement again.
2. Remove the arm cuff.

   • Press the START/STOP button to turn the monitor off.
     The monitor automatically stores the measurement in its memory. It will automatically turn off after 2 minutes.
     Important: If your systolic or diastolic pressure is outside the standard range, The blood pressure colour indicator will light in orange when the measurement result is displayed. Recent research suggests that the following values can be used as a guide to high blood pressure for measurements taken at home.



     • Systolic Blood Pressure Above 135 mmHg
     • Diastolic Blood Pressure Above 85 mmHg

   • This criteria is for home blood pressure measurement.



     • Your blood pressure monitor includes an irregular heartbeat feature. Irregular heartbeats can influence the results of the measurement.
   • The irregular heartbeat algorithm automatically determines if the measurement is usable or needs to be repeated. If the measurement results are affected by irregular heartbeats but the result is valid, the result is shown together with the irregular heartbeat symbol (). If the irregular heartbeats cause the measurement to be invalid, no result is shown. If the irregular heartbeat symbol () is shown after you have taken a measurement, repeat the measurement. If the irregular heartbeat symbol () is shown frequently, please make your doctor aware of it.

     • If you move during measurement, the movement error symbol () will appear on the display. Keep still and repeat the measurement.



Using the Guest Mode

The monitor stores measurement values for one user in the memory. The guest mode can be used to take a single measurement for another user. No measurement values are stored in the memory when the guest mode is selected.

1. Press and hold the START/STOP button for more than 3 seconds.
   The date/time display will disappear.

2. Release the START/STOP button when the date/time display turns off.
   The arm cuff will start to inflate automatically.



Using the Memory Function

The monitor automatically stores the result up to 60 sets. It can also calculate an average reading based on the measurements from the last three readings taken within 10 minutes. If there are only two readings in memory for that period, the average will be based on two readings. If there is one reading in memory for that period, the average will be based on one reading.

Notes:

• If the memory is full, the monitor will delete the oldest reading.
• When viewing the reading taken without setting the date and time, “-:--” is displayed instead of the date and time.

To View the Readings Stored in Memory

1. Press the button.



   The Memory number appears for a second before the pulse rate is displayed. The newest set is numbered “1”.
   Notes:

   • If your systolic or diastolic pressure is outside thestandard range, the Blood pressure colour indicator will light when the measurement result is displayed.
   • The cuff wrapping guide result appears on the display with the measurement values.The cuff wrapping guide lamp will not lignt.
     : The arm cuff was correctly wrapped tightly enough.
     : The arm cuff was loose or not wrapped correctly.
2. Press the or button to view the readings stored in memory.
   : To the older readings
   : To the more recent readings

To View the Average Value

1. Press and hold the button for ore than 3 seconds.
   Notes:
   • If the previous reading was taken without setting the date and time, the average value is not calculated.

   • If there are no measurements results stored in the memory, the screen to the right is displayed.



To Delete All the Values Stored in Memory

When the memory symbol () appears, first press the Memory button. Then while holding it down, press the START/STOP button simultaneously for more than 3 seconds.

Note: You cannot partially delete the stored readings.

Setup Guide

To set up and operate the Omron HEM-7132, follow these steps:

1. Insert the batteries into the device according to the manufacturer's instructions.
2. Wrap the pre-formed cuff around your upper arm, ensuring it is snug but not too tight.
3. Sit comfortably with your back supported and feet flat on the floor.
4. Turn on the device and press the start button. The cuff will inflate automatically.
5. Wait for the measurement to be taken and displayed on the screen.
6. Remove the cuff and note down your reading if necessary.

Blood Pressure Monitor HEM-7132 Maintenance

To protect your unit from damage, please observe the following:
Cause Remedy

Notes:

• When you take a measurement on the right arm, the air tube will be at the side of your elbow. Be careful not to rest your arm on the air tube.

Notes:

• To cancel a measurement, press the START/STOP button to release the air in the arm cuff.
• Remain still while taking a measurement.
• Press the START/STOP button.
  The arm cuff will start to inflate automatically.

Notes:

• If the previous reading was taken without setting the date and time, the average value is not calculated.
• If there are no measurements results stored in the memory, the screen to the right is displayed.
• Do not subject the main unit and the cuff to extreme temperatures, humidity, moisture or direct sunlight.
• Do not fold the cuff or tubing tightly.
• Do not inflate the arm cuff over 299 mmHg.
• Do not disassemble the unit.
• Do not subject the unit to strong shocks or vibrations (for example, dropping the unit on the floor).
• Do not use volatile liquids to clean the main unit.
• Do not wash the arm cuff or immerse it in water.
• Do not use petrol, thinners or similar solvents to clean the arm cuff.

• Do not carry out repairs of any kind yourself. If a defect occurs, consult your local OMRON representative.



• The unit should be cleaned with a soft, dry cloth.
• Use a soft, moistened cloth and neutral soap to clean the arm cuff.

Note: Read and follow the “Correct Disposal of This Product” in the Technical Data Section when disposing of the device and any used accessories or optional parts.

Storage

1. Unplug the air plug from the air jack.

2. Gently fold the air tube into the arm cuff.



   Notes:

   • Do not bend the air tube excessively.
   • Do not store the unit in the following situations:
     • If the unit is wet.
     • Locations exposed to extreme temperatures, humidity, direct sunlight, dust or corrosive vapours.
     • Locations exposed to vibrations, shocks or where it will be at an angle.

Optional Parts

• Arm Cuff
  Arm circumference
  22 - 42 cm



• AC Adapter S



Note: Please check with your local OMRON representatives for the appropriate optional part models.

Using the Optional AC Adapter

1. Insert the AC adapter plug into the AC adapter jack on the rear side of the main unit.

2. Plug the AC adapter into an  electrical outlet.



   To disconnect the AC adapter, unplug the AC adapter from the electrical outlet first and then remove the AC adapter plug from the main unit.

Troubleshooting

The Icons and Error Messages

Error Display	Cause	Remedy
	Irregular heartbeats are detected.	Remove the arm cuff. Wait 2 - 3 minutes and then takeanother measurement. Repeat the steps in section 3.3. If this errorcontinues to appear,contact your doctor.
	Movement duringmeasurement.	Carefully readand repeat the steps in section 3.3.
	The batteries are low.	You shouldreplace them with new ones ahead of time. Refer to section 2.1.
	The batteries are exhausted.	You shouldreplace them with new ones at once. Refer to section 2.1.
E1	Air plug disconnected.	Insert theplug securely. Refer to section 3.1.
	Arm cuffnot applied correctly.	Apply thearm cuff correctly. Refer to section 3.1.
	Air is leaking from the arm cuff.	Replace thecuff with the new one. Refer to Chapter 5.
E2	Movement duringmeasurement and thearm cuff has not been inflated sufficiently.	Repeat measurement. Remain still and do not talk duringmeasurement. Refer to section 3.3.
		If “E2”appears repeatedly, inflate the cuff manually until it is 30 to 40 mmHg above your previous measurement result. Refer to section 3.3.
E3	The armcuff was inflated above 299 mmHg when inflating the cuff manually.	Do not inflate the cuff above299 mmHg. Refer to section 3.3.
E4	Movement duringmeasurement.	Repeat measurement. Remain still and do not talk duringmeasurement. Refer to section 3.3.
E5	Clothing is interfering withthe arm cuff.	Remove any clothing interfering withthe arm cuff.Refer to section 3.1.
E6	Device error.	Contact your localOMRON representative.

Pros & Cons

Pros

• Accurate and consistent readings
• User-friendly interface
• Compact and portable design
• Advanced features like irregular heartbeat detection
• Affordable pricing

Cons

• Some users may find the cuff size limiting
• Batteries may need frequent replacement with heavy use
• No Bluetooth or app connectivity for data tracking

Customer Reviews

Customers generally praise the Omron HEM-7132 for its ease of use and accuracy. Many appreciate the clear display and automatic inflation feature, which makes taking blood pressure readings a simple task. Some users have noted that the device is reliable over time and provides consistent results. However, a few users have mentioned the lack of connectivity features as a drawback.

Calibration and Service

The accuracy of this blood pressure monitor has been carefully tested and is designed for a long service life.

It is generally recommended to have the unit inspected every two years to ensure correct functioning and accuracy. Please consult your local OMRON representative.
