Introduction of Wolo Mfg Electric Fun Horn 330

The Wolo is a playful and distinctive accessory for any 12-volt vehicle, producing a classic "OOOGAH" sound that captures attention. Designed for easy installation, this horn is powered by a heavy-duty motor and boasts a noise level of 114 decibels, ensuring it can be heard from a distance. With its retro charm and robust construction, the Wolo Fun Horn is available for approximately $29.99, making it an affordable addition to your vehicle's sound system.

Detailed Specifications

The Wolo Mfg Electric Fun Horn 330 comes with several key features that make it a standout in its category:

• Multi-Tone Sounds: Offers multiple fun and alert sounds to choose from.
• Compact Design: Lightweight and easy to install in most vehicles.
• High-Quality Construction: Durable materials ensure long-lasting performance.
• Easy Installation: Simple wiring and mounting system for quick setup.
• Volume Control: Adjustable volume to suit different driving conditions.

MOUNTING

FIG. #1

1. LOCATE AN AREA IN THE ENGINE COMPARTMENT THAT IS DRY AND SAFE FROM EXHAUST MANIFOLD HEAT.
2. The Fun Horn's open red trumpet is to be mounted facing downward. This will help prevent water and dirt from entering into the horn.
3. Drill a 1/4 inch hole at the selected mounting location. Mount using bolt and nut provided.

WIRING

Electrical Connections for a New Horn Button Switch: Fig. #2

• Connect the horns (+) terminal to12-volts positive such as, battery, alternator or accessories. Use 16-gauge or heavier wire. IMPORTANT: Always make sure that there is a 15-amp fuse used in the horn circuit to protect the vehicle, (not included).
• Connect the horns (-) terminal to the horn switch, (not included).
• Connect the horns switch’s other terminal to ground, any metal body surface that is clean of paint and rust.
• Provided in the kit is wire leads with 1/4” push-on insulated terminals, for easy connection to the FUN HORN. Installation is complete.

Electrical Connection to Vehicles Horn System TWO-(2) TERMINAL WIRING FIG. #3

Two-(2) wire systems:

• For vehicles where the factory horn wires connect to two-(2) terminals, simply transfer the wires to the FUN HORN’S terminals.
• If the wire terminals that were connected to your vehicle’s factory horn Fig 3 wires don’t connect to your new Wolo FUN HORN, wire leads with ¼” push-on insulated terminals are provided in the kit. The installation is complete and the horn is ready to be used.

IMPORTANT: Always make sure that a 15-amp fuse is used in the horn circuit to protect the vehicle. When testing the horns, if the sound doesn’t correct, reverse the wires connected to the terminals of the FUN HORN.

Electrical Connection to vehicles horn system ONE-(1) TERMINAL WIRING FIG. #4

One (1) wire systems:

• For vehicles where the factory horn wire connects to one-(1) terminal, simply transfer the wire to the FUN HORN’S positive (+) terminal.
• The FUN HORN’S negative terminal is connected to ground, any metal body bolt. A ground connection should be free of rust and paint.
• If the wire terminal that was connected to your vehicle’s factory horn wire doesn’t connect to your new Wolo FUN HORN, wire leads with Fig 4 1/4” push-on insulated terminals is provided in the kit. The installation is complete and the horn is ready to be used.

IMPORTANT: Always make sure that there is a 15-amp fuse is used in the horn circuit to protect the vehicle. When testing the horns, if the sound doesn’t correct, reverse the wires connected to the terminals of the FUN HORN.

Setup Guide

To set up the Wolo Mfg Electric Fun Horn 330, follow these steps:

1. Locate a suitable mounting spot for the horn, ensuring it is secure and protected from the elements.
2. Connect the wiring to your vehicle's electrical system, following the provided instructions for proper connection.
3. Mount the horn securely using the included hardware.
4. Test the horn to ensure it is working correctly and adjust the volume as needed.

Troubleshooting

If you encounter any issues with your Wolo Mfg Electric Fun Horn 330, here are some common problems and solutions:

• No Sound: Check wiring connections and ensure they are secure. Also, verify that the horn is properly mounted and not obstructed.
• Distorted Sound: Adjust the volume control or check for any damage to the wiring or horn itself.

Always refer to the user manual for specific instructions and warnings related to installation and operation.

WARRANTY

Wolo Manufacturing Corporation (“Wolo”) warranties to the original purchaser, for three months from the date of purchase, that this product is free from defects in workmanship and materials. If there is such a proven defect, Wolo, at its option, will either repair or replace the item free of charge, if it is returned to Wolo within three months from the date of purchase together with proof of purchase as described below. Wolo reserves the right to inspect any defect prior to settling any warranty claim by repair or replacement. This warranty is limited as above provided and Wolo will not be responsible for fire or other casualty or accident, due to neglect, abuse, abnormal use, modifications, faulty installation of this product, or natural causes.

Wolo Mfg Electric Fun Horn 330 Pros & Cons

Pros

• Multiple Sound Options: Offers a variety of fun and alert sounds to choose from.
• Easy Installation: Simple wiring and mounting system makes setup quick and easy.
• Durable Construction: High-quality materials ensure long-lasting performance.
• Adjustable Volume: Allows you to tailor the sound output to different driving conditions.

Cons

• Space Requirements: Although compact, it still requires space for installation which might be limited in some vehicles.
• Wiring Complexity: While generally easy, wiring can be complicated for those without basic electrical knowledge.

Customer Reviews

Customers have generally praised the Wolo Mfg Electric Fun Horn 330 for its ease of installation and variety of sound options. However, some have noted that the wiring process can be complex for those without prior experience. Here are a few common complaints:

• Some users have reported issues with the horn's durability over time, especially in harsh weather conditions.
• A few customers have mentioned that the volume control could be more intuitive.
