Introduction

The MSI PRO-VDH WIFI ProSeries Motherboard B550M is a feature-rich motherboard designed for AMD Ryzen processors, offering exceptional performance and stability for gamers and professionals alike. With support for DDR4 memory up to 4400MHz and PCIe 4.0 technology, it ensures fast data transfer and efficient multitasking. The integrated Wi-Fi provides seamless connectivity, while the compact micro-ATX form factor makes it suitable for various builds. Priced at approximately $129, this motherboard delivers great value for high-performance computing.

Specifications

CPU

Supports AM4 socket 3rd Gen AMD Ryzen™ processors, and future AMD Ryzen™ processors with BIOS update

Chipset

AMD B550Chipset

Memory

4x DDR4memory slots, support up to 128GB*
- Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
- Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200

/3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by

A-XMP OC MODE

▫ 1DPC 1R max speed 4400 MHZ

▫ 1DPC 2R max speed3733 MHZ

▫ 2DPC 1R max speed3866 MHZ

▫ 2DPC 2R max speed3466 MHZ

Dual channel memory architecture
Supports non-ECC UDIMM memory
Supports ECC UDIMM memory
Supports un-buffered memory

* Please refer www.msi.com formore information on compatible memory.

Expansion Slot

1x PCIe 3.0/ 4.0 x16 slot(PCI_E1)*
2x PCIe 3.0 x1 slots

*The supported specification depends on installed processor.

Onboard Graphics

1x VGA port, supports resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz*
1x DisplayPort, supports a maximumresolution of 4096x2160 @60Hz*
1x HDMI2.1 port, supports a maximum resolution of 4096x2160 @60Hz*/**
Maximum sharedmemory of 16 GB

* Available for the processor with integrated graphics.

**Graphics specifications mayvary depending on the CPU installed.

Storage

AMD B550Chipset

4x SATA 6Gb/sports
2x M.2 slots (Key M)
- M2_1 slot (from AMD processor)

▫ Supports PCIe 4.0/ 3.0 x4 *

▫ Supports SATA 6Gb/s

▫ Supports 2242/ 2260/ 2280 storage devices

M2_2 slot(from AMD B550 chipset)

▫ Supports PCIe 3.0x4

▫ Supports 2242/ 2260/ 2280 storage devices

*The supported specification depends on installed processor.

RAID

Supports RAID 0, RAID 1 and RAID10 for SATAstorage devices
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices

USB

AMD B550Chipset

3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal

USB3.2 Gen 1 5Gbps connector)

6x USB 2.0 ports(2 Type-A portson the backpanel, 4 ports through the internal USB 2.0 connectors)

AMD Processor

4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel

Audio

Realtek® ALC892/ ALC897 Codec

7.1-Channel HighDefinition Audio

LAN

1x Realtek® RTL8111HN 1Gbps LAN controller

Wireless LAN & Bluetooth®

Intel® Dual Band Wireless-AC 3168 (For B550M PRO-VDH WIFI)

Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 433 Mbps speed.
Supports Dual Mode Bluetooth® 2.1, 2.1+EDR, 3.0, 4.0, BLE, 4.2

Intel® Wi-Fi6 AX200 (ForB550M PRO-VDH WIFI6)

Supports Wi-Fi802.11 a/b/g/n/ac/ax, MU-MIMO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps
Supports Bluetooth® 5

Internal Connectors

1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
4x SATA 6Gb/sconnectors
2x M.2 slots (M-Key)
1x USB 3.2 Gen 1 5Gbps Type-Cport
1x USB 3.2 Gen 1 5Gbps connector(supports additional 2 USB 3.2 Gen 1 5Gbps ports)
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x 4-pin CPU fan connector
1x 4-pinwater-pump fan connector
3x 4-pinsystem fan connectors
1x Frontpanel audio connector
2x System panel connectors
1x Serial port connector
1x ChassisIntrusion connector
2x 4-pin RGB LED connectors
2x 3-pin RAINBOW LED connectors
1xTPM module connector
1x Clear CMOSjumper

LED Features

1x EZ LED Control switch
4x EZ Debug LED

Back Panel Connectors	1x Flash BIOS Button 1x VGA port 1x Display port 1x HDMI port 4x USB 3.2 Gen 1 5Gbps Type-Aports 1x PS/2 keyboard/ mouse combo port 2x USB 2.0 Type-A ports 1x LAN (RJ45) port 2x Wi-FiAntenna connectors 3x Audio jacks
I/OController	NUVOTON NCT6687-R Controller Chip
Hardware Monitor	CPU/ System/ Chipset temperature detection CPU/ System/ Pump fan speeddetection CPU/ System/ Pump fan speedcontrol
Form Factor	Micro-ATX FormFactor 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
BIOS Features	1x 256 Mb flash UEFI AMI BIOS ACPI 6.0, SMBIOS 2.8 Multi-language
Software	Drivers DRAGON CENTER CPU-Z MSI GAMING Google Chrome™, Google Toolbar, Google Drive Norton™ Internet Security Solution

Dragon Center Features

Mystic Light
User Scenario
Hardware Monitor
True Color
Live Update
Speed Up
Smart Tool
Super Charger

Special Features

Audio
- Audio Boost
Network
- Intel WiFi
Cooling
- Pump Fan
- Smart Fan Control
LED
- Mystic LightExtension (RAINBOW/RGB)
- EZ LED Control
- EZ DEBUG LED
Performance
- DDR4 Boost
- Core Boost
- Creator Genie
- Front USB Type-C
Protection
- PCI-E Steel Armor
Experience
- Dragon Center
- Click BIOS 5
- Flash BIOS Button

Package contents

Please check the contents of your motherboard package.

Motherboard	B550M PRO-VDHWIFI/ B550M PRO-VDHWIFI6
Cable	SATA 6G cables (2 cables/pack)	1
Accessories	Wi-Fi antenna	1
	M.2screws (3 pcs./pack)	1
	Case badge	1
	Product registration card	1
Application	Driver DVD	1
Documentation	Quick installation guide	1
Documentation	MSI components compatibility & reward program card	1

It should contain:

Important
If any of the above items are damaged or missing, please contact your retailer.

Block Diagram

Rear I/O Panel

Flash BIOS Port/ Button - Please refer to page 46 for Updating BIOS with Flash BIOS Button.

LAN Port LED Status Table

Realtek Audio Console
After Realtek Audio Console is installed. You can use it to change sound settings to get better sound experience.


Device Selection - allows you to select a audio output source to change the related options. The check sign indicates the devices as default.
Application Enhancement - the array of options will provide you a complete guidance of anticipated sound effect for both output and input device.
Main Volume - controls the volume or balance the right/left side of the speakers that you plugged in front or rear panel by adjust the bar.
Jack Status - depicts all render and capture devices currently connected with your computer.
Connector Settings - configures the connection settings.

Audio 7.1-channel Configuration
To configure 7.1-channel audio, you have to connect front audio I/O module to JAUD1 connector and follow the below steps.

Click on the Realtek Audio Console > Device advanced settings to open the dialog below.
Select Mute the rear output device, when a front headphone plugged in.
Plug your speakers to audio jacks on rear and front I/O panel. When you plug a device into an audio jack, a dialogue window will pop up asking you which device is current connected.

Important
The pictures above for reference only and may vary from the product you purchased.

Installing antennas

Screw the antennas tight to the antenna connectors as shown below.
Orient the antennas.

Overview of Components

Component Contents

Port Name	Port Type	Page
CPU_FAN1, PUMP_FAN1, SYS_FAN1~3	Fan Connectors	36
CPU_PWR1, ATX_PWR1	Power Connectors	33
DIMMA1, DIMMA2, DIMMB1, DIMMB2	DIMM Slots	28
JAUD1	Front Audio Connector	32
JBAT1	Clear CMOS(Reset BIOS) Jumper	38
JCI1	Chassis Intrusion Connector	37
JCOM1	Serial Port Connector	38
JFP1, JFP2	Front Panel Connectors	32
JRAINBOW1~2	Addressable RGB LED connectors	40
JRGB1~2	RGB LED connector	39
JTPM1	TPM Module Connector	35
JUSB1	USB 3.2 Gen1 5Gbps Type-C Connector	34
JUSB2	USB 3.2 Gen 1 5Gbps Connector	34
JUSB3~4	USB 2.0 Connectors	35
LED_SW1	EZ LED Control	41
M2_1~2	M.2 Slots (Key M)	30
PCI_E1~3	PCIe Expansion Slots	29
Processor Socket	Socket AM4	27
SATA1~4	SATA 6Gb/s Connectors	29

Description

The MSI PRO-VDH WIFI ProSeries Motherboard B550M boasts a sleek and durable design, with a black PCB and silver accents. It features a robust power delivery system, ensuring stable power to the CPU and other components. The motherboard also includes multiple fan headers for comprehensive cooling options.

The audio is enhanced with Audio Boost technology, providing clear and immersive sound. The Wi-Fi 6 and Bluetooth 5.2 ensure fast and reliable wireless connectivity. With its rich set of features and high-quality components, this motherboard is well-suited for both gamers and content creators.

AMD RAID Configuration

The following are the RAID levels supported by RAIDXpert2.

RAID 0 (Striping) breaks the data into blocks which are written to separate hard drives. Spreading the hard drive I/O load across independent channels greatly improves I/O performance.
RAID 1 (Mirroring) provides data redundancy by mirroring data between the hard drives and provides enhanced read performance.
RAID 10 (Striped RAID1 Sets) uses four hard drives to create a combination of RAID 0 and 1 by forming a RAID 0 array from two RAID 1 arrays.
Volume (JBOD) provides the ability to link-together storage from one or several disks, regardless of the size of the space on those disks. Useful in scavenging space on disks unused by other disks in the array. Does not provide performance benefits or data redundancy.
RAIDABLE (also known as RAID Ready) allows the user to add more storage space or create a redundant array after a system is installed.

RAID level comparison

	RAID 0	RAID 1	RAID 10
Minimum # drives	2	2	4
Data protection	None	Excellent	Excellent
Read performance	Excellent	OK	OK
Write performance	Excellent	Good	Good
Capacity utilization	100%	50%	50%

Important: All the information/ volumes/ pictures listed in your system might differ from the illustrations in this appendix.

Enabling RAIDXpert2 Configuration Utility

To enter the RAIDXpert2 Configuration Utility menu

Power on and press Delete key to enter BIOS Setup menu.
Press F7 to switch to Advanced mode from EZ mode.
Go to BIOS > SETTINGS > Advanced > Integrated Peripherals > SATA Mode and change setting to RAID Mode.
Go to BIOS > SETTINGS > Advanced > Windows OS Configuration > BIOS UEFI/CSM Mode and change setting to UEFI.
Press F10 to save configuration and exit, and then reboot and press Delete key to enter BIOS Setup menu.
Go to BIOS > SETTINGS > Advanced > RAIDXpert2 Configuration Utility sub-menu.

Initializing Disks

New disks and legacy disks must be initialized before they can be used to create an AMD-RAID array. Initialization writes AMD-RAID configuration information (metadata) to a disk.

Important

If a disk is part of an AMD-RAID array, the disk cannot be selected for initialization. To initial the disk anyway, delete the AMD-RAID array. Data on the disk is deleted during initialization so ensure the correct disks are chosen to initialize.
A legacy disk can contain valid data. When a legacy disk is initialized, all data on the disk is lost.

To initialize disks

As previously mentioned, enable RAIDXpert2 Configuration Utility.
Go to BIOS > SETTINGS > Advanced > RAIDXpert2 Configuration Utility > Physical Disk Management > Select Physical Disk Operations > Initialize Disk sub-menu.
Select desired disks by changing the Physical Disk setting to Enabled.
Select OK, then press Enter.
Review the warning message, if you want to proceed, select YES, then press Enter.
Initialization takes 10 to 15 seconds per disk. During initialization, a complete rescan of all channels is done automatically.

Creating Arrays

Arrays can be created after the disks are initialized.

Important

For redundant arrays, the Create process is not started until after the operating system and AMD-RAID OS drivers have been installed and the system has booted to the operating system. However, the arrays are immediately available to use for either a bootable array or a data array.
Array numbers are valid only for a given boot and might be different in the RAIDXpert2 Configuration Utility and RAIDXpert2. If a permanent label is required, use the RAIDXpert2 Web GUI Array Naming feature.
At any point in the procedure, return to a prior window by pressing ESC.
If the system is booted from an AMD-RAID bootable array, the first array in the Arrays section must be the bootable array. The system boots only from the first array in the Arrays section.

To create an array

As previously mentioned, enable RAIDXpert2 Configuration Utility.
Go to BIOS > SETTINGS > Advanced > RAIDXpert2 Configuration Utility > Array Management > Create Array sub-menu.
Select the RAID level from the Select RAID Level drop down menu.
Enter Select Physical Disks sub-menu, select member disks by changing the Physical Disk setting to Enabled.
Select Apply Changes, then press Enter to apply and go back to previous sub-menu.
Change the Select CacheTagSize, Read Cache Policy and Write Cache Policy settings according to your needs.
Select Create Array, then press Enter.

Deleting Arrays

Important

Deleting an array permanently destroys all data that is on the array. This action cannot be undone and it is very unlikely that the data can be recovered.
Do not delete the first array listed in the Arrays section, if it is the AMD-RAID bootable array. Doing this deletes the operating system and AMD-RAID files.

To delete an array

As previously mentioned, enable RAIDXpert2 Configuration Utility.
Go to BIOS > SETTINGS > Advanced > RAIDXpert2 Configuration Utility > Array Management > Delete Array sub-menu.
Select the desired array and change the setting to Enabled.
Enter Delete Array(s) sub-menu.
Review the warning message, if you want to proceed, Select Confirm and change the setting to Enabled.
Select YES then press Enter.

Setup Guide

To set up the MSI PRO-VDH WIFI ProSeries Motherboard B550M,

Start by unboxing and preparing all the components.
Mount the motherboard onto the case stand-offs and secure it with screws.
Connect the CPU, CPU cooler, and RAM to their respective slots.
Install the storage devices (HDD/SSD) into the SATA ports or M.2 slots.
Connect the power cables from the power supply unit to the motherboard.
Install the graphics card into the PCIe x16 slot if necessary.
Connect all front panel headers, USB ports, and other peripherals to their corresponding headers on the motherboard.
Boot up the system and enter the BIOS to configure settings as needed.

Installing RAID Driver

New Operating System Installation
The following details the installation of the drivers while installing operating system.

During the operating system installation, after selecting the location to install Windows click on Load driver button to install a third party RAID driver.
When prompted, insert the USB flash drive with AMD RAID Drivers and then click Browse.
- To make an AMD RAID Drivers USB flash drive. Insert the MSI Driver Disc into the optical drive. Copy all the contents in \\Storage\AMD\
Navigate to the directory containing the saved AMD RAID drivers, then click OK.
Select the (rcbottom.inf) driver, click Next.
When prompted, click OK.
Click Browse and navigate to the directory containing the saved AMD RAID drivers again, then click OK.
Select the (rcraid.inf) driver, click Next.
You have successfully installed the RAID driver, and Windows setup should continue.
Leave the disk/ USB drive in the computer until the system reboots itself. Windows setup will need to copy the files after the RAID volume is formatted, and Windows setup starts copying files.

AMD RAIDXpert2 Management Suite Installation

Set the SATA Mode to RAID Mode in BIOS
Insert the MSI Driver Disc into the optical drive.
Click the Select to choose what happens with this disc pop-up notification, then select Run DVDSetup.exe to open the installer. If you turn off the AutoPlay feature from the Windows Control Panel, you can still manually execute the DVDSetup. exe from the root path of the MSI Driver Disc.
Under the Drivers/Software tab, check the AMD RAID Drivers check-box.
Click the Install button.
When prompt you to restart, click OK button to finish.
Restart your computer and enter the Windows operating system.
Double-click the RAIDXpert2 icon to open the RAIDXpert2 Web GUI.
1. Default credentials are:
  - Username - admin
  - Password - admin
Change the credentials:
- Create new username and password
Re-log into the RAIDXpert2 Web GUI with the new credentials.

MSI PRO-VDH WIFI ProSeries Motherboard B550M Troubleshooting

Before sending the motherboard for RMA repair, try to go over troubleshooting guide first to see if your got similar symptoms as mentioned below.

The power is not on.

Connect the AC power cord to an electrical outlet securely.
Check if all ATX power connectors like ATX_PWR1, CPU_PWR1 are connected from the power supply to the motherboard?
Some power supply units have a power button on the rear side, make sure the button is turned on.
Check if the power switch cable is connected to JFP1 pin header properly.
Verify the Clear CMOS jumper JBAT1 is set to Keep DATA.
Test with another known working power supply of equal or greater wattage.

The power is on, but no signal to monitor

Connect the monitor power cord to a electrical outlet securely.
Make sure the monitor is turned on.
Select different inputs on the monitor.
If 3 long beeps are heard, remove all memory modules and try to install only one memory module in the DIMMA2 slot first and then restart the computer.
If 1 long 2 short beeps are heard, remove and reinstall the graphics card and then restart the computer.
Test with another known working graphics card.

The computer does not boot after updating the BIOS

Clear the CMOS.
Use the secondary BIOS to bootup the system (Only for motherboard with Dual BIOS)

Lost BIOS password

Clear the CMOS, but that will cause you to lose all customized settings in the BIOS.

There is no audio

Adjust the volume.
Connect the speakers/headphones to audio ports on the motherboard rear IO panel.
Remove secondary speakers/ headphones, HDMI cables, USB audio devices.
Test with another known working speaker or headphone.

There is no network

Make sure the network chipset driver has been installed.
Verify if the network cable is properly connected and make sure the LAN port LEDs are properly illuminated.
Verify your TCP/IP settings.
Restart or reset your router.
Test with another known working LAN cable.

The USB device is not working

Make sure your USB drive driver has been installed.
Verify if USB device is listed in Windows Device Manager.
Connect the USB device to other USB port on the motherboard rear IO panel.

Pros & Cons

Pros:

Robust power delivery system for stable CPU performance
High-quality audio with Audio Boost technology
Fast Wi-Fi 6 and Bluetooth 5.2 connectivity
Multiple USB ports including USB 3.2 Gen 2
Support for high-speed DDR4 memory up to 4600MHz+
RGB lighting support with Mystic Light

Cons:

No built-in USB 3.2 Gen 2x2 port
Limited number of SATA ports compared to some other models
No onboard display outputs (requires separate graphics card)
BIOS can be complex for novice users

Customer Reviews

Customers have generally praised the MSI PRO-VDH WIFI ProSeries Motherboard B550M for its stability and performance. Many have noted that it handles demanding tasks such as gaming and video editing with ease. However, some users have mentioned that the BIOS interface could be more user-friendly.

Common complaints include the lack of onboard display outputs and the limited number of SATA ports. Despite these minor drawbacks, the motherboard has received positive reviews for its overall quality and feature set.

msi Manuals

Read More

Read More

Read More

Read More
