Introduction

The Powr-Flite Comfort Pro Backpack Vacuum BP10S is a highly efficient cleaning solution designed for both commercial and residential use. This lightweight vacuum features a 10-quart capacity and is engineered for superior comfort, allowing users to clean for extended periods without fatigue. With its powerful suction and versatile tool kit, the BP10 excels at tackling various surfaces, including carpets and hard floors. Priced at approximately $399, it offers exceptional performance and productivity for any cleaning task.

Check the carton for shipping damage. Carefully unpack and inspect your new Powr-Flite vacuum for shipping damage. Each unit is tested and thoroughly inspected prior to shipping. If damage is discovered, immediately notify the transportation company that delivered your machine and request an inspection. As a manufacturer, we are unable to act upon any claim for concealed damage; you must originate the claim. Be sure to keep the carton, packing inserts, packing lists, and carrier’s receipt until the inspector has verified your claim.

Hands-free tool kit

REPLACEMENT / ACCESSORIES

REPLACEMENT / ACCESORIES
MODEL	COMFORT PRO 6 - BP6S & BP6P	COMFORT PRO 10 - BP10S & BP10P
MICRO HEPA FILTER BAG (10 PK)	X9739	X9737
CLOSED MOUTH PAPER BAG (10 PK)	X9735	X9736
OPEN MOUTH PAPER BAG (10 PK)	X9737	X9738
MICRO CLOTH BAG	X9679	X9692
INLET FILTER	X9683	X9683
EXHAUST FILTER	X9682	X9682
50' POWER CORD	X9714	X9714

SPECIFICATIONS

PRODUCT SPECIFICATIONS
MODEL	COMFORT PRO 6	COMFORT PRO 10	COMFORT PRO 6 PREMIUM	COMFORT PRO 10 PREMIUM
ITEM#	BP6S	BP10S	BP6P	BP10P
TOOL KIT*	Standard	Standard	Hands-Free	Hands-Free
BODY	High Density Polyethylene	High Density Polyethylene	High Density Polyethylene	High Density Polyethylene
DIMENSIONS (L X W X H)	10 in x 12.5 in x 26.5 in 25.4 cm x 31.8 cm x 67.3 cm	13” x 11.5” x 26.5” 33 cm x 29.2 cm x 67.3 cm	10 in x 12.5 in x 26.5 in 25.4 cm x 31.8 cm x 67.3 cm	13” x 11.5” x 26.5” 33 cm x 29.2 cm x 67.3 cm
MACHINE WEIGHT (LBS. / KG)	8.62 lbs. / 3.22 kg	9.62 lbs. / 4.3636 kg	8.75 lbs. / 3.9689kg	9.75 lbs. / 4.4225 kg
HARNESS WEIGHT (LBS. / KG)	3.2 lbs. / 1.45 kg	3.2 lbs. / 1.45 kg	3.2 lbs. / 1.45 kg	3.2 lbs. / 1.45 kg
CORD LENGTH / TYPE	50 ft. / 15 m, direct plug	50 ft. / 15 m, direct plug	50 ft. / 15 m, direct plug	50 ft. / 15 m, direct plug
CAPACITY (QUARTS / LITERS)	6 qt. / 5.69 l	10 qt. / 9.46 l	6 qt. / 5.69 l	10 qt. / 9.46 l
FILTRATION	5 stage HEPA	5 stage HEPA	5 stage HEPA	5 stage HEPA
WATERLIFT	110 in. / 279 cm	110 in. / 279 cm	110 in. / 279 cm	110 in. / 279 cm
CFM /CMM	130 cfm / 3.68 cmm	130 cfm / 3.68 cmm	130 cfm / 3.68 cmm	130 cfm / 3.68 cmm
CLEANING PRODUCTIVITY	7,407 sq. feet per hour 688 sq. metersper hour	7,407 sq. feet per hour 688 sq. metersper hour	7,407 sq. feet per hour 688 sq. metersper hour	7,407 sq. feet per hour 688 sq. metersper hour
SOUND LEVEL	62 dBa	62 dBa	62 dBa	62 dBa
VACUUM MOTOR	1200 W / 10 Amp	1200 W / 10 Amp	1200 W / 10 Amp	1200 W / 10 Amp
POWER	120V / 60Hz	120V / 60Hz	120V / 60Hz	120V / 60Hz
APPROVALS	CRI Gold Level Approved	CRI Gold Level Approved	CRI Gold Level Approved	CRI Gold Level Approved
230V AVAILABLE	Yes	Yes	Yes	Yes

Specifications and parts are subject to change without notice.
Please refer to https://www.Powr-Flite.com for the latest schematic drawing and parts list.

IMPORTANT SAFETY INSTRUCTIONS

Save These Instructions

SAFETY WARNINGS AND PRECAUTIONS

WARNING! Read all instructions before using. Save These Instructions.
Following the cleaning instructions will prolong the life of your Powr-Flite vacuum.

When using an electrical appliance, basic precautions should always be followed.

Use only as instructed in this manual. Use only the recommended attachments and replacement parts.
Do not leave vacuum cleaner plugged in when not in use. Unplug vacuum before servicing.
Do not use outdoors or on wet surfaces.
Do not use to pick up liquids. This vacuum is for Dry Pickup only.
If the unit is not working as it should, has been dropped, damaged, left outdoors, or exposed to water, return it to a service center before using.
Do not vacuum up hard or sharp objects, as they may damage the hose, vacuum bag or the vacuum motor.
Do not use without paper vacuum bag, cloth bag and filters in place.
Do not operate the vacuum while it is standing on high-pile carpet. The exhaust airflow is restricted and will cause the unit to overheat.
Do not use with damaged cord or plug.
Do not kink or twist the power cord.
Do not pull or carry by the cord, use the cord as a handle, close a door on cord, or pull cord around sharp edges or corner. Do not run vacuum cleaner over cord. Keep cord away from heated surfaces.
Do not pull on the cord to unplug. Grasp and pull the plug, not the cord. Turn off the vacuum before unplugging.
Do not handle the cord, plug, switch or vacuum with wet hands.
Do not use outlets with inadequate current capacity.
Do not use an extension cord with this vacuum.
Do not put any objects into openings. Do not use with any opening blocked. Keep free of dust, lint, hair and anything that might reduce airflow.
Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
Use with extra care when cleaning stairs.
Do not vacuum flammable or combustible materials or anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
Do not use with dust bag not in place.
Sparks inside the motor can ignite flammable vapors or dust. To reduce the risk or fire or explosion, do not use near combustible liquids, gases, or dusts, such as gasoline or other fuels, lighter fluid, cleaners, oil-based paints, or natural gas.
To reduce the risk of inhaling toxic vapors do not vacuum or use near toxic or hazardous materials.
Keep children and unauthorized persons away from the vacuum when in use.
This machine is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge.
Do not attempt to service the vacuum yourself. Repair by anyone other than an authorized repair service center may void the warranty.
Store the vacuum indoors in a cool, dry area.

CONNECT TO A PROPERLY GROUNDED OUTLET ONLY!

See Grounding Instructions

This vacuum must be grounded! Grounding is a safety measure to reduce the risk of electrical shock to the operator should the machine malfunction or stop working. Grounding provides the path of least resistance for electric current and will trip the circuit breaker, stopping the flow of electricity.
This unit is equipped with a cord that has an equipment-grounding conductor and grounding plug. The plug must be inserted in an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. Cutting off the ground wire or using a cord that is not equipped with a ground plug will void the warranty on the unit. Powr-Flite will accept NO liability associated with the unit.

WARNING! Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the outlet is properly grounded. Do not modify the plug provided with the appliance. If it will not fit the outlet, have a proper outlet installed by a qualified electrician.

The vacuums are for use on a nominal 120-volt circuit, and have a grounded plug that looks like the plug illustrated in Figure A. A temporary adapter that looks like the adapter illustrated in Figure B and C may be used to connect this plug to a 2-pole receptacle as show in Figure B if a properly grounded outlet is not available. The temporary adapter should be used only until a properly grounded outlet (Figure A) can be installed by a qualified electrician. The green colored rigid ear, lug, or the like, extending for the adapter must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the adapter is used, it must be held in place by a metal screw.


Note: In Canada, the use of a temporary adapter is not permitted by the Canadian Electrical Code.

WARNING! The replacement or repair of damaged wiring should only be performed by a qualified electrician or service engineer from the manufacturer or authorized service center.The replacement or repair of damaged wiring should only be performed by a qualified electrician or service engineer from the manufacturer or authorized service center.

Description

The Powr-Flite Comfort Pro Backpack Vacuum BP10 is engineered with comfort and efficiency in mind. The ergonomic backpack design distributes the weight evenly, reducing strain on the user's back and shoulders. The vacuum features a powerful motor that delivers high suction power, making it capable of picking up dirt, dust, and debris efficiently. The 10 quart dust bag provides ample capacity for extended cleaning sessions without frequent emptying.

The BP10 also includes a HEPA filter and pre-filter, ensuring that the air expelled is clean and free from allergens. Additional tools such as a crevice tool, upholstery tool, and dusting brush are included to handle various cleaning tasks.

OPERATING INSTRUCTIONS

IMPORTANT!
PERFORM PROPER INSTALLATION OF HEPA BAGS AND CORD IN COMFORT PRO BACKPACK VACUUMS.

Please read the following instructions carefully. They will help to get the best performance from this professional commer-cial vacuum cleaner and to maintain it in optimum condition. Always make sure the main power of the vacuum is off and the unit is not plugged in when doing any maintenance on the vacuum.

Preparing To Vacuum

Remove vacuum hose from top of unit. (Fig. 1)
Release the two latches and lift off lid. (Fig. 2)
Ensure Micro Cloth bag is fully seated on Comfort Pro tank housing. (Fig. 3)
Fold the bottom 2” of the HEPA bag up and hold into place.(Fig. 4)
Insert HEPA bag inside of micro cloth bag. (Fig.5)
Squeeze bag just below the cardboard collar and drop onto rubber gasket. (Fig. 6)
Ensure that white bag is not protruding under cardboard collar.(Fig. 7)
NOTE: Cardboard must be properly seated inside gasket groove. Cardboard will be flush with gasket. (Fig. 8)
Replace lid, lock down the two latches and install hose. (Fig. 9).
Ensure the extension cord is wrapped around the cord retainer on the harness with 6 inches of cord from the retainer to the end of the plug. (Fig. 10)
WARNING! Always use the cord retainer. There is a risk of electrical shock/damage to the backpack vacuum if cord retainer is not used. (Fig. 10)
Then plug the extension cord to the plug receptacle.
Store the power cord on the cord hook located on the harness after each use. (Fig. 11)

WARNING! Always unplug machine before cleaning, or making any adjustments or repairs.

The backpack vacuum has four levels of filtration: the paper vacuum bag, a micro cloth filter, a pre-motor filter and an exhaust filter. These bags and filters capture fine dust particles and protect the motor from dirt. It is important to replace the paper bag when it is no more than ½ full and to clean the filters on a regular schedule and replace as necessary.

Paper Vacuum Bag

Remove paper bag. Insert a new paper bag into the cloth bag, making sure the cardboard disk is centered on the flexible sealing ring. When you replace the lid, the short nozzle in the center of the lid will be closed over the central hole of the cardboard disk of the paper vacuum bag providing a seal. (Fig. A)
Replace the lid. Fasten latches and replace hose. (Figs. C-D)
Micro Cloth Filter
After each use, the cloth filter bag should be inspected.
Remove the micro cloth bag, clean and replace. (Fig. B)
Replace paper vacuum bag and lid. Fasten latches and insert hose. (Figs. C-D)
Pre-Motor Filter
The pre-motor filter is located under the micro cloth filter. Inspect after each use. The filter can be washed using cold water and no detergent. Lay flat to dry. Replace every 6 months.
Remove the lid, the paper vacuum bag, and the cloth bag to expose the pre-motor filter.
Remove the foam pre-motor filter from the dust compartment, clean and replace. If filter is extremely dirty, rinse out and air dry before replacing back into vacuum.(Fig. E)
Reinstall the cloth bag, the paper vacuum bag and replace the lid, fasten latches and insert the hose. (Figs. C-D)
Exhaust Filter
The exhaust filter is an easy-access washable, reusable post-motor filter located on the bottom of the vacuum. For average use of the vacuum, remove and clean the exhaust motor filter every 3 months. The filter can be rinsed using cold water and no detergent. Lay flat to dry. Replace once a year.
Remove the foam post motor filter, clean and replace.
Reinstall the filter at the bottom of the vacuum. (Fig. F)

Wearing the Backpack Vacuum

The backpack is designed to balance the weight of the vacuum on the hips, not the shoulders.

Adjust the Vari-Quick height adjuster to your back length.
Loosen all of the straps and place the vacuum on your back.
Place the hip belt over your hip and connect the buckle. Your hip bones should be centered between the top and bottom of the belt. Pull the straps forward to tighten the hip belt. (Fig. 1)
Pull down the shoulder straps to tighten the backpack on your shoulders. (Fig. 2) Do not tighten too tight. The main weight of the vacuum should be on the hip belt. The anchor points of the shoulder straps should ideally be between the shoulder blades. Adjust the Vari-Quick height adjuster if necessary to properly place the vacuum to your back length.
Adjust the sternum strap on a comfortable part of your chest and close the strap. (Fig. 3)
Loosen or tighten the stabilizer straps as needed, to fit your back. (Fig. 4)
Do final adjustments on the shoulder and stabilizer straps as needed to balance the weight of the vacuum on the hips.

Active Cooling (Premium Model)

To turn Active Cooling on, raise silver metal bar. (Fig. 5)
Warm air will be pulled into machine and circulate cooler air through mesh on Deuter harness. Active Cooling can be turned off by lowering silver metal bar. (Fig. 6)
Active Cooling can stay open all the time.

Setup Guide

To operate the Powr-Flite Comfort Pro Backpack Vacuum BP10, follow these steps:

Assemble the vacuum by attaching the hose to the motor unit and ensuring all connections are secure.
Put on the backpack harness and adjust it to fit comfortably.
Plug in the vacuum and turn it on using the switch located on the handle.
Use the included tools to clean different areas such as floors, stairs, upholstery, and tight spaces.
Regularly check and replace filters as needed to maintain optimal performance.

MAINTENANCE

Routine maintenance can significantly increase the life of your backpack vacuum. The applications and amount of use varies, so the recommendations listed below are for average-to-high volume use. Constant operation may require additional maintenance.

Before Each Use

Inspect power cord for fraying, cuts or damage; do not use if damaged.
Verify that paper vacuum bag is installed.
Place the hip belt over your hip and connect the buckle. Your hip bones should be centered between the top and bottom of the belt. Pull the straps forward to tighten the hip belt.
Pull down the shoulder straps to tighten the backpack on your shoulders. Do not tighten too tight. The main weight of the vacuum should be on the hip belt. The anchor points of the shoulder straps should ideally be between the shoulder blades. Adjust the Vari-Quick height adjuster if necessary to properly place the vacuum to your back length.
Adjust the sternum strap on a comfortable part of your chest and close the strap.
Loosen or tighten the stabilizer straps as needed, to fit your back.
Do final adjustments on the shoulder and stabilizer straps as needed to balance the weight of the vacuum on the hips.

After Each Use

Unplug cord from wall outlet by pulling on the plug - not the cord.
Lay plug on ground.
Start at machine and loosely wrap (loop) power cord.
Secure the end of the power cord to itself using latch on the plug of the power cord.
Hang cord on cord hook.

Periodic Maintenance

Inspect all electrical connections.
Check the power cord for any breaks, fraying, separations, or cuts.
Make sure the ground pin or grounding prong is intact.

TROUBLESHOOTING

If the vacuum will not turn on:

Make sure the power cord is firmly connected to the unit and is in good condition.
Check sure the power cord is firmly seated in the wall outlet.
Check to see if the building circuit breaker is tripped. If circuit is overloaded, move the unit to another circuit.

The backpack vacuum has been fitted with a thermal overload switch to protect the motor against damage should the airflow be blocked for extended periods. This may occur if the vacuum bag is overfull, the micro cloth bag is clogged, or if the vacuum hose or exhaust is blocked. The vacuum motor will stop before it can get too hot. If this happens, empty and thoroughly clean the vacuum bag and filters, or free any blockage and ensure that adequate airflow is restored. After the motor has cooled to a safe operating temperature, locate the thermal reset switch on the bottom of the unit, under the post motor filter and push it back in. There will be a slight audible click. Now the motor will restart.

TOOL KITS

Install the floor tool to the end of the wand. Align the brass ring with the groove on the floor tool to ensure a secure fit.

To properly attach one-bend adapter (#J1007) to the one-bend telescopic wand (#CT170):
Install the adapter on the wand with the line pointing to the center of the notches on the wand. Install floor tool onto adapter and tighten plastic nut to secure.

TOOLS SCHEMATICS AND PARTS LIST

SCHEMATIC BP10S

STANDARD TOOL KIT - FITS - BP10S
ITEM	DESCRIPTION	PART NO.	OTY
1	CARPET TOOL W/CLIP	B352-PF10	1
2	HARD FLOOR TOOL W/CLIP	C352-PF20	1
3A	DOUBLE BEND WAND	CT171	1
4	17" CREVICE TOOL W/CLIP	CT176	1
5	3" DUSTING TOOL W/CLIP	CT184	1
6	5" UPHOLSTERY TOOL W/CLIP	CT188	1
7	POWR-GLIDE CARPET TOOL W/CLIP	CT194	1
8	4' CRUSH PROOF HOSE W/90° CUFF	J1006	1
10	POWR-GLIDE CARPET TOOL BODY W/CLIP	CT190	1
11	90 DEGREE SWIVEL CUFF	J1004	1

SCHEMATIC – BP6S - BP10S

ITEM	DESCRIPTION	PART NO.
1	#6 FLAT WASHER ZP	01575
2	HARNESS MOUNTING WASHER	02568
3	WASHER #10 INT TOOTH,LOCK	7CY001
4	LID LATCH	A352-3300
5	FEMALE RIVOTFOR BELT PANEL	A352-9401
6	BELT PANEL MOUNTING SCREW	A352-9402
7	THERMAL RESETSWITCH	B333-0400B
8	5.1" VACUUMMOTOR	B395-2000
9	STRAIN RELIEF	PD8
10	SMALL MADE IN THE USA LABEL	X1004
11	PLUG COVER,COMFORT PRO	X1042
12	8-32 POST MOLD INSERT	X1075
13	12A CIRCUITBREAKER	X1141
14	BACKPACK SWITCHASSEMBLY	X1151
15	PAN HEADSHOULDERED PHILLIPS M4X7 BLACK	X1257
16	NEOPRENE RUBBERNUT	X1466
17	NUT, LOCK,1/2" STEEL CONDUIT	X8008N
18	6-32 NYLONLOCK NUT	X8257
19	10-24 NYLONLOCK NUT ZP	X8271
20	SCREW 8-32 X 1/2 PAN	X8278
21	BOLT 1/4-20X 1" HEX	X8282
22	LABEL, SERIALNUMBER, PLAIN	X8459
23	MOUNTING RIVOT	X8946
24	GASKET 3/8" DONUT MOTOR SEAL	X9079
25	DEUTER HARNESS	X9658
26	HOUSING 10QTCOMFORT VAC WITHFILTER	X9663-F
27	HOUSING 6QT COMFORT VAC WITH FILTER	X9664-F
28	10 QUARTLID	X9665
29	6 QUARTLID	X9666
30	EXHAUST FILTERPLATE	X9667
31	MOTOR SHIELD	X9669
32	HARNESS FRAME	X9670
33	MOTOR MOUNTING BRACKET	X9671
34	BELT CLIP PANEL	X9672
35	8-18 3/4LONG HI LO SCREW	X9676
36	PLUG RECEPTICLE	X9677
37	6 QUARTCLOTH BAG	X9679
38	RUBBER MOTORMOUNT	X9681
39	EXHAUST FILTER	X9682
40	MOTOR PLATEGASKET	X9684
41	HOUSING BUMPER	X9685
42	POWR-FLITE LABEL	X9687
43	MOTOR MOUNTING BOLT	X9688
44	8-18 HI-LOSCREW	X9690
45	10 QUARTSMS BAG	X9692
46	9" LONGPIPE INSULATION	X9693
47	WARNING LABEL	X9697
48	HARNESS LABEL	X9698
49	MOTOR MOUNTING WELDNUT	X9713

50	18 GAGE50' YELLOW EXTENSION CORD	X9714
51	CORD HOOK	X9718
52	COMFORT PRO LABEL	X9729
53	SCREW CAP BASE	X9733
54	SCREW CAP	X9734
55	6 QUARTHEPA BAG	X9739
56	10 QUARTHEPA BAG	X9740
57	CRI GOLDLABEL	X9742
58	10-24 X 1.75" PHILPAN HEAD SCREWBLACK	X9746
59	#10 USS FLAT WASHERBLACK	X9747
60	6-32 X 5/8 PHIL PAN SCREW BLACK	X9748
61	MOTOR RESETLABEL	X9755
62	RIVET	X9758

POWER-FLITE LIMITED WARRANTY

PARTS: New or comparable rebuilt parts, for one year after original purchase. Lifetime warranty on molded body.

This warranty covers normal use and does not cover damage which occurs in shipment or failure resulting from alteration, accident, misuse, abuse, neglect, or improper maintenance.

Pros & Cons

Pros:

Ergonomic Design: Reduces user fatigue with comfortable backpack harness.
High Suction Power: Efficiently cleans large areas and various surfaces.
Lightweight: Easy to maneuver and transport.
HEPA Filtration: Ensures clean air and reduces allergens.

Cons:

Noisy Operation: The motor can be loud during use.
Cord Management: The 50-foot cord can be cumbersome to manage.
Filter Maintenance: Requires regular filter checks and replacements.

Customer Reviews

Customers praise the Powr-Flite Comfort Pro Backpack Vacuum BP10 for its comfort and efficiency. Many users appreciate the lightweight design and high suction power, which makes it ideal for extended cleaning sessions. However, some users have noted that the vacuum can be noisy and requires careful cord management.

Common complaints include the need for regular filter maintenance and the occasional issue with loose connections. Overall, the BP10 is well-regarded for its performance and durability.

Search Manuals in: backpack

Read More

Read More

Read More

Read More
