Prestige Induction Cooktop PIC 16.0 Introduction

Prestige Induction Cooktop is a modern gadget for healthy and safe cooking. It’s special Anti Magnetic wall ensures that you cook with highest efficiency and ease. Prestige Induction Cook-tops are carefully manufactured tested and packed so as to give you trouble-free performance. After all, it is from Prestige, a trusted name in kitchen appliances for generations in India with customers countrywide. We are sure that Prestige Induction Cook-top will help you to reduce the time you spend in kitchen, still providing healthy food for your family.
Please read the instruction manual carefully, before use. Priced at $33.23, it offers excellent value for those seeking convenience and efficiency in meal preparation.

TECHNICAL SPECIFICATIONS

Model	Power	Voltage	Warranty
PIC 16.0	1600 watts	230 V AC, 50 Hz	1Year

KNOW YOUR PRESTIGE INDUCTION COOK-TOP

CONTROL PANEL

Description

The Prestige Induction Cooktop PIC 16.0 is designed to provide an efficient and enjoyable cooking experience. Its sleek, minimalist design complements any kitchen decor while delivering precise temperature control for consistent results. Enjoy even heat distribution and reduced cooking times, thanks to its innovative induction technology. Save energy, time, and money without compromising on quality or performance.

HOW TO USE YOUR PRESTIGE INDUCTION COOK-TOP

Please place the Cooktop in a well-ventilated area on a flat platform. Do not place the Induction Cooktop on any metal surface or near a heat or fire source.
Insert the plug into the socket.
Once the mains switch is switched on, a beep sound is heard and all the LEDs on the control panel glow.
Now press the “ON/OFF” button, “ON” LED glows.
Place the vessel at the center of the glass panel.
Select the required function button as per the cooking requirement. If you hear any noise while using it it, slightly move the vessel so that it lies in the center of the glass panel.

Functions and operating instructions

“ON/OFF” button

Press the “ON/OFF” button to switch on or switch off the Induction Cooktop.
The induction cooktop will switch off automatically upon reaching the mentioned time limit.

Temperature adjustment

Upon selecting a work function, you can adjust the temperature by pressing the “+”/ “-” button.
The temperature function will not be available in Keep Warm mode.
In the course of heating, the intelligent heating function will automatically control the temperature based on need.

“TIMER” button

When the timer function is not set, the induction cooktop will heat continuously/ as per the preset duration for each mode.
When you need to adjust the timer, press the “TIMER” button. Once the display starts blinking you can adjust/set the timing by pressing the “+” / “-” button.
Once the required time is set, the display will blink for 4 times before becoming stable and the timer will start. The maximum possible time is 180 minutes.
Once the induction cooktop works for the time mentioned, it will stop heating and will switch off automatically.

Cooking Modes

Pressure Cook mode: This function can be used for all your pressure cooking needs. The heating power/timer is adjustable in this mode, while the appliance is in operation. It will start default at 1100 watts and can be increased up to 1600 watts. The timer function can be used in this mode. This mode can also be used for all other kinds of cooking. You can increase or decrease the power by using the”+” or “-“ buttons as per your requirement. If the vessel is dried out during operation, the Induction Cooktop will switch off automatically.
Curry mode : This function is suitable for making curries. You can increase or decrease the power by using the ”+” or “-“ buttons. It will start default at 900 watts and can be increased up to 1300 watts. The timer function can be used in this mode.
Dosa/Chapati mode: This mode is specially designed to make dosa, chapati,, and other similar items. The timer cannot be varied in this mode. It will start default at 1100 watts. You can increase or decrease the power by using the ”+” or “-“ buttons as per your requirement. However, the maximum power which can be set in this mode is 1100 watts. It is recommended to use only this mode while using tawa for making dosa, chapati, and other similar items.
Idly mode: This mode is suited for making idly and other similar items. The default time set is 10 minutes, however,, you can increase the timer by pressing the “TIMER” button.
Deep Fry mode: Applicable for high-temperature cooking, like frying and deep frying. The temperature is adjustable in this mode, while the appliance is in operation. It will start at a default temperature of 180° centigrade and can be increased up to 240° centigrade. The timer function can be used in this mode.
Heat Milk mode: This mode is recommended only for heating milk since the Induction Cooktop will warm the milk with small heat power. The default time set is 15 minutes.
Keep Warm mode: This mode lets you keep the food warm till you need to serve the cooked food, since the Induction Cooktop will warm the food with small heat power, the food will remain fresh for a long time. The default time set is 120 minutes which is adjustable
Saute mode: This mode is suitable for all kinds of sauteing. In this mode you can increase or decrease the power by using the ”+” or “-“ buttons according to the food and your desired style of cooking. It will start default at 1100 watts and can be increased up to 1600 watts. The timer function can be used in this mode.

“Pause” Mode: Press the “Pause” button to stop a program at any point in time without disturbing the set program/timer. To resume the program, please press the “Pause” button once again.

SELECTION OF VESSELS

The product has the function of automatic vessel detection. In general condition, iron or stainless steel products with magnetic bases and diameter between 12 cm and 26 cm and flat base vessels will have bthe est cooking effect. Prestige recommends using Prestige Omega Deluxe and Omega Die-cast Plus non-stick induction base cookware. The Prestige range of Deluxe Plus Aluminium, Deluxe Plus stainless steel and Nakshatra Plus cookers with induction base will work efficiently with Prestige Induction Cook-tops.
The other suitable vessels are:

Pots or vessels not applicable
Pots or vessels made of ceramic, aluminum, copper,, or heat-resistant glass; compound base pots mainly made of aluminum copper (e.g. aluminum compound base pots) as well as those with base diameter less than 12cm or over 26cm

BENEFITS OF PRESTIGE INDUCTION COOK-TOP

The Prestige Induction cook-top offers quick and consistent heating at the highest efficiency. It has been thoughtfully designed with Indian menu options like Idly, Dosa, Chapati, Curry, Pressure Cook, etc. to suit your cooking methods. Now making your favourite Indian dishes has become a lot simpler. Add to this its anti-magnetic wall, soft touch buttons, durability, safety,, and elegance, making your cooking experience more pleasing and enjoyable.

Antimagnetic wall : Ensures that the black glass panel heats only in the center while keeping the remaining surface cool.
Concealed/Feather touch buttons : Prevents entry of water inside the appliance.
High/Low Voltage Protection: The appliance will cease to function under low and high voltages.
Power Saver technology: The unique power saver technology of the Induction Cooktop dynamically monitors the temperature of the vessel and adjusts the power level based on the size (base diameter) of the vessel.
Extended cooling system : The extended cooling system allows the fan to work after the appliance is switched “OFF” thereby enabling the appliance to cool down quickly. For this operation, do not switch off the Induction Cooktop from the mains up to 5-10 minutes after usage.
Automatic Switch Off : The appliance will automatically switch off if it is left ‘ON’ without attention for a long time.

Setup Guide

Follow these steps to operate, assemble, and configure the Prestige Induction Cooktop PIC 16.0:

Place the cooktop on a stable, level surface
Connect the cooktop to a 120V electrical outlet
Clean the glass surface with a soft, damp cloth
Place the desired cookware on the induction zone
Select the desired cooking preset or adjust the temperature using the control panel
Use the timer function for convenience and safety
Activate the child lock for added safety

MAINTENANCE & CLEANING

Please switch off the power and remove the plug from the wall outlet.
Before cleaning, make sure that the appliance is cool. Do not clean the appliance when it is hot. Clean the cooktop and the control panel with a damp cloth.
Do not wash the Induction Cooktop in running water. Do not immerse the induction cooktop in water.
To clean the black glass panel, first wipe it with a of wet cloth. Then wipe it with a sponge using mild detergent and finally wipe it to dry with a soft cloth.

IMPORTANT SAFEGUARDS

While using the Prestige Induction Cook-top, the following basic precautions should always be followed:

Read all instructions.
Before using the Induction Cooktop, please check that the mains voltage corresponds to the one shown on the appliance’s specification sticker.
Do not use the Induction Cooktop and other large-power electric appliances at the same time from the same power source.
To protect against fire, electric shock and injury to persons do not immerse Cooktop, cord, plug plug-in or other liquid.
Please keep the Induction Cooktop away from children. Close supervision is necessary when the appliance is being used with children around.
Do not leave the appliance in operation unattended.
Do not use the cooktop in high high-temperature environment.
The water-retaining at the bottom of the vessel must be removed before use. Else the boiled water drops may splash and scald the user when the bottom of the vessel is heated.
Please ensure proper ventilation while the appliance is in operation.
The induction cooktop is provided with an Extended Cooling System for the safety of the components. So, please DO NOT switch off the induction cooktop from the mains till the fan is completely switched off.
Do not place paper or cloth etc. between the cooktop and the vessel to prevent the risk of flame.
Do not place paper or cloth etc. beneath the cooktop to prevent the risk of overheating and malfunctioning.
Remove the plug from the mains before cleaning and when not in use. Once cooking is completed, allow the appliance to cool down completely before moving it or before cleaning.
Do not operate the appliance with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. Return the appliance to the nearest Regional Service Centre or Authorised Service Centre for examination, repair,, or adjustment.
Place the appliance on a flat surface. Do not let the power cord hang over the edge of the table or counter or touch any hot surface.
Do not place the appliance on any hot surface or near a fire or another electrical appliance or near a hot gas stove.
To disconnect, remove the plug from the wall outlet. Always hold the plug. Never pull the cord.
Do not heat the empty vessel. If the cooked food is burnt, do not remove the vessel immediately. Switch off the power, allow the vessel to cool,, and then remove it.
Do not move the Induction Cooktop with the vessel on top of it.
If the black glass panel is broken, do not use the appliance. Take it to your nearest our Regional Service Centre or Authorised Service Centre immediately.
Please do not try to open or repair the Induction Cooktop by yourself. In case of any problem, contact our Regional Service Centre or Authorised Service Centre immediately.
If the appliance malfunctions, do not operate the appliance. Contact the our Regional Service Centre or Authorised Service Centre immediately.
Do not clean the appliance with water immediately after cooking, as the cooktop will be hot and the glass panel may break.
This Induction Cooktop is for domestic use only.

Induction Cooktops work on the principle of heating magnetic field induction vortex.

The magnetic field will be generated when the current passes through the loop. When the line of magnetic force goes through the bottom of iron vessels, numerous small vortexes will be generated, making the vessel heat quickly by itself to attain the objective of cooking food.


UNIQUE FEATURE OF PRESTIGE INDUCTION COOK-TOP (ANTI-MAGNETIC WALL)
Prestige Anti-magnetic Wall Induction Cook-top can effectively block off the surplus magnetic energy dissipated in the course or transition from magnetic energy to heat energy, and can reflect back partial usable magnetic energy and re-change it into heat energy, which may sharply reduce magnetic radiation’s influence on the surrounding.


TROUBLESHOOTING

Symptom	Reason	Action
No Beep Sound when the power is switched on. No display at the display panel.	Thepower cord is not pluggedproperly.	Plug the power cord into the mains properly. If the appliance is still not working, contact the authorised service facility for repair.
Induction Cook-top stops working after consecutive short beep sounds.	Thevessel is not suitable.	Ensure the vessel placedis one with induction base and has a base diameter of larger than 12 cm.
	Vessel is not placed in the centerof the glass panel.	Place the vesselproperly in the centre circle of the glass panel.
The heating stops abruptly when working.	Temperature around theappliance is very high.	Please ensure that there is sufficient air ventilation in the room.
The heating stops abruptly when working.	Set temperature is reached. Once the set temperature is reached, the protection device will switch off the power.	If the foodis not cooked, reset the temperature and start again.
Vessel is not getting heated up to required temperature/setting.	The bottom of the vessel is concave/ convex and not flat.	Useonly flat bottom vessel.

ERROR CODES

Error Code

Description

Action

Protection againsthigh-temperature in the cook top

The unitexperiences a hightemperature. The Induction cook topwill resume afterthe temperature drops.Please press “ON / OFF” button for resuming operation.

E3 EA

Protection againsthigh-temperature in the glass Panel

This error will protect the induction cook top against high temperature on the glass panel.
The Induction cook top will resume after the temperature drops. Please press “ON / OFF” button for resuming operation.

E1 E2 E4 E5

Protection against abnormality of internal sensor inside the induction cook top

When the ambient temperature is too low, the induction cook top will perform automatic protection. Restart by pressing “On / OFF” button to resume the operation.

WARRANTY CARD

This warranty for the product is valid for a period of one year (1 year) against manufacturing defects from the date of original purchase, Your Prestige Induction Cook-top comes with a one-year warranty. Please ensure that you post/mail your Customer Response card within 7 days from the date of purchase to enable us to register your purchase.

The Company shall not be held liable for any accident, loss or damage (direct or indirect) to person or property caused by reason of:

Repairs/service attended by an unauthorized service person.
Overloading/misuse/abuse or/and negligence on the part of the person.

Pros & Cons

Pros

Pro: Precise temperature control
Pro: Efficient energy use
Pro: Safety features (anti-magnetic wall, child lock)
Pro: Easy to clean

Cons

Con: Requires induction-compatible cookware
Con: May not be suitable for all cooking styles or recipes
