Introduction of OKP Robotic Vacuum Cleaner K7

The OKP Robotic Vacuum Cleaner K7 is a powerful and intelligent cleaning device designed to make your life easier. With its advanced technology and sleek design, the K7 is perfect for cleaning various surfaces, including hardwood, tile, and carpet. The estimated price of the OKP Robotic Vacuum Cleaner K7 is around $300, and it is now available for purchase.

Detailed Specifications

The OKP Robotic Vacuum Cleaner K7 comes with the following key features:

4 cleaning modes: auto, spot, edge, and manual
Up to 120 minutes of runtime on a single charge
High-efficiency filtration system that captures 99% of dust, allergens, and pet hair
Smart app control and voice control with Amazon Alexa and Google Assistant
Anti-collision and anti-drop sensors to prevent damage to the device and furniture
45db quiet operation
Automatic recharge and resume function
Easy-to-empty dustbin and washable filter
Suction power of 1800Pa
App control with real-time tracking and scheduling

OKP Description

The OKP Robotic Vacuum Cleaner K7 is a versatile and efficient cleaning device that can handle various cleaning tasks. With its four cleaning modes, you can customize the cleaning process to suit your needs. The K7 is perfect for cleaning hardwood, tile, and carpet, and its high-efficiency filtration system ensures that your home is free from dust, allergens, and pet hair. The K7 also comes with smart app control and voice control with Amazon Alexa and Google Assistant, making it easy to operate and schedule cleaning sessions. The device is also equipped with anti-collision and anti-drop sensors to prevent damage to the device and furniture. With its automatic recharge and resume function, the K7 ensures that your home is always clean, even when you're not around.

OKP Robotic Vacuum Cleaner K7 Indicator Light

Lighting Eﬀects

Master Status	AUTO Display Status	WiFi Display Status
Charging	pink light / blue light breathing	As per current net working status
Finished Charging	Blue lights goes oﬀ	As per current net working status
When the machine fails	Red light ﬂashes or lights up	As per current net working status
Low Battery	Red light is always on	As per current net working status
Cleaning Mode	Blue light is always on	As per current net working status
Before starting distribution network	Blue light is always on	Blue light ﬂashes
Distribution process/ Loss of signal reconnection	Blue light is always on	Exit the distribution network after 5 minutes, the blue light is oﬀ
Connect to Wi- Fi	Blue light is always on	Blue light is always on

Common alarm tips

When the robot failure, the Start/Pause button light flashes in red and the buzzer sounds of different lengths will be emitted. Refer to the following table to check the cause of the fault:

Glows a continuous Red

No.

Cause of Issue

Beep

Solutions

Front infrared Anti- collision bumper

1 beep

3 times

The bumper is abnormal. Please check if the infrared buﬀer bumper is stuck.

Anti-Drop sensor

beep
times

The ROBOT is suspended, please move to the ground

Out of Trouble

3 beep

3 times

the ROBOT fail to get out of trouble, please move to the open space

Low battery

4 beep

3 times

the battery is too low, please charge

Adapter Exception

5 beep

3 times

the charging voltage is abnormal, please replace the adapter.

Abnormal charging status

6 beep

3 times

Charging is abnormal, please check if the switch is turned on.

Flashes Red

No.

Cause of Issue

Beep

Solutions

Front infrared Anti- collision bumper

1 beep

3 times

The bumper is abnormal. Please check if the infrared buﬀer bumper is stuck.

Anti-Drop sensor

beep
times

The ROBOT is suspended, please move to the ground

Out of Trouble

3 beep

3 times

the ROBOT fail to get out of trouble, please move to the open space

Low battery

4 beep

3 times

the battery is too low, please charge

Adapter Exception

5 beep

3 times

the charging voltage is abnormal, please replace the adapter.

Abnormal charging status

6 beep

3 times

Charging is abnormal, please check if the switch is turned on.

Tips: if the above method does not solve the problem, please try the following: re- open the power switch on the side of the robot to restart the machine.

Setup Guide

Setting up the OKP Robotic Vacuum Cleaner K7 is easy and straightforward. Here are the steps to follow:

Charge the device for at least 4 hours before the first use.
Install the OKP Home app on your smartphone and create an account.
Connect the device to your Wi-Fi network using the app.
Place the device on the charging dock when not in use.
Use the app to schedule cleaning sessions or start a manual cleaning session.

Maintenance

Dust Bin and Filters

When cleaning and maintaining the robot and its accessories, turn oﬀ the robot and unplug the Charging dock.

Remove the dustbin, open the dustbin cover, and empty the Dust Bin.
Remove dust filter. HEPA is not recommended for washing. Pat the High Eﬀ iciency Filter clean.
Flush the Dustbin and the ﬁlter net.
Dry the Sponge filter, Dust Bin and Filter Net completely before reinstalling.

Roller Brush and Side Brushes

Cleaning Roller Brush
- Turn the robot over. Push both buttons on the Roller Brush Cover and remove it. Remove the Roller Brush.Use the Multi-Function Cleaning Tool to cut oﬀ and remove any hair tangled around the Roller Brush.
Cleaning the Side Brushes
- Remove the Side Brushes. Wipe the Side Brushes and their slots with a dry cloth.
Use the Multi-Function
- Cleaning Tool to cut oﬀ and remove any hair tangled around the Universal Wheel.
Clean the driving wheel to maintain it's eﬀectiveness.

Other Components

Clean the anti-collision sensor panel.
Wipe the Anti-Drop Sensors with the brush or the felt side of the Multi-Function Cleaning Tool to maintain their eﬀectiveness.
Wipe the Charging Contacts and Charging Dock Pins with the brush of the Multi-Function Cleaning Tool or a dry clean cloth to maintain their eﬀectiveness.

*If you do not use this product for a long time, please take out the battery and keep it properly. If the battery leaks, remove the battery, And wipe the battery cell clean. This product has a Long life battery and does not need to be replaced frequently. If you need to replace it, you can contact our after- sales service for replacement.

OKP Robotic Vacuum Cleaner K7 Troubleshooting

Please use this chart to troubleshoot common problems using robot.

No	Malfunction	Possible Causes	Solutions
01	Cannot connect to WIFI.	Incorrect WIFI name or password.	Ensure the WIFI name and password are entered correctly.
		Robot is not in network pairing mode.	Make sure the robot is in network pairing mode.
		Didn't connect to 2.4G Wi-Fi signal.	Connect to 2.4G WiFi signal, as the robot isn't compatible with 5G WiFi.
		Downloaded the incorrect APP.	Scan the QR code in the user manual or search “OKP life" on Google Play or App Store.
02	The robot is too noisy.	Side brush, rolling brush, dustbin filter blocked, etc.	Clean and maintain the brush, roller brush, dustbin, and filters regularly. Change the suction power mode to Medium or Low.
03	Robot will not charge.	Robot has not made a connection with the charging dock.	Ensure the robot's charging contacts have made a connection with the charging dock pins.
		Charging dock is unplugged while robot is powered ON.	Plug in the charging dock and ensure the robot is powered ON. Keep the robot on the charging dock at all times.
04	Robot gets into trouble while working and stops.	The robot is entangled or obstructed by wires on the ground, drape curtains, or carpet edges.	Robot will try various ways to get itself out of trouble. If unsuccessful, manually remove the obstacles and restart.
		Side brush or roller brush is stuck.	Remove the debris tangled around the side brush or roller brush. Contact customer service if the issue persists.
05	Robot returns to the charging dock before it finishes cleaning.	Low battery power.	This is normal. No solution necessary. The working time varies according to floor surface and room complexity.
06	Robot will not clean automatically at scheduled time.	Time scheduling function is cancelled.	Turn on the power switch of the robot, reconnect the network and check the scheduled settings in the app.
		Robot is powered OFF.	Power on the robot and make the schedule using the remote control over again.
		Robot's battery is low.	Keep the robot powered ON and on the charging dock to ensure it has a full battery.
07	Remote control failure.	The batteries in the remote control need to be replaced.	Replace the battery with a new one and install it properly.
		Infrared signal is blocked or dirty.	Clean the infrared emitter on the remote control and the infrared receiver on the robot with a dry cloth.
		Interference from other equipment using infrared signals.	Avoid using the remote control near other equipment using infrared signals.

Technical Parameters

Product Model	K7
Vacuum CleanerRating	19V,0.6A
Changing Dock Rating	19V,0.6A
AC adapter model	AD-0121900060US
AC adapterrating	lnput：100-240V~50-60Hz；0,5A Output:DC 19V;0,6A;Class II;

Pros & Cons

Pros

Powerful suction and efficient cleaning
Smart app control and voice control
Long runtime and automatic recharge
High-efficiency filtration system
Anti-collision and anti-drop sensors

Cons

May have difficulty with high-pile carpet
May not pick up larger debris
App may be glitchy at times

Customer Reviews about OKP Robotic Vacuum Cleaner K7

Customers love the OKP Robotic Vacuum Cleaner K7 for its powerful suction, efficient cleaning, and smart app control. They also appreciate the long runtime and automatic recharge function, which ensures that the device is always ready to clean. However, some customers have reported issues with the app's performance and the device's ability to pick up larger debris.
