Introduction of Sanyo LED TV XT-43S7300F

The Sanyo LED TV XT-43S7300F is a high-performance television that delivers stunning visuals and immersive audio. With a 43-inch 4K UHD display, this TV offers crisp, clear images and lifelike colors. The TV also comes with smart features, such as built-in Wi-Fi and access to popular streaming services, making it a great choice for anyone who wants a modern and versatile TV. The XT-43S7300F is available for an estimated price of $400 to $500 and was launched in late 2021.

Standard accessories

1. Accessories may not be placed all together. Take care not to throw them away unintentionally.
2. This product contains possibly dangerous parts (such as plastic bags), that can be breathed in or swallowed by young children accidentally. Keep these parts out of reach of young children.

Optional accessories

Wall-hanging bracket

Warning

• Failure to use a Sanyo bracket or choosing to mount the unit yourself will be done at the risk of the consumer. Always be sure to ask a qualified technician to carry out set up. Incorrect fitting may cause equipment to fall, resulting in injury and product damage. Any damage resulting from not having a professional installer mount your unit will void your warranty.
• When any optional accessories or wall hanging brackets are used, always ensure that the instructions provided are followed fully.
• Do not mount the unit directly below ceiling lights (such as spotlights or halogen lights) which typically give off high heat. Doing so may warp or damage plastic cabinet parts.
• Take care when fixing wall brackets to the wall. Wall mounted equipment shall not be grounded by metal within the wall. Always ensure that there are no electrical cables or pipes in the wall before hanging bracket.
• To prevent fall and injury, remove the TV from its fixed wall position when it is no longer in use.

Specifications

Connection Terminals

Basic Connection

Terminals

1. HEADPHONE
2. AV 1 IN
3. PC IN
4. USBx2
5. AV OUT
6. AV 2 IN
7. ANTENNA
8. HDMIx2
9. PC AUDIO IN

Power connection and aerial

Note

1. Do not place the RF cable under the TV.
2. To obtain optimum quality picture and sound, an aerial, the correct cable(750 coaxial), and the correct terminating plug are required.
3. If a communal aerial system is used, you may require the correct connection cable and plug between the wall aerial socket and the TV.
4. Your Sanyo Service Centre or dealer may be able to assist you in obtaining the correct aerial system for your particular area and the accessories required.
5. Any matters regarding aerial installation, upgrading of existing systems or accessories required, and the costs incurred, are the responsibility of vou, the Customer.

External Equipment
These diagrams show our recommendations for connection of your TV to various pieces of equipment.

• Check the type of terminals and cable plugs are correct when connecting.
• Please also read the manual of the equipment being connected.

• Keep the TV away from electronic equipment (video equipment, etc.) or equipment with an infrared sensor. Otherwise, distortion of image / sound may occur or operation of other equipment may be interfered.





Remote Control Functions

Most of your television's functions are available via the menu that appear on the screen. The remote control supplied with your set can be used to navigate through the menu and to configure all general settings.

• POWER (On/Off button): Turns the TV on or off.

• INPUT: when short press open the Input ▲ /▼ to select the desired source, then press Input button to exit.

• USB: Goes to the USB menu.

• 🔇MUTE: Reduces the TV's volume to its minimum level. Press again to restore the volume.

• PICTURE: Toggles through the picture preset settings: Vivid, Sports, Standard, Cinema, Soft, User.

• SOUND: Toggles through the sound modes: Music, Cinema, Standard, Speech, and User.

• AUDIO ONLY: Press to select Audio only mode ON or OFF.

• SLEEP: Sets the TV to turn off after a given amount of time.

• MENU: Brings up the menu system.

• ▲ / ▼ / ◄ / ► RETURN: Exit the menu and return to the previous menu.

• OK: Confirms your selection.

• INFO: Displays the status information.

• EXIT: Exits the menu system.

  • ❚◀ This key will function as previous song, video, picture in USB.

  • ▶❚❚ This key will function as play & pause in USB mode.

  • ■ This key will function as stop in USB mode.

  • ▶❚ This key will function as next song, video, picture in USB.

• VOL +/-: Increases or decreases the TV's volume.

• CH A/V: Scans up or down through the current channel list.

  • ◀◀ This key will function as backward play in USB.

  • ▶▶ This key will function as forward play in USB.

• 0-9 (numeric buttons): Enters channel numbers.

• FREEZE: This key will function to freeze the Picture except on USB Mode.

• ASPECT: Aspect Ratio: Selects the picture size 4:3, 16:9, Zoom1, Zoom2, Full and Just Scan.

Note: Some options may not be selectable for certain signal sources.

Buttons on the TV

Take a certain model for an example:

1. POWER
   Standby or switch on the TV.
2. SOURCE
   Press it to display input source list. Press it continuously to select preferred source and confirm by (VOL+) button. It can be used to confirm submenu in MENU operation.
3. MENU
   Display or exit MENU.
4. VOL-/+
   To be used to adjust volume.
5. CH-/+
   To be used to change channels.

Note: The location and names of the function buttons and power button on the TV may vary according to TV mode.

Description

The Sanyo LED TV XT-43S7300F is a smart TV that offers a range of features to enhance your viewing experience. The 43-inch 4K UHD display delivers stunning visuals with a resolution of 3840 x 2160 pixels, and the TV also supports HDR10 and HLG for even more vibrant colors. The TV is powered by a quad-core processor and comes with 1.5GB of RAM and 8GB of internal storage, ensuring smooth and seamless performance. The XT-43S7300F also has built-in Wi-Fi and supports Bluetooth, allowing you to connect a range of devices to the TV. The TV also comes with a range of smart features, such as access to popular streaming services, such as Netflix, Hulu, and Amazon Prime Video, making it easy to find something to watch.

General Operation

Switching on
Follow the instructions on this page on how to switch on your TV set and the remote control before going on to following pages describing how to use the channel set-up procedure.

1. Insert two AA batteries in the remote control.
   Precautions on using batteries
   • Only use the battery types specified.
   • Make sure you use the correct polarity.
   • Do not mix new and used batteries.
   • Do not use rechargeable batteries.
   • Do not expose batteries to excessive heat such as sunshine, fire or the like, throw them in a fire, recharge them or try to open them, as this could cause them to leak or explode.
   • Remove the batteries from the remote control if you are not using it for a long period of time.
2. Connect the power cable FIRST to the television, THEN to a mains socket.
   (Note: If the power cable is connected to the television, please only connect the power cable to the mains socket.) Your TV set should only be connected to an AC supply. It must not be connected to a DC supply. If the plug is detached from the cable, do not, under any circumstances, connect it to a mains socket, as there is a risk of electric shock.
   Note: The figures are for representation only. The location of the power socket at the back of the television might differ depending on the model.
3. Connect an outside aerial to the ANTENNA IN socket at the back of the TV set. The aerial socket (75 OHM - VHF / UHF / cable) can be used for connecting an external aerial or other equipment fitted.
   Note: For some models with the To by presing the button. If the power indicator lights upred, the TV set is in standby mode. Press the O button on the remote control or on the TV set to turn on the TV.

Switching off

• To put the TV set into standby mode, press the O button on the remote control or on the TV, the TV set remains powered up, but with low energy consumption.
• To switch off the TV set, unplug the mains socket from the mains outlet.

Note: For some models, press the power button to switch off the TV set.

Menu Function

The following instructions will introduce how to access and operate the main menu of the TV. Please note that some function might be unavailable in certain input source.

ANTENNA

• Press MENU button to display the main menu.
• Press up or down button to select ANTENNA in the main menu.
• Press OK button or right button to enter sub-menu.

The Antenna menu allows you to select all the settings required to be able to search for and store all the channels you can receive. You also may edit those channels.

• Auto Tuning: Searches and stores the active channel automatically.
• Manual Tuning: Manually searches and stores the channel in analog mode that have not been stored after automatic tuning.
• Programme Edit: Delete, Rename, Favor Skip a channel.

Manual Tuning Set-up

1. Activate the Antenna menu and press the up or down direction button to select the Manual Tuning option.
2. Press the right direction or OK button to enter the Manual Tuning menu.
3. Select the Current Channel option and press the left or right direction button to select a channel number to store the channel that will be found.
4. Press the up or down direction button to select the Search option to search manually.
5. Press RETURN key to return or Exit to close the menu. Color System: use the left or right direction button to select your desired color system.

(Note: The available color system might differ depending on the model).

Setting the Sound System

1. Activate the Channel menu and press the up or down direction button to select the Sound System option.
2. Press the left or right direction button to select an appropriate sound system: DK, BG,
3. Press RETURN to return or Exit to close the menu.

Fine-Tune
If the picture is not clear you can fine tune the channel.

1. Activate the Channel menu and press the up or down direction button to select the Fine-Tune option.
2. Press the left or right direction button to fine tuning.
3. Press Retum key to return or Exit to close the menu. Programme Edit
   You can use this function to Delete, Rename, Skip the channel.
4. Activate the Programme menu and press the up or down direction button to select the Programme Edit option.

5. Press the right direction or OK button to enter the Programme Edit menu.



Setup Guide

Setting up the Sanyo LED TV XT-43S7300F is a straightforward process. First, unbox the TV and attach the stand to the bottom of the TV. Then, plug in the power cord and connect any devices you want to use with the TV, such as a cable box, Blu-ray player, or game console. Next, turn on the TV and follow the on-screen prompts to connect the TV to your Wi-Fi network and sign in to your Sanyo account. From there, you can customize the TV's settings and start watching your favorite shows and movies.

Advanced Functions

Adjusting the Picture
The menu for adjusting the picture are used to obtain the best picture setting according to your preference, the type of programme you are watching and the ambient lighting.

• Press up or down button to select Picture in the main menu.
• Press OK button or right button to enter sub-menu..

Note: Some options may be not available for certain signal sources.

• Picture Mode: Use the up and down direction button to select Picture Mode, then press the left or right direction button to select the picture preset settings:Vivid, Sports, Standard, Cinema, Soft, User.
• Contrast: Adjusts the difference between the light and dark areas of the picture.
• Brightness: Adjusts the brightness of the picture.
• Color: Adjusts the richness of color.
• Hue: Adjusts the balance between the red and green

Note: Hue is available to be adjusted only when the system of the video signal is NTSC.

• Sharpness: Adjusts the crispness of the edges in the picture.
• Backlight: This option can be used to adjust the Intensity of the backlight, depending on room lighting. Use the left or right direction button to adjust.
• Color Temperature: Adjusts the color temperature of the picture. Options include Medium, Warm and
• Cool: Cool is for a more blue palette of picture colors; Warm is for a more red palette of picture colors; Medium is between the two.
• Noise Reduction: Options include: Off, Low, Middle and High.

Adjusting the Sound

1. Press MENU button to display the main menu.
2. Press down or up button to select Sound in the main menu.
3. Press OK button or right button to enter sub-menu. The Sound menu allows you to adjust each option for your listening pleasure.
4. Sound Mode: Options include Music, Cinema, Standard, Speech and User.
5. Bass: Adjusts the Low frequency settings.
6. Treble: Adjusts the High frequency settings.
7. Balance: Adjusts the volume between the left and right speaker. Sets to "0 "in the normal condition.
8. Audio Only: TV will deliver only sound and screen will be turned off. Auto Volume level: Options include Off and On.

Timer

• Press MENU button to display the main menu.
• Press down or up button to select Timer in the main menu.
• Press OK button or right button to enter sub-menu.

1. Sleep Timer: Sets a period of time after which the TV set goes into standby mode.
2. OSD Timer: No action menu display time.

Note: It turns off automatically without signal in 10 minute.

Settings

• Press MENU button to display the main menu.
• Press down or up button to select Settings in the main menu.
• Press OK button or right button to enter sub-menu.
• Press down or up button to select the option that you want to adjust in the Settings menu.
• Press left or right button to adjust or OK button enter.
• After finishing your adjustment, Press RETURN button to save and return back to the previous menu.
• OSD Language: English
• Aspect Ratio: Selects the picture size: 4:3, 16:9, Zoom1,Zoom2,Full,Just Scan.

Note: Some options may be not selectable for certain signal sources.

• Blue Screen: Set blue screen when there is no signal.
• Reset: Press left button selecting Yes to restore factory default.
• Sound Out: When the sound out Setting is enabled on your TV,the TV set's speakers will mute automatically and the audio will be outputted on your sound device system.

Note: There is no Sound out during the volume adjustment operation. Sound can be get when operation done.

• Location: Press to select Home or Shop mode.
• Home Mode: You would be able to view the standard

Lock

Press MENU button to display the main menu. Press down or up button to select Lock in the main menu. Press OK button or right button to enter sub-menu. This function allows you to effectively stop anyone without the correct password from watching TV.When you select the Lock System is On, the menu is changed, the options Include Set Password, Channel Lock and Key Lock.

• Lock System: On/Off.
• Set Password: Sets a new password for operating TV. the default password is"0000".
• Channel Lock: Lock the program you set.
• Key Lock: Lock buttons on the TV.

Selecting a Signal Input

Press the input button on the remote control to switch the inputs.

Selecting a Signal Source

1. Press the up or down direction button to select your desired source.
   (Note: The available source might differ depending on the model.)
2. Press the OK button to confirm the selection.

Multimedia

1. Connect a USB device to a USB socket and press USB key on remote to enter USB input mode.
2. You can also select USB input by selecting input button. In USB state, if no USB device connected, the USB interface will be displayed.


1. Select Photo Icon, then press the OK button to enter the USB device.
2. Press the up, down, left or right direction button to select your desired picture file and press OK to show.
3. When showing pictures,you can press OK the button to display the play console. For the play console,press the left or right direction button to select an icon, then press the OK button to confirm. The play console includes: Play/Pause, Prev, Next, Stop, Repeat Mode, Music On/Off, Playlist, Info., Rotate(clockwise), Rotate(anticlockwise), Zoom In, Zoom Out, Move View.
4. Select the Stop icon in play console, and press OK or press Exit to return.

Movie

1. Select Movie Icon, then press the OK button to enter the USB device.
2. Press the up, down,left or right direction button to select a movie file, then press OK to play it.
3. When playing a movie, you can press the OK button to display the play console. For the play console, press the left or right direction button to select an icon, then press the OK button to confirm. The play console includes:Play/Pause,FB,FF, Prev.,Next, Stop, Repeat Mode, AB Repeat setting, Playlist, Info., Slow Forward, Step Forward, Goto Time, Zoom In, Zoom Out, Aspect Ratio and Move View.

Music

1. Select Music Icon, then press the OK button to enter the USB device.
2. Press the up, down, left or right direction button to select your desired music file and press OK to play it.
3. When playing music, press the OK button to display the play console. For the play console, press the left or right direction button to select an icon, then press the OK button to confirm. The play console includes: Play/Pause, FB, FF, Prev., Next, Stop, Repeat Mode, Mute, Playlist, Info. and Goto Time.
4. While playing music, press ❚◀to Previous, ▶❚❚ to Play/Pause, ■ to Stop, ▶❚ to Next.
5. While playing music, press ◀◀ to Fast Backward and press ▶▶ to Fast Forward.
6. Select the Stop icon in play console, and press OK or press Exit to return.

Notes

1. Some non-standard mobile storage device may not be recognized. Please change to use the standard device.

2. This system supports the following file formats:
   Picture format: JPEG. BMP. PNG



Note: For coding files, there are many kinds of nonstandard coding method, so this system can not be guaranteed to support the file formats using any coding method.

1. Under the following conditions, this system cannot decode the file and the file cannot be play normally:
   • The parameters of file, such as the pixel of picture, code rate of audio and video file, sampling rate of audio file, exceed the limit of the system;
   • The format of file is not matched or the file is harmed.
     Note: The code rate of this system does not support exceed 20Mbps.
2. Hot plug: Do not disconnect when the system is reading or transmitting data, avoid damaging the system or the device.
3. Pay attention to the power supply of the device when you are using a mobile hard disk or a digital camera. If the power supply is not sufficient or not stable, you may encounter problems during operating or can not operate at all. In this case, please restart the device, or unplug the device and plug it again, and ensure that its power supply is normal.
4. The system supports standard USB1.1 and USB2.0 devices, such as standard U-disks, MP3 players, mobile hard disks, etc..
5. For obtaining better audio and video quality, It is suggested to use the external device which accords with USB2.0 standard.
6. When playing the video with high compression ratio, these phenomenon, such as picture standstill and menu long time response, are normal.
7. For some USB device with power supply, such as large size hard disk, MP4, etc., Suggests using it with power to avoid electric power shortage. The parameters of file, such as the pixel of picture, code rate of audio and video file, sampling rate of audio file, exceed the limit of the system.

PC Settings

Display the menu by pressing the MENU button. Press the up or down direction button to select the PC icon and press the OK button to enter the PC menu.
Note: This function is only available in PC mode.

1. Auto Adjust: Press the right direction or OK button to adjust the picture's position, phase and clock automatically. The menu will auto exit when finishing the adjusting.
2. Note: This function is only available in PC mode.
3. H Position (Horizontal Pos.): Adjusts the picture's position left or right.
4. V Position (Vertical Pos.): Adjusts the picture's position upward or downward.
5. Clock: Adjusts the clock sync of the picture.
6. Phase: Adjusts the picture if there is flicker of screen letters, color misalignment, or blurring.

Reset Position

1. Press the OK button to restore the default position.
2. Press Return key to return to menu & Exit key to close the menu.

Troubleshooting

Most problems you encounter with your TV can be corrected by consulting the following troubleshooting list.

No picture, no sound

1. Plug another electrical device into the outlet to make sure it is working or turned on.
2. Power plug is in a bad contact with the outlet.
3. Check the signal source.

No color

1. Change the color system.
2. Adjust the saturation.
3. Try another channel. Black-white program may be received.

Remote control does not work

1. Change the batteries.
2. Batteries are not installed correctly.
3. Main power is not connected.

No picture, normal sound

1. Adjust the brightness and contrast.
2. Broadcasting failure may happen.

Normal picture, no sound

1. Press the Vol+ button to increase volume.
2. Volume is set to mute, press the mute button to restore soundl
3. Change the sound system.
4. Broadcasting failure may happen. Unorderly ripples on the picture It is usually caused by local interference, such as cars, daylight lamps and hair driers. Adjust the antenna to minimize the interference.

Blank screen when connected computer system
Perhaps the TV can not recognize the resolution set by the PC. Suggest to change to the best resolution or other standard resolutions of the Windows system.

Sanyo LED TV XT-43S7300F Pros & Cons

Pros

• 43-inch 4K UHD display with HDR10 and HLG support
• Quad-core processor and 1.5GB of RAM for smooth performance
• Built-in Wi-Fi and Bluetooth connectivity
• Access to popular streaming services
• Affordable price

Cons

• Limited internal storage (8GB)
• No voice control feature
• Only one HDMI input

Customer Reviews about Sanyo LED TV XT-43S7300F

Customers who have purchased the Sanyo LED TV XT-43S7300F have praised its stunning visuals and immersive audio. Many have also appreciated the TV's smart features and affordable price. However, some have noted that the TV's limited internal storage and lack of voice control feature can be frustrating. Some customers have also reported issues with the TV's Wi-Fi connectivity.
