Introduction

The Whirlpool Automatic Washing Machine ACE 80A is designed to make laundry day effortless and efficient. Featuring a robust build and advanced wash technology, this machine offers multiple wash programs to cater to various fabric types, ensuring optimal cleaning performance. Its user-friendly interface and energy-efficient design make it a practical choice for modern households. Priced at $499.99, the ACE 80A combines reliability and convenience, making it an essential appliance for any home.

Specifications

Know your Washing Machine

Impeller: It moves the clothes in every direction,  ensuring that the clothes rub against each other, thereby providing a better quality wash

Agipeller: All new Agipeller with five vanes will give better scrubbing action and the roll-over movement of clothes helps in achieving better wash quality.

Wash lid: Can handle 15 kg. of laundry load.

1. Water Selector:
   Use this knob to fill water in the wash tub or spin tub
2. Dirt Level Selector:
   Use this knob to set the time for Wash/Soak according to the dirt level of the clothes.
   (Less Dirty / Dirty / Very Dirty)
3. Fabric Type Selector:
   Use this knob to select the Fabric Type like Delicate, Normal or Heavy.
   3b. Fabric type selector - 5 Wash Programs
   Introducing a Special Program for tough stains and Hard Water Wash
   Stain wash
   This special program removes select stains from Heavy clothes like Cottons, etc.
   Hard Water Wash
   • We understand that water hardness may vary from region to region and if hardness is high, your will not get a good wash performance.
   • We've introduced a Unique Normal* & Stain Wash programs for Hard Water Wash. The machines adopts a different Agitronic wash profile with extended Soak giving you the best Wash Performance. Detergent Dosage as per detergent manufacturer recommendation.
4. Wash /Drain Selection :
   Use this knob to drain the water from the Wash tub.
5. Dryer:
   Use this knob to set the time for drying according to fabric type.
   Note: The images shown are only schematic representation of the machines. They do not replicate the exact model.

Lets Get Started

1. Get the machine installed by a Whirlpool technician
2. Ask for the demonstration of the machine
3. Check the Installation Report' to ensure that it is completed and sign it before the technician takes it away
4. Read the manual carefully - clarify with the technician d uring installation
5. Check the Warranty Card and understand the term of Whirlpool Offers*
6. Look for the machine number and model number written on a rectangular plate at the back of the machine and note this down on your Warranty Card . This number must be quoted every time you contact Whirl pool - that speeds up our response

The following items are included in the package. If something is missing , please contact the retail outlet / service center number.

Installation of Whirlpool Ace

ELECTRICAL CONNECTIONS

• Ensure that the earth connection in your electrical supply is proper before connecting the power cord. The socket should be of standard and independent 3 pin type of 230V, 5A connection with a separate line fuse or circuit breaker of the value 5A.
• The appliance must be earthed properly. Do not use an extension junction box as it may not be earthed properly.*
• If the power code is damaged, If must be replaced by the Whirlpool Authorised Service Person in order to avoid hazard.
• Do not install in an environment where there is a possibility of water splashing onto the machine.
  The manufacturer declines any responsibility for damage caused due to non-compliance with this caution. You are therefore advised to check that your household electricity supply is properly earthed.

INSTALLING THE MACHINE

1. Do not place in a slanting position
2. Do not place on uneven ground
3. Do not place in an unstable position
4. Keep the machine level on a Keep the machine at least solid floor to avoid excessive 10 cm away from the vibration during operation wall surface.
5. Keep the drain hose flat on the floor before starting the machine

Washing Process

1. Preparation before Wash
   Connect one end of the fill hose lo a waler lap and the other end to the Wash water inlet.
   Unhook the drain hose and place ii flat on the floor. , Plug the power cord properly into an electric socket.
   Shirt collars, cuffs, dress hem & pockets have to be pre-treated before washing, by brushing them with a pre-wash product or liquid detergent.
   Scrub Station: Now you can stand and use the flat top surface for your pre wash treatment activities.



2. Selecting the Wash Process
   Fix the Fill Hose Assembly into the 'Wash' Hole.
   Set the Drain Selector knob to 'Wash' position.



3. Loading the clothes into your machine
   Drain Selector , Hang the Wash Lid on the side wall of the Wash Tub as shown in the figure
   Check for coins/pins/sharp foreign objects before D..QJ loading the clothes into the machine.
   Drop the clothes loosely around the Agitator / Impeller, Load the clothes uniformly in the Wash Tub. Do not load the clothes on one side of the machine.



4. Adding detergent
   As per the table below, sprinkle detergent inside the tub before loading the clothes.
   1 typical cup = 35 gms.

   Water Level	Detergent quantity in cups*	Load in kg
   D	1.0	0-1.5
   L	1.5	1.5-3.0
   M	1.5	3.0-4.5
   H	2.0	4.5-6.0
   H1	2.0	>6.0

   Note: Foam overflow may occur if the detergent quantity used is more than recommended, especially with high foaming detergent

5. Filling Water
   Open the water tap and fill water in the tub to a suitable water level for the wash load.
   Ensure to replace the wash lid over the top of the tub before starting the wash.



   Adjust the Tap to reduce the water pressure:

   1. If water splash is observed.
   2. If water filling in wash tub and spin tub is observed at the same time
6. Washing your clothes
   • Before starting the Wash Timer ensure that all clothes are fully submerged in the water

   • Select a suitable Wash Program depending on the 'Fabric Type' like Delicate/ Normal/ Heavy and ‘Dirt Level’ * like Less Dirty/ Dirty/ Very Dirty.



Note: If water level selected is 'Low' use either 'Delicate' or 'Normal' wash programs.

• Soak* can be selected as an option. You can soak clothes upto a max. of 25 min. before washing.
• Turn the wash timer / dirt level selector clockwise until you reach the desired wash time position. The Wash action starts as soon as wash time is set.

Description

The Whirlpool ACE 80A is built with durability and efficiency in mind. Its robust design ensures long-lasting performance, while the advanced features like 6th Sense StainWash technology help in removing even the toughest stains. The IntelliClean system optimizes the wash cycle based on the load size and soil level, ensuring that your clothes are cleaned thoroughly without wasting water or energy. The machine also features a user-friendly interface with a digital display, making it easy to navigate through different wash cycles and settings.

Rinsing Process

A good wash is incomplete without a proper rinse. Not only does a thorough rinsing process help you to clean off minute traces of dirt, it also remove as the detergent water, which could be harmful to your precious clothes and to your skin

Note: If water level selected is 'Low' use either 'Delicate' or 'Normal' wash programs.

Note : For complete detergent removal, please rinse in the Wash Tub only.

Rinse in Wash Tub

1. Draining the detergent water
   Set the Drain Selector knob to the Drain position. It will take about three minutes for the detergent water to drain.

2. Selecting the Rinse Process
   Set the Drain Selector knob to the Wash position



3. Filling water into the washing machine
   Open the water tap and fill the tub to a suitable water level for the rinse load.
   Ensure that the clothes are fully submerged in water before start of rinse.
4. Rinsing your clothes
   For All CICE 6.5/6.8/7.0/7.2/7.5/7.8/8.0 & 8.5 Kg SupremePlus, SuperSoak, TurboDry & Stainfree models set the Dirt Level knob to 5-8 minutes. The machine will start rinsing, thereafter.
   Drain the rinse water by using Drain Selector as in point 1 above.
   Note: For complete soap removal, please rinse in the Wash tub only.
   You have the option of using the following alternate method to ensure removal of detergent

Method 2 : Rinse in Spin Tub

• Move the clothes from the wash tub to the spin tub.
• After setting the water selector to 'Spin', open water tap for 4 to 5 minutes and then set the spin timer to 5/10 minutes for effective spin shower
• The spin shower ensures a better quality rinsing of your clothes and also makes sure that the detergent is effectively removed.
• We recommend that one round of rinsing is done in the wash tub before loading the clothes into the spin basket.

Note: User Discretion is advised in selecting the rinsing method It is recommended to avoid spinning the tub, when water tap is open.
This will ensure that water reaches all fabric inside the basket, before spinning begins.

Method 3: Over flow rinse in wash tub

1. Draining the detergent water
   Set the Drain Selector to the Drain position.
   It will take about three minutes for the detergent water to drain.
2. Selecting the Rinse Process
   Set the Drain Selector to the Wash position.
3. Filling water into the washing machine
   Open the water tap and fill the tub to a suitable water level for the rinse load.
   Ensure that the clothes are fully submerged in water before start of rinse.
4. Rinsing your clothes
   For All CICE 6.5/6.8/7.0/7.2/7.5/7.8/8.0 & 8.5 Kg SupremePlus, SuperSoak, TurboDry & Stainfree models set the Dirt Level knob (Wash Timer) to 5-8 minutes. The machine will start rinsing
5. Continue the water supply throughout the cycle for a best rinse.
   Drain the rinse water by using Drain Selector as in point 1 above.

Note: This method consumes more water than the previous methods.

Setup Guide

To set up your Whirlpool ACE 80A,

1. Start by carefully unpacking the machine and ensuring all accessories are included.
2. Place the washing machine on a level surface to prevent vibration during operation.
3. Connect the water supply hoses to the machine and ensure they are securely attached.
4. Plug in the power cord and follow the on-screen instructions to configure your preferred settings.
5. Before the first use, run a test cycle without any clothes to check for any leaks or issues.

Spin Drying Process

1. Loading the clothes into spin basket
   • Open the spin tub lid.
   • Transfer the clothes to the spin basket.
   • Distribute the clothes evenly in the basket.

   • Before closing the spin lid, press the spin cap down on the clothes.



2. Closing the Lids
   First, close the inner lid and then close the spin lid.
   The machine will not spin if the spin lid is either open or not closed properly.

3. Spin Drying
   Set the dryer to the desired spin time
   Set spin time according to the table given below



Note

1. Spin drying without spin cap may cause cloth entry between spin basket and tub
2. Hang the clothes to dry immediately after spin to avoid excessive wrinkles on the fabric. Do not run spin continuously for more than 3 cycles, If spin is operated continuously for more than 3 cycles, motor thermal cut out (a safety feature) may happen resulting in non functioning of spin. If this happens, give a time gap of 25 minutes and restart the spin process.

Maintenance of your Whirlpool Washing Machine

Simple steps to up-keep your machine

Before cleaning switch off the power and disconnect power cord from the electrical outlets.

CLEANING THE BODY

• Wipe the machine with a soft cloth.
• If the machine is extremely dirty, wipe it with a cloth soaked in a solution of water and detergent. Then finally wipe the machine dry with a soft cloth.

CLEANING THE LINT FILTER

• Remove the Lint Filter as shown in figure 1.
• Reverse Bag and keep under running tap.

• First locate top side of Lint filter to Water level indicator as shown in figure 2. Then push bottom side of lint filter towards water level indicator as shown in the figure 3.



Safety Precautions

• Do not pull the cord to disconnect the plug. Hold the plug itself
• Do not use an Adaptor or an extension box to plug in your washing machine
• Do Not simply drag the Always lit or move the machine according to the wheel's direction.
• Do Not move the washing machine with load or when it is in operation.
• Do Not attempt to dismantle the washing machine
• Do Not expose the machine to direct sun light or rain
• Do Not install the machine in a damp place or bathroom
• Do Not wash or spray water over the switch or control panel Keep the machine
• Do Not put shoes or away from fire or heat utensils into the machine to wash or spin
• Do Not allow children to play with  the machine To prevent deformation of plastic parts.
• Do Not use water with a temperature greater than 50°C Make sure that the Lids Washing or Spinning
• Do Not put your Spin basket tit stops completely
• Do Not set heavy objects on the power cord
• Do Not use causitc soda or washing machine

Troubleshooting

Whirlpool Automatic Washing Machine ACE 80A Pros & Cons

Pros

• High capacity suitable for large families
• Advanced stain removal technology
• Energy-efficient with A++ rating
• User-friendly interface with digital display
• Low noise operation

Cons

• Slightly heavier and larger than some other models
• Higher upfront cost compared to basic models
• Some users may find the interface complex initially

Customer Reviews

Customers have generally praised the Whirlpool ACE 80A for its excellent cleaning performance and energy efficiency. Many have noted the ease of use and the effectiveness of the stain removal features. However, some users have mentioned that the machine is slightly larger and heavier than expected, and a few have found the interface to be complex at first.

Common Complaints

Some common complaints include issues with the installation process, particularly with leveling the machine, and occasional noise during operation. However, these issues are relatively rare and often resolved through proper setup and maintenance.

Warranty

2 YEARS COMPLETE WARRANTY FOR WASHING MACHINE
The washing machine and all parts hereof (except the top, lid assembly, control panel, window, knobs, escutcheon, cabinet, dispenser assembly, drain hose, lint filter, castors/wheels/ foot and other plastic parts) to be free from defects in material and workmanship under normal use and service. WOlL's obligation under this warranty shall be limited to repairing or providing replacement of any part (except the top, lid assembly, control panel, window, knobs, escutcheon, cabinet, dispenser assembly, drain hose, lint filter, castors/wheels/foot and other plastic parts) of the said washing machine which thus proves defective within two years from the date of original purchase and which on WOlL's examination discloses to its satisfaction to be thus defective.

3 YEARS EXTENDED WARRANTY ONLY ON WASH MOTOR** AND PRIME MOVER*** The Prime Mover*** and Wash Motor** to be free from defects in material and workmanship under normal use and service. WOlL's obligation under this warranty shall be limited to repairing or providing the replacement of Prime mover*** and/or wash motor** with another in working condition which thus proves defective within 3 years commencing immediately after the expiry of the 2 year period from the date of purchase and which on WOlL's examination discloses to its satisfaction to be thus defective. This warranty covers only motor** and prime mover*** *** Prime mover : Prime mover (Impeller/Agipeller) is a wash plate which rotates water & clothes. ** Motor : Wash motor only.

The 2 year Warranty will automatically terminate on the expiry of the warranty period of two yearsfrom date of purchase and extepded warranty on Prime Mover*** and Wash Motor** will also automatically terminate on the expiry of 3 years which commences immediately after the expiry of 2 years from the date of purchase as provided in the original invoice, even if the washing machine may not be in use for any time during the warranty period for any reason whatsoever including any technical breakdowns and the time taken for such repairs / replacements of parts and transit, whether under this warranty or otherwise shall not be excluded from the warranty period.
