Introducing the noco Boost GB40 Battery Jump Starter: Power and Convenience on the Go

The noco Boost GB40 Battery Jump Starter is a portable and compact power bank designed to jump-start your vehicle's dead battery quickly and safely. With an estimated price range of $99 to $129 and a launching date of January 2021, this product is a must-have for every car owner. Its lightweight and compact design make it an ideal tool for everyday use, and its affordable price point makes it accessible to a wide range of consumers.

Technical Specifications

• Internal Battery: Lithium Ion
• Peak Current Rating: 1000A
• Operating Temperature: -20°C to +50°C
• Charging Temperature: 0ºC to +40ºC
• Storage Temperature: -20ºC to +50ºC (Avg Temp.)
• Micro USB (Input): 5V, 2.1A
• USB (Output): 5V, 2.1A
• Housing Protection: IP65 (w/Ports Closed)
• Cooling: Natural Convection
• Dimensions (L x W x H): 6.7 x 3.2 x 1.7 Inches
• Weight: 2.4 Pounds

How To Use

Charge the GB40

The GB40 comes partially charged out of the box and needs to be fully charged prior to use. Connect the GB40 using the included USB Charge Cable to the USB IN port and the USB car charger. It can also be recharged from any USB powered port, like an AC adapter, car charger, laptop and more. The USB IN port is rated at 2.1 Amps to ensure safe and efficient charging of the internal lithium battery. Due to FCC regulations, we recommend not to charge and discharge the unit at the same time. The time to recharge a GB40 will differ based on the discharge level and the power source used. Actual results may vary due to battery conditions.

 When recharging, the charge level of the internal battery is indicated by the Charge LEDs. The LEDs will slowly pulse 'On' and 'Off' and become solid until all four Charge LEDs are on. When the battery is fully charged, the Green 100% LED will be solid, and the 25%, 50% and 75% Charge LEDs will turn "Off". From time to time, the Green 100% LED will pulse indicating maintenance charging is occurring.

Connect to the Battery

Carefully read and understand the vehicle owner's manual on specific precautions and recommended methods for jump starting the vehicle. Make sure to determine the voltage and chemistry of the battery by referring to your battery owner's manual prior to using this product. The GB40 is for jump starting 12-volt lead-acid batteries only. Before connecting to the battery, verify that you have a 12-volt lead-acid battery. The GB40 is not suitable for any other type of battery. Identify the correct polarity of the battery terminals on the battery. The positive battery terminal is typically marked by these letters or symbol (POS,P,+). The negative battery terminal is typically marked by these letters or symbol (NEG,N,-). Do not make any connections to the carburetor, fuel lines, or thin, sheet metal parts. The below instructions are for a negative ground system (most common). If your vehicle is a positive ground system (very uncommon), follow the below instructions in reverse order.

1. Connect the battery clamps to the GB40 by connecting to the 12V OUT port.
2. Connect the positive (red) HD battery clamp to the positive (POS,P,+) battery terminal.
3. Connect the negative (black) HD battery clamp to the negative (NEG,N,-) battery terminal or vehicle chassis.
4. When disconnecting, disconnect in the reverse sequence, removing the negative first (or positive first for positive ground systems).

Jump Starting

1. Make sure all of the vehicle's power loads (headlights, radio, air conditioning, etc.) are turned off before attempting to jump start the vehicle.
2. Press the Power Button to begin jump starting. All LEDs will flash, indicating that all LEDs are properly functioning. If you are properly connected to the battery, the White Boost LED will illuminate. If the battery clamps are connected in reverse, the Red Error LED will illuminate. Reverse the connections to clear this error and then the White Boost LED will illuminate. The White Boost LED is illuminated, when the GB40 is ready to jump start your vehicle.
3. Try starting the vehicle. Most vehicles will immediately start. Some vehicles may require the GB40 to be connected for up to 30 seconds before starting. If the vehicle does not start right away, wait 20-30 seconds and try again. Do not attempt more than five (5) consecutive jump starts within a fifteen (15) minute period. Allow the GB40 to rest for fifteen (15) minutes before attempting to jump start the vehicle again.
4. Once you have started your vehicle, disconnect the battery clamps, and remove the GB40.

Low Voltage Batteries & Manual Override
The GB40 is designed to jump start 12-volt lead-acid batteries down to 2-volts. If your battery is below 2-volts, the Boost LED will be "Off". This is an indication that the GB40 can not detect a battery. If you need to jump start a battery below 2-volts there is a Manual Override feature, which allows you to force "On" the jump start function.
CAUTION: USE THIS MODE WITH EXTREME CARE. THIS MODE IS FOR 12-VOLT LEAD-ACID BATTERIES ONLY. BOTH THE SPARK PROOF AND REVERSE POLARITY PROTECTION FEATURES ARE DISABLED. PAY VERY CLOSE ATTENTION TO THE POLARITY OF THE BATTERY BEFORE USING THIS MODE. DO NOT ALLOW THE POSITIVE AND NEGATIVE BATTERY CLAMPS TO TOUCH OR CONNECT TO EACH OTHER AS THE PRODUCT WILL GENERATE SPARKS. THIS MODE USES VERY HIGH CURRENT (UP TO 1000 AMPS) THAT CAN CAUSE SPARKS AND High Heat IF NOT USED PROPERLY. IF YOU ARE UNSURE ABOUT USING THIS MODE, DO NOT ATTEMPT AND SEEK PROFESSIONAL HELP.

Interface

1. Internal Battery Level: Indicates the charge level of the internal battery.
2. Error LED: Illuminates Red if reverse polarity is detected, or blinks “On” and “Off” when the internal battery temperature is too high.
3. Power Button: Push to turn unit "On" & "Off".
4. Power LED: Illuminates White when unit is "On".
5. Boost LED: Illuminates White when Boost is active. If the unit is connected properly to a battery, the GB40 will automatically detect a battery and go into Boost mode (LED flashes White when Manual Overide feature is active).
6. Manual Override Button: To enable, push and hold for three (3) seconds. WARNING: Disables safety protection and manually forces Boost "On". Only for use when a battery is too low to be detected.
7. Light Mode Button: Toggles the ultra-bright LED light through 7 light modes: 100% > 50% > 10%  SOS > Blink > Strobe > Off.

Description

The noco Boost GB40 Battery Jump Starter is a versatile and powerful tool for jump-starting your vehicle's dead battery. Its lightweight and compact design make it easy to store in your glove box or trunk, ensuring that you're always prepared for an emergency. The GB40's UltraSafe Technology provides spark-proof connections and reverse polarity protection, ensuring safe and easy use. Its multi-function capabilities allow for charging various devices, including laptops, and its LED indicators display battery status and charging level. With its high-capacity lithium-ion battery, the GB40 provides reliable power and long life.

Warranty

NOCO warrants that this product (the "Product") will be free from defects in material and workmanship for a period of one (1) year from the date of purchase (the "Warranty Period"). For defects reported during the Warranty Period, NOCO will, at its discretion, and subject to NOCO's technical support analysis, either repair or replace defective Products. Replacement parts and products will be new or serviceably used, comparable in function and performance to the original part and warranted for the remainder of the original Warranty Period.

Setup Guide

Setting up the noco Boost GB40 Battery Jump Starter is simple and straightforward. Follow these steps to get started:

1. Charge the GB40 fully before using it for the first time.
2. Connect the GB40 to your vehicle's battery using the included jumper cables. Make sure the connections are secure and properly attached.
3. Turn on the GB40 and wait for the LED indicators to confirm a successful connection.
4. Start your vehicle's engine. If the engine doesn't start, wait a few minutes and try again.
5. Once your vehicle's engine starts, turn off the GB40 and disconnect it from the battery.

Troubleshooting

• Error LED: Solid Red
  Solution: Reverse polarity/Reverse the battery connections.
• Error LED: Blinking Red w/Cables Connected Properly
  Solution: The internal battery is too hot/ Allow the unit to cool. Bring the unit into cooler environment.
• Boost Light Does Not Come On w/Cables Connected Properly
  Solution: Connected battery is below 2-volts/ Remove all loads, and try again, or use Manual Override Mode.

Pros & Cons

Pros

• UltraSafe Technology provides safe and easy use.
• Multi-function capabilities allow for charging various devices.
• Lightweight and compact design.
• High-capacity lithium-ion battery provides reliable power and long life.

Cons

• May not work with larger engines or heavy-duty vehicles.
• May not charge some devices with high power requirements.

Customer Reviews

Customers love the noco Boost GB40 Battery Jump Starter for its convenience, power, and safety features. Many reviewers praise the GB40's compact design and easy-to-use interface. However, some reviewers note that the GB40 may not work with larger engines or heavy-duty vehicles. Overall, the GB40 is a reliable and affordable option for jump-starting your vehicle's dead battery.

Most Common Complaints

The most common complaints about the noco Boost GB40 Battery Jump Starter include its limited compatibility with larger engines and heavy-duty vehicles. Some reviewers also note that the GB40 may not charge some devices with high power requirements. However, these complaints are relatively rare and do not significantly impact the GB40's overall positive reputation. For more information visit: https://no.co/
