Introducing the D-Link 1000 Mbps Unmanaged Switch DGS-1005C

The D-Link 1000 Mbps Unmanaged Switch DGS-1005C is a high-performance networking device designed to connect multiple devices together in a home or small business environment. This unmanaged switch features 5 Gigabit ports, providing fast and reliable data transfer rates of up to 1000 Mbps. With its plug-and-play design, this switch is easy to install and requires no configuration, making it an ideal choice for users seeking a simple and cost-effective networking solution. The estimated price of the DGS-1005C is around $30-$40, and it was launched in 2018.

D-Link Technical Specifications

Product Highlights

• Gigabit High-Speed Networking
  Gigabit ports allow you to connect up to five or eight devices for fast file transfers and smooth media streaming
• Intelligent Data Streaming
  QoS support enables uninterrupted VoIP calls, smooth streaming video, and quick file transfers over your network
• Energy Efficient
  Uses 802.3az Energy Efficient Ethernet to reduce power usage automatically without sacrificing performance

D-Link 1000 Mbps Features

Gigabit Connectivity

• Five (DGS-1005C) or eight (DGS-1008C) Gigabit LAN ports for high-speed wired connections
• Cable Diagnostics function notifies users of cable conditions through port LEDs
• Plug-and-play installation for convenience

Energy Efficient and Eco-Friendly

• Reduces power to a port when there is no traffic
• Optimizes power usage for a port for the length of cable connected to it
• Energy efficient design reduces heat generated and allows switch to run silently

The DGS-1005C and DGS-1008C 10/100/1000 Mbps Unmanaged Switches are economical, plug-and-play networking switch solutions for SOHO and small and medium businesses wanting to benefit from the increased bandwidth of Gigabit Ethernet. They provide five or eight 10/100/1000 Mbps ports that enable you to easily expand your network and provide a quick way to upgrade your network to fast connectivity.

Upgrade to Gigabit Networking

With data transfer speeds of up to 2000 Mbps at full duplex, these switches are ideal for quick file transfers, online gaming and smooth streaming media. They feature easy-to-access Ethernet ports with LED indicators per port to easily distinguish link status. Auto MDI/MDIX crossover makes connection a cinch; just plug in your cables and you’re ready to go.

Conserve Energy

The DGS-1005C and DGS-1008C implement 802.3az Energy Efficient Ethernet, which saves energy and reduces heat automatically without sacrificing performance or functionality. The switches can detect when a connected computer is shut down or when there is no Ethernet traffic and can automatically reduce the power used for that port, cutting power usage substantially. In addition, the switch optimizes power usage for each port for the length of cable connected to it, using only as much power as is required. Both of these features work together to help you save power automatically.

Reliable Plug and Play Installation

The DGS-1005C and DGS-1008C are Plug-and-Play devices that require no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment. 802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full, giving you a more reliable connection for all of your connected devices.

Smooth Streaming

These switches support QoS, which prioritizes network traffic so that time-sensitive data is delivered efficiently, even during bursts of high data traffic. This helps ensure an optimal experience for streaming media and VoIP calls.

Your Network Setup

Description of D-Link DGS-1005C

The D-Link 1000 Mbps Unmanaged Switch DGS-1005C is a compact and lightweight switch, measuring only 5.5 x 3.9 x 1.1 inches and weighing less than a pound. It features a sturdy metal casing that can withstand daily wear and tear, making it suitable for use in various environments. The switch supports auto-negotiation, which detects the link speed and duplex mode of the connected devices and adjusts its settings accordingly. Additionally, it features a store-and-forward transmission mode that ensures reliable data transfer while minimizing data collisions. The switch also supports IGMP snooping, which enables it to optimize multicast data transmission, making it ideal for multimedia applications.

Setup Guide

Setting up the D-Link DGS-1005C is a straightforward process that requires no technical expertise. Simply connect the switch to a power source and plug in the Ethernet cables to the switch and the devices you want to connect. The switch will automatically detect the devices and establish a connection. The LED indicators on the switch will light up to indicate the status of each port. If the LED indicator is green, it means the port is connected and operating at 1000 Mbps. If it's amber, it means the port is connected but operating at a lower speed.

D-Link 1000 Mbps Unmanaged Switch DGS-1005C Troubleshooting

If you encounter any issues with the D-Link 1000 Mbps Unmanaged Switch DGS-1005C, try the following troubleshooting steps:

• Check the LED indicators to ensure that the switch is properly connected and operating.
• Ensure that the Ethernet cables are not damaged or loose.
• Try restarting the switch and the connected devices to reset the connection.
• If the issue persists, try updating the switch's firmware to the latest version.

Pros & Cons

Pros

• High-performance networking with 1000 Mbps speeds
• Plug-and-play design with no configuration required
• Compact and sturdy metal casing
• Supports IGMP snooping for optimized multicast data transmission
• Affordable price point

Cons

• Limited to 5 ports
• No management features available
• May not be suitable for larger network environments

Customer Reviews about Switch DGS-1005C

Customers have praised the D-Link DGS-1005C for its high-performance networking capabilities and plug-and-play design. Many have noted that it is an affordable and reliable solution for small businesses and home networks. However, some have expressed disappointment that the switch only has 5 ports and lacks any management features. The most common complaint is that the switch can get hot during extended use, but this has not been a widespread issue.
