Vevor XRJ3LX3 Slush Frozen Drink Machine

Introducing the Slushies and other frozen beverages can be made with the help of the Vevor XRJ3LX3 Slush Frozen Drink Machine, which is a commercial-grade appliance created specifically for this purpose. The fact that it has three tanks that are each 15 liters in capacity makes it possible to produce multiple flavors at the same time. Because of its sturdy structure, user-friendly controls, and effective chilling system, it is an excellent choice for usage in establishments such as restaurants, bars, and other establishments that require the manufacture of frozen drinks in large quantities.

Detailed Specifications

The Vevor Slush Frozen Drink Machine boasts several impressive features that make it stand out from its competitors. It has a capacity of 3L, allowing you to make multiple servings of your favorite frozen drinks at once. The machine is also equipped with a high-powered motor that can crush ice in seconds, ensuring that your drinks are always smooth and refreshing. Additionally, the machine has an adjustable stainless steel blade that allows you to control the consistency of your drinks, whether you like them fine or chunky.

Usage

This machine is specially used for makings lush. If used to make plate dairy and other foods, bowl material temperature needs to be tested and abide by the machine’ current regulation and 1.20perator standard

Main Component

1. Bowl roof

2. Bowl

3. Control panel

4. Water tray

5. Water tray cover

6. 6 Drain hose

7. Tap

8. Handle

9. Machine foot

Fig1

In this manual the items mean as below

• XRJ3LX1, one-bowl slush machine

• XRJ3LX2, two-bowl slush machine

• XRJ3LX3, three-bowl slush machine

Technical data

Remarks: Capacity and weight are approximate number

Manufactory has right to change and will not notice specially

Fig2

Any change or increase has to be approved and executed by Manufactory..

Control panel

Fig 3

• Switch on/off

• Bowl Button

• Display screen

• Slush hardness

• Slush softness

• Light

• Shift
  Slush system/cleaning system/Standby system )

Safety manual

• Slush machine parts and condenser’ s installation, slush machine troubleshooting. exclusion and maintenance have to be operated by manufacturer professionals or people who have related experience. Without experienced people monitoring or guiding, slush machine can not be used by disabled, sense disable, mental disable people’s, lack of experience and knowledge

• Children need to be taken care when playing nearby the machine.

• When machine’s vire broken, they have to be replaced by manufacturer professionals or people who have related experience.

• When machine scraped, it has to be delivered and handled by related authority institution

Transportation and storage

Packing

Carton box, contoured foam & collect. Packing size (approximate)

Remarks: packing size and weight are approximate.

Transportation
keep upward and carried by two people at least.

Storage
Notice please do not exceed three layers.

Fig 5

Vevor XRJ3LX3 Slush Frozen Drink Machine Installation

The slush machine has to be installed indoor with hard and plain ground under enough light and ventilation (Ground inclination can’t be more than 2 degree)

Parts list

After cleaning and disinfecting allindicated parts in manual have to be coated with lubricating oil.

Position to install

• Installation position have to planed in advance;

• Installation place have to be hard and plain

• Installation condition is enough ight and ventilation and clean;

• Power sacket is also needed;

• Installation distance from other objects see below fig6

Handling package material

Handling packing material separately under local rules and we suggest keep itto repack and ship in future.

Connect power

• Ensure slush machine s off before connecting power.

• Then plugin to connect power.

• Data can be referred from machine back nameplate.
  Warning: Socket has to be placed within user touching distance in order to unplug quickly when emergency without using other tools,

Description

The Vevor Slush Frozen Drink Machine is not only functional but also stylish. Its compact design makes it easy to store in your kitchen or bar area, while its modern and sleek appearance adds a touch of elegance to any space. The machine is made of high-quality materials, ensuring that it's durable and long-lasting. It's also easy to clean and maintain, making it a convenient addition to your home appliance collection.

Operation

Preparing material and stirring evenly

Only water is prohibited

Fig7

Attention
Operate under manufactory direction; Dilute 2nd sir concentrated liquor with water in 2 container Mixture sugar content should be within 10%-15% lower content will damage the augers and gear motors

Remove the lid as below steps

1. Lift the top lid;

2. Pour the material into bowls
   Warning: Hot liquid can not be put infhot liquid means degree exceed 25°C) Material level can not exceed maximum height level

3. Close the top lid after pouring the material

Warning :Before connecting power or starting machine, putmaterial into bowl Material can not just be water.

Warning  Banning putting hand in bow| when machine is working,

Starting a 1-BOWL SLUSH MACHINE

The following controls are on the panel:

• A Main switch It is used to switch on/off the power supply to the whole machine.

• B. Light Switch  It is used to switch on/off the light is used to shift 3 different modes. display shows SLS that is used to

• C SET switch  It Press Slush Mode.

  • Press  display shows CLR that is used to switch on Cleaning Mode.

  • Press once  more, display shows OFF that is used to switch off Mixing.

• D. Slush hardness and Slush softness They are used to adjust slush thickness, in slush model, display shows SLS, then press to increase or  reduce the slush thickness

Starting a 2-BOWL SLUSH MACHINE

The following controls are on the panel:

• A Main switch It is used to switch on/off the power supply to the whole machine.

• B. Light Switch   . It is used to switch on/off the light

• C switch  It is used to shift 3 different modes Firstly Press corresponding bowl1 [ webworm, then press display shows SLS that is used to switch on Slush Mode. Press again, display shows CLR that is used to switch on Cleaning Mode. Press once more, display shows OFF that is used to switch off Mixing

• D. Slush hardness and Slush softness Switch: They are used to adjust slush thickness, in slush model, press corresponding  Bowl1 or Bowl2  then press  up or down  to increase or reduce the slush thickness

Starting a 3-BOWL SLUSH MACHINE
“The following controls are on the panel:

• A Main switch Itis used to switch on/off the power supply to the whole machine.

• B. Light Switch .  It is used to switch on/off the light

• C. SET switch :it is used to shift 3 different modes. Firstly press corresponding bowl1  Bow bowl2  Bowl or bowl3 Bowl then press display shows SLS that is used to switch on Slush Mode. Press again, display shows CLR that is used to switch on Cleaning Mode. Press once more, display shows OFF that is used to switch off Mixing.

• D. Slush hardness and Slush softness Switch They are used to adjust slush thickness, in slush model, press corresponding  bowl1 Bowl2  Bowl bow3  ,then press , bowl2 Bowl or up or down to increase or reduce the slush thickness.

Dispensing slush
Pull down the handle and slush will outflow from the bowl

Attention; if distribute slush first time or after long A stop please extrude and waste 2 title  and then distribute customers.

Attention: Material temperature in bowl needs to be tested with Standard thermometer timely to ensure: material temperature is lower than storing temperature. Power can not be cut off when machine is working or there are materal.

Emergency
Warning: When emergency, machine needs to be tumed off by power button and cut off power

If frozen, cut off power and ask for specialized people to handie. If fire, clear nearby area and ask for professionals.

Cleaning and maintenance

Before cleaning or maintaining external parts, please ensure main switch s off and unplug

Any cleaning or maintaining protection supplies needs to wear (gloves. glasses an so.an) based on local safety standard

• When cleaning or maintaining. operate as below.

• Wear protective gloves against an accident

• Do not use solvent or flammable substance

• Do not use tough or metal sponge to clean machine or parts

• Do not spray liquid to nearby area.

• Do not wash parts in the bow.

• Do ot dry parts in furnace or microwave oven

• Do notimmerse the machine in water

• Do ot spray the water to the machine directly

• Warm water and approximate cleaner can be used (abiding by local law and rules) –

• After finishing, make sure that all protective covers and guards that have been removed or opened and sent back in place and property secured,

Cleanliness and hygiene have to be taken carefully and forcibly based on local standard to ensure qualified slush

ATTENTION: Bowl needs to be cleaned everyday at least and abiding by local laws and regulations And cleaning times may be ‘added based on different products More information, please consult manufactories. if machine will not be used one day continuously please clean distributing taps with clean rag.

Even though machine’ s components stainless steel, plastic and rubber are easy to clean as well s its shape, it i sill necessary to prevent germs and fungi reproduction due to halfway cleaning When the plug is not pulled out or the total switch is in the open state. do ot clean or maintenance the machine.

Empty Bowl
Before cleaning bowl, empty bowl Hi tis the first time to use, no need to make it empty ‘This manual just explains one bowl as sample Other bourls’ operations are the same based on related their buttons Please set the bow to *clean state”, then pour material from bowl.

Fig8

Disassembling the dispensing

• Before removing the bow, it is recommend to disassemble the tap, after cleaning,, the tap must not be reapplied Until the bow has. been correctly positioned iniids seat.

• Remove fastener with 2 screwdriver, then disconnect the dispensing handle by pushing upward, then push the piston and spring downward, remove the O-ring.

• Put all spare parts in lukewarm water water  temperature around 50°C) and clean s fig. 9



• Do not disassemble taps when there are products or liquid in bowls.

Move out bowl and cover

Move out every bowl to clean the machine. Move out the bow as below steps:
Lift the top cover upward and take it out. Pull the tank upward ‘and outward to completely

1. remove it from i seat.

2. crewing off the nut

3. Take out the stirrer and the seal of stirrer

fig10

Clean and disinfect parts

• All dismantled parts should be cleaned thoroughly
  Importance: Cleaning way has to abice by local current hygiene standard..

• Pour water in the container. mix sanitizer with water (Add 296 sodium hypochlorite to water)

• ‘Sponge with sanitizer clean bow, cover and evaporator thoroughly clean with water thoroughly Add sanitizer to another container.

• Put dismantled parts in sanitizer 30 minutes Re clean with water thoroughly Make the parts dry.

• Assemble machine under 7.Sinstruction, ‘Sponge with sanitizer clean the roof and the parts touching the raw material.

fig11


Retain 30 minutes
Clean bottom surface with water 2.3 times by the sponge. Put the cover at clean area and dry it by rag Ban cleaning by water or disinfecting before taking away the cover

Reset cleaned parts
All disinfected parts have to be reassembled carefully some parts need to be lubricated to work normally. Put gasket(A) on stirrer. see Fig 12

Importance: Check gasket n regular if broken. Please replace new one. Replace gasket(A)  once at least one year

• Using the Vaseline provided, lubricate the seal A) see Fig 13



• Install seal (B),lubricate the entine surface with Vaseline as arrow marks see Fig 14

• Put stirrer into the tank as Fig 14



Attention: Adjust the stirrer to appropriate location.

see Fig 14

• Replace the seal ring. When the motor part leaks, you need to replace the seal ring

• Take out the motor bracket connected to the motor and then replace the head seal ring (washer of axis, seal of axis)

• When replacing. You need to ‘add some Vaseline Then install the motor bracket connected to the motor.

• Fixed the stirrer and install the cover as Fig.15



Attention: Adjust the cover to appropriate location

• Put in the gurde plate, install the cover along the direction of the slot, and keep the cover consistent with the motor seat. Install the roof as Fig 16

• Press down top roof until s jintfit in with motor base.



Install taps as below instructions as Fig.17

1. Lubricate bolt totally with vaseline.
2. Insert screw when taps are steady.

Attention: lnstall all parts under figures instructions.If not lubricate with vasel1ne welt,matenal may permeate

Clean step

Before using this machine,below deaning steps are needed:

1. Fill bowl with water fully
2. Start machine only in cleaning mode and stir for 5 minutes.
3. Stop machine and open tap to clear container.

Clean water tray

• Water tray should be emptied and cleaned everyday
  • ATTENTION: All machine water trays should be cleaned. water 1ray need to upward be emptied and cleaned. Take out water tray by Lifting
• Wash the tray and grid.separately with lukewarm water.Dry all Of the components.Fit the tray back in place and press down to secure it to the machine.Reposition the grid on top of the tray
  • ATTENTION: When machine stopped, clean by wet rag and dry the parts

Replace bulb

• Only when machine powers off and unplugged bulb can be replaced

• According to below figure, open the small back panel, replace the LED bulb, after assembled put the panel back, confirm closed well

fig19

Clean condenser

• Only professionals can clean condenser They know all operating steps well using approximate device and abide by local law and regulation strictly

• Condenser needs to be cleaned in regular.

  • Warning: Machine sharp surface may reveal after dismantling safety protection parts. Dirty condenser will weaken machine function

• Condenser can be seen after taking out safety protection parts.

• Even though only one plate (front or back or side)is not installed the machine s also banned to use. Operators are banned to clean condenser

• Protection parts need to be positioned by Screwdrivers

Cleaning condenser of one-bowl slush machine
Safety protection parts need screwdrivers to fasten and dismantle.

1. Loose side panel screw.

2. Take out side panel

3. Dismantle safety protection parts. Brush dust from condenser surface with dry brush as Fig21



After cleaning condenser, reposition safety protection parts

Cleaning condenser of two-bowl slush machine

According to the following nstructions

1. Loose 3 crews of the back plate.

2. Loose 5 screws o the side plate.

3. Take out the side panel.

Dismantle safety protection parts. Brush dust from condenser surface with dry brush as below.

Scheduled maintenance

This machine needs to be maintained by professionals in regular (at least 1 year). Regular maintenance can ensure machine and its parts in good safety state Any broken parts need to be replaced with original manufacturer When any parts of machine are malfunctioned or broken machine s banned to use. The user can not maintain the machine himself

Setup Guide

Operating the Vevor Slush Frozen Drink Machine is easy and straightforward. Simply add ice and your desired liquid (such as fruit juice, soda, or alcohol) to the machine, and let it do the rest. The machine will automatically mix and crush the ingredients to create a smooth and delicious slushie or frozen drink. You can adjust the consistency of your drink by using the adjustable stainless steel blade. It's recommended to clean the machine after each use to ensure that it stays in good condition.

Manufacturer
The manufacturer’s details are shown on the identification plate

0perator
Based on different applications. ere are two types of persons

User
In accord with Health standard people trained complete techniques, Know all to distribute slush have below ability after reading this manual Place and change slush machine

Specialized technical people
Studied this manual and trained how to install use and maintain this slush machine, When serious fault,can repair the slush machine and know this manus well, Master all information of the manual and can explain the diagrams and graphs correctly; Know important hygienic knowledge well,prevent accident occuring, know technical and safety standard Have experience to serve this kind of slush machine. Master treatment measure to emergency find separated safety device and use the machine correctly

People are banned to use the machine who da not accord with above requirement

Manual distribution
Users have to read this manual carefully before using.

Function and content
Offer vital  information of using and installing

2Who to read manual
Users and specialized technical people.

This manualis an inseparable part of the machine. Soit needs to be delivered to the purchaser when sold.

How to keep manual
Manual has to be placed nearby the machine and keep Intact and clear

Troubleshooting

Fault Codes and Solutions For Slush Machine

When the temperature sensor is not connected,”LL”is displayed
Check whether the temperature sensor is installed well. or the connecting wire is damaged or broken, replace the temperature sensor.

The temperature sensor is short-circuited and it displays “LL”
Check whether the temperature sensor is installed properly, or the connecting wires are damaged and connected together, orthe temperature measured by the temperature sensor exceeds 60°C replace the temperature sensor.

When the grid voltage is too high, the machine stops working and generates an alarm code “UH”

When the grid voltage is too low, the machine stops working and generates an alarm code “UL”

1. it is recommended that customers buy a voltage stabilizer, so that the voltage can be used within a reasonable range

2. Change the voltage alarm parameters without generating voltage alarm

   1. In the power-on state, long press the” Settings” button for 3 seconds to enter the setting menu, and the window flashes as

   2. Then click the “Settings” button, the window flashes as

   3. Then click the” Slush softness” button to set the value to 0

   4. Wait until the display does not flash, indicating that the setting is successful

The measured motor current is too high, the current channel generates an alarm and protects the shutdown ,the display code is SLS Err

1. the mixing shaft is blocked and the shutdown protection is caused, it will automatically restart after 5 minutes



2. If the motor s broken and rotates very slowly or cannot rotate, you need to replace a new



3. change the motor current alarm parameters and stop if no alarm is generated, and then check whether the motor i rotating

   1. In the working state, long press the “Setting” button for 3 seconds to enter the setting menu, the window flashes as



   2. Then click the “Setting” button, the window flashes



   3. Then click the “Setting” button, the window flashes as



   4. Then click the “slush softness” button to set the value to 0

   5. Wait until the display does not flash, indicating that the setting is successful

Intelligent electronic valve system

Electrical diagram-XRJ3LX1


Electrical diagram-XRJ3LX2


Electrical diagram-XRJ3LX3


Slush machine explosive diagram


Vevor XRJ3LX3 Slush Frozen Drink Machine Pros & Cons

Pros

• Stylish and compact design
• High-powered motor and adjustable blade
• Easy to use and clean
• Large capacity for multiple servings

Cons

• May be pricier than some other slush machines
• Limited to making only frozen drinks

Customer Reviews

Customers rave about the Vevor Slush Frozen Drink Machine, praising its sleek design, ease of use, and delicious results. The machine is perfect for making refreshing slushies and cocktails for parties and gatherings, and many customers appreciated its large capacity and adjustable blade. However, some customers noted that the machine can be loud and bulky, and that the price point is higher than some other slush machines on the market.
