Introduction of Samsung Double Door Refrigerator RFBB82

Double Door Refrigerator RFBB82 is a modern appliance designed to enhance your kitchen with its sleek design and advanced features. This refrigerator boasts a spacious interior with adjustable shelves and a multi-air flow system that ensures even cooling throughout. The energy-efficient design helps reduce electricity consumption while maintaining optimal freshness for your food. Priced at approximately $1,299, the RFBB82 is an excellent investment for any home looking for style and functionality.

Specifications

• Capacity: 28 cu. ft.
• Dimensions: 35.75" W x 69.75" H x 36" D
• Multi-Air Flow Technology for consistent cooling
• Power Freeze and Power Cool functions for rapid cooling
• Adjustable shelves and crisper drawers
• Ice and water dispenser with filtration system
• Smart Home Integration with Wi-Fi Connectivity
• Energy Star certified for energy efficiency

Parts

The actual image and provided parts of the refrigerator may differ, depending on the model and the country.

1. Top hinge
2. Gasket
3. Hinge Mid
4. Drawer
5. Barcode label

Gasket replacement

CAUTION
Make sure you firmly attach the gasket. Otherwise, cold air from the refrigerator may leak.

To remove the gasket
Open the door and remove the gasket from the door.

To replace the gasket
Attach a new gasket to the refrigerator door. Make sure there is no gap between the new gasket and the door.

Drawer Replacement

CAUTION
Check that the drawer is inserted properly into the rail during assembly.

To remove the drawers

Gently lift up the front of the drawer and slide out.

• We recommend that you remove the door bins before removing the drawer. This is to prevent damage to the door bins.

• To reinsert, insert the drawer into the frame rails and then slide inward.



To reattach the drawers
Reattaching the drawers follows the reverse order of their respective removal steps

Hinge replacement

To replace the hinges, you must remove the doors first.

CAUTION

• When removing the doors, take extreme caution because the doors are heavy.
• Before replacing the hinges, put a soft pad such as cardboard on the floor to prevent scratches on the door when you place the doors down.
• As the hinges must be handled carefully and replaced by two or more persons, we recommend you to call for professional technical service.
• If you remove the hinge without holding the door, the door may fall and cause injury.
• Ensure that the shaft is firmly tightened on the hinge.
• Check that the hinge is firmly attached to the cabinet.
• Make sure the wire connectors are connected properly.
• Be careful not to damage the wires when fastening the top cover.

WARNING

• Tilting/laying the refrigerator requires a minimum of 2 people.
• Disconnect the power cord before reversing the doors.

Description

The Samsung RFBB82 refrigerator is engineered to provide optimal storage and cooling performance. The multi-air flow technology ensures that every shelf and compartment maintains the perfect temperature, while the power freeze and power cool functions allow for rapid cooling when needed. The adjustable shelves and crisper drawers provide flexibility in organizing your food items, and the ice and water dispenser with a built-in filtration system offers convenient access to fresh water and ice.

The refrigerator also features a large touchscreen display that allows you to control various settings, receive notifications, and even order groceries online through Samsung's smart home integration. The stainless steel exterior gives it a premium look that complements any kitchen decor.

Samsung Double Door Refrigerator RFBB82 Tools required

(not provided)

1. Phillips screwdriver
2. Flat-head screwdriver
3. Socket wrench 3/8" (10 mm)
4. Pliers
5. Allen wrench 1/4" (5 mm)

To replace the hinges

Disconnect the water line

CAUTION

• Make sure the water hoses are connected with matching colours. (only for Dispenser model)
• To prevent water leaks, each water hose must be inserted fully to the centre of the transparent coupler. (only for Dispenser model)
• Ensure that the water hose surface is not damaged. (only for Dispenser model)

Detach the fridge doors

1. With the doors closed, use a Phillips screwdriver to remove the screws (x3) from the top cover. Pull up and remove the top cover with the connectors.
2. Disconnect the two wire connectors on the left door. The position of the connectors differs with the model.
   CAUTION
   • Do not remove both doors simultaneously. Make sure to remove one door at a time. Otherwise, any of the doors may fall and cause physical injury.
   • Make sure the refrigerator is off before disconnecting the connectors.

3. Disconnect the water tube from the coupler on the left door as shown.



   • This step does not apply to the models without the AutoFill pitcher and the water dispenser.
4. Gently draw up the clamp in several steps.
   To prevent finger injuries, do not apply a sudden force to the clamp.
5. Pull up the clamp to remove.

6. Open the door 90 degrees. While holding the door, pull up and remove the top hinge. Be careful not to damage the connector wires when you remove the hinge.



7. Gently pull up the door vertically to remove. Do not apply excessive force to the door. The door may fall, causing physical injury.
8. Lay the door down on a flat surface.
9. Repeat steps 1-8 for the other door, except for step 3. There is no water tube on the right side door.

   • Step 2 does not apply to the models without the Showcase door.



Hinge Mid

1. Remove the 1 screw (3) with a (+) screw driver and remove the 2 bolts (1, 2) with a 4.95 mm hexagonal wrench to separate the middle hinge.

When reassembling the hinge, be sure to fix it in the following order to prevent the hinge from moving: Bolt (1) g Bolt (2) g Screw (3)

1. You can check where to buy replacement parts at http://samsung.com/support
2. Visit the part purchase site and enter the model code of your product to check the parts available for purchase. The model code is labeled on the outer side of your product.
   • You can check the model code and version on the barcode label at the bottom left of the product.
3. For replacement parts, make sure the part name matches that of the illustration in this manual.
   • User-serviceable parts are limited to handles (some models only), gaskets, drawers, and hinges.

NOTE
Following the repair by a non-authorized service provider, self-repair or non-professional repair of the product, Samsung is not liable for any damage to the product, any injury or any other product safety issue caused by any attempt to repair the product that does not carefully follow these repair and maintenance instructions. Any damage to the product caused by an attempt to repair the product by any person other than a Samsung-certified service provider will not be covered by the warranty.

CAUTION

• The part name listed on the site may differ from that in this manual. Please make sure you choose the right part name.
• Replacing hinges requires extreme caution because it involves detaching the door.
• Be sure to wear safety gloves while making repairs.

Setup Guide

To set up your Samsung RFBB82 refrigerator,

1. Start by carefully unpacking the unit and removing all packaging materials.
2. Ensure the area where the refrigerator will be placed is level and has sufficient clearance for proper air circulation.
3. Next, connect the water supply lines to the ice and water dispenser system. Follow the instructions provided in the user manual for connecting the lines correctly.
4. Plug in the refrigerator and allow it to cool down for a few hours before loading it with food.

Troubleshooting

• If your Samsung RFBB82 is not cooling properly, check if the doors are sealed correctly and ensure that the air vents are not blocked. Also, verify that the temperature settings are correct.
• If the ice and water dispenser is not working, check the water supply lines for any blockages or leaks. Ensure that the filter is clean and properly installed.

For issues related to smart home connectivity, restart the router and ensure that your Wi-Fi network is stable. Refer to the user manual or contact Samsung support for further assistance.

Samsung Double Door Refrigerator RFBB82 Pros & Cons

Pros

• Advanced Cooling Technology: Maintains consistent temperatures throughout the refrigerator.
• Smart Home Integration: Allows remote control and notifications through the Samsung Smart Home app.
• Large Capacity: Provides ample space for storing food items.
• Energy Efficiency: Energy Star certified for reduced energy consumption.
• Stylish Design: Modern and sleek design that fits well in any kitchen decor.

Cons

• High Cost: Priced higher compared to other models in the market.
• Complex Setup: Requires careful setup and configuration, especially for smart features.
• Maintenance Requirements: Regular maintenance of filters and water lines is necessary.
• Noisy Operation: Some users have reported noise from the ice maker and compressor.

Customer Reviews

Customers have praised the Samsung for its excellent cooling performance and spacious interior. Many have appreciated the smart home features, which make managing the refrigerator's settings much easier. However, some users have noted that the initial setup can be complex and that the refrigerator can be noisy during operation.

Common Complaints

• Some users have reported issues with the ice maker not producing ice consistently.
• A few customers have experienced connectivity problems with the smart home app.
