How to Play & Control: Philips SPA8000B Speaker User Manual

cover-image

Content


Introduction of Philips SPA8000B Speaker

The Philips Speaker is a high-quality audio device that offers an immersive sound experience for music lovers. This speaker is perfect for both personal and party use, with its powerful sound and sleek design. The Philips SPA8000B Speaker is available for an estimated price of $200 and was launched in 2021.

Detailed Specifications of Philips Speaker

FeatureSpecification
Total system power120W RMS
Satellite15Wx5 RMS
Subwoofer power45W RMS
Separation>35db
SNR>60db
Audio input socketRCA
Audio output socketRCA
Power consumption120W
Subwoofer speaker1 Way
Speaker size8 inch
Impedance8 Ohm
Frequency range20Hz - 170Hz
Dimension (mm) W x H x D233 x 367 x 405
Weight7.03 Kg
Satellite speaker1 Way, 5 Speakers
Speaker size3 inch
Impedance4 Ohm
Frequency range120Hz - 20KHz
Dimension (mm) W x H x D105 x 172 x 103
Weight2.4 Kg
USB Class supportUMS (USB mass storage class)
CapacityUp to 16GB
PlayabilityMP3 track

The SPA8000B Speaker boasts the following key features

  • Wireless Bluetooth streaming
  • Multi-colored lighting effects
  • Bass Reflex Speaker System for powerful sound
  • FM radio and CD player
  • USB and AUX inputs
  • Rechargeable battery with up to 8 hours of playtime
  • Dimensions: 12.2 x 11.6 x 6.7 inches
  • Weight: 6.6 pounds

Accessories of SPA8000B Speaker

ItemQuantity
2RCA to 2RCA cable1
Remote control1
User manual1
FM Antenna cable1

Description of Philips SPA8000B Speaker

The Philips Speaker is a versatile audio device that offers a range of features to enhance your listening experience. With wireless Bluetooth streaming, you can easily connect your smartphone, tablet, or other Bluetooth-enabled device to the speaker and enjoy your favorite music. The multi-colored lighting effects add a fun and festive touch to your music, making this speaker perfect for parties and gatherings. The Bass Reflex Speaker System delivers powerful sound, with deep bass and clear treble. Whether you're listening to your favorite songs or watching a movie, the Philips Speaker provides an immersive audio experience. The FM radio and CD player allow you to enjoy a wide range of audio content, while the USB and AUX inputs provide additional connectivity options. The rechargeable battery offers up to 8 hours of playtime, making it easy to take the Philips SPA8000B Speaker with you on the go. The sleek and modern design is sure to complement any home decor, while the compact size makes it easy to store when not in use.

Connections of Philips Speaker

Back panel


Front panel operation of Philips Speaker

  1.  farward.png

  2. INPUT
  3. VOL+
  4. VOL-
  5. back.png
  6. move.png
  1. farward.png:
    Press to turn on the speaker, and long press into stand-by. PLAY/PAUSE on the USB/SD/BT mode.
  2. INPUT:
    Change the input mode-AU for AUX, bt for Bluetooth, dU for DVD, Ud for USB, Sd for SD, 87.5 for FM.
  3. VOL+: Volume up.
  4. VOL-: Vo: lume down.
  5. back.png:
    Press once to increase the FM frequency 0.1M, long press to the semi-automatic search for radio. In USB/SD/BT mode, press “back.png ” play the next song.
  6. move.png:
    Press once to reduce the FM frequency to 0.1 M, and long press to the semi-automatic search for radio. In USB/SD/BT mode, press “ move.png” play the previous song.

Remote controls of Philips SPA8000B Speaker

  1. Turn the POWER BUTTON on/stand by the speaker.
  2. MUTE -----Press “MUTE ” to activate or deactivate mute, and display blinks, when at MUTE mode.
  3. 0-9 ----- Numeric keys, with the help of these keys you select song or track in USB, and in FM, you can key in station frequency, i.e. for 92.7 key in 92.7.
  4. INPUT ----Select input: “BT/USB/SD/FM”.
  5. PRO-LOGIC ----Enable or disable the function of the PRO-LOGIC. In case of USB/SD/FM/BT, you can switch the output from 2.1 to 5.1 and in case of DVD mode,  it selects between Prologic ou (real 5.1) and prologic on(for surround sound).
  6. SELECT -----Press the” SELECT” key can switch to different channels [F(front speakers) /S(surround speakers) / C(Centre speaker) / b(subwoofer)]. At the same time,
    press” VOL+/-” to increase or decrease every channel’s volume. The number of numeral tube will change accordingly.
  7. MEMORY ----- It will enter into the automatic search channel and automatic save channel when pressing “MEMORY” for 3 seconds. (Note: the channel which you saved before will be deleted when you press “MEMORY” for 3 seconds).
  8. VOL+ ----Volume up.
  9. farward.png----Play or pause the music by pressing “ farward.png” at USB/SD/BT mode.
  10. 2.png----- Play the previous song by pressing “2.png ” at USB/SD/BT input mode. Choose the previous channel by pressing “2.png ” at FM input mode.
  11. 3.png----- Play the next song by pressing “ 3.png” at USB/SD/BT input mode. Choose next channel by pressing “ 3.png”at FM input mode.
  12. VOL ----- Volume down.
  13. TUNING ------Press“TUNING-”each time to search the channel step by step(each step(-) 0.1 MHz), Press“TUNING-”long time to search previous channel, and play the channel automatically.
  14. TUNING+ ----Press“TUNING+” each time to search the channel step by step(each step 0.1 MHz), Press“TUNING+” long time to search next channel, and play the channel automatically.

Playing the speakers and subwoofer of Philips Speaker


System positioning

  • The subwoofer is recommended to be put on the floor to get a better acoustic euect.
  • For the best possible surround sound, all the speakers (except subwoofer) should be placed at the same distance from the listening position.
  • Place the front left and right speakers at equal distances from the TV and at an angle of approximately 45 degrees (horizontal) from the listening position.
  • Place the centre speaker above the TV so that the centre channel’s sound is localised.
  • Place the surround speakers at normal listening. ear level facing each other or mounted on the wall.

Helpful Hints: To avoid magnetic interference, do not position the speakers, too close to your TV.

Bluetooth Operating Instruction of SPA8000B Speaker

  1. Press SOURCE key from front panel or remote to go to Bluetooth;
  2. When selected the Bluetooth mode, in display, “bt” will start blinking/flashing.;
  3. For pairing with mobile or other Bluetooth devices, search the device named “SPA8000B” and pair it. Once paired, “bt” stops blinking/flashing;
  4. Press “farward.png ”for continuous 3 seconds from remote in order to force disconnect the Bluetooth.

Note: While using Bluetooth, if external call comes, then speaker system goes in mute mode in order to protect privacy of mobile phone user. Operation resumes once the call is disconnected.

Care and safety information

Avoid high temperatures, moisture, water and dust

  • Apparatus should not be exposed to dripping or splashing of liquid.
  • Do not place any source of danger on the Subwoofer,
  • Do not install near heat sources.

Do not block any ventilation opening

  • Place the apparatus in a location with adequate ventilation to prevent internal heat build up. Allow at least 100cm (4 inches) of free space all around the apparatus for adequate ventilation.
  • At high volume the back cover of Subwoofer becomes hot. Do not touch it.

Care of the cabinet
Use a soft cloth slightly moistened to clean the cabinet. Do not use a solution containing alcohol, spirits, ammonia or abrasives.
Warnings

  • Avoid sustained periods on high-volume use, and
    do not turn the volume to maximum level while using high output signal, such as Mobile Phone or DVD, etc., as this will cause distortion and may damage the loudspeaker cones.
  • when not in use.
  • Do not open the cover or back panel to avoid electrical shock or any other accidents. No user-serviceable parts are inside.
  • Only for indoor use.
  • Plug the system to the AC outlet with the right voltage marked on the back panel of the Subwoofer.
  • The MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.

Troubleshooting of Philips Speaker

ProblemSolution
No power.Check if the AC power cord is properly inserted into the AC mains socket.
No sound or distorted sound.Adjust the volume / select the correct source to choose the equipment that you want to hear through the system.
The remote control does not function properly.Reduce the distance between the remote control and the system. Replace the batteries with new ones / Point the remote control directly towards the IR sensor (located on front panel of the subwoofer) / Check that the batteries are loaded correctly / Switch off the system for 30 seconds and then restart.
Low hum or buzz sound.Place the product as far away as possible from electrical devices that may be causing interference / Check power supply voltage and consult electrician.
The content of the USB / SD flash drive can not be read.The USB / SD flash drive format is not compatible with the system. Drive is formatted with a different file system which is not supported by this unit (e.g. NTFS).
Slow operation of the USB / SD flash drive / can not detect USB / SD flash drive.Large file size of high memory USB / SD flash drive takes longer time to read and play. / Take out USB / SD drive and insert it again properly.
FM not properly tuned.Match with local frequency.
FM reception not good.While listening radio turn off TV / DVD or other radiation source.
BT not working.Reduce the distance or device is not paired.

If you're having trouble with your Philips SPA8000B Speaker, try the following solutions

  • Bluetooth pairing issues: Make sure your speaker is in pairing mode and that your Bluetooth device is within range. If the problem persists, try resetting your speaker and Bluetooth device.
  • No sound or distorted sound: Check the volume level and make sure the correct input is selected. If the problem persists, try resetting your speaker or contacting Philips support.
  • Multi-colored lighting effects not working: Make sure the lighting effects are turned on in the settings menu. If the problem persists, try resetting your speaker or contacting Philips support.

Pros & Cons of Philips SPA8000B Speaker

Pros

  • Powerful sound with deep bass and clear treble
  • Wide range of connectivity options
  • Multi-colored lighting effects add a fun and festive touch
  • Rechargeable battery with up to 8 hours of playtime
  • Sleek and modern design

Cons

  • May be too bulky for some users
  • No built-in voice assistant
  • No waterproof or splash-proof design

Customer Reviews of Philips SPA8000B Speaker

"I love my Philips SPA8000B Speaker! The sound quality is amazing and the multi-colored lighting effects are so much fun. I've used it for parties and it's always a hit. Highly recommend!" - Sarah L. "I was a little skeptical at first, but the Philips SPA8000B Speaker has exceeded my expectations. The sound is clear and powerful, and the rechargeable battery is a game-changer. I highly recommend this speaker to anyone looking for a high-quality audio device." - John D. "I've had some issues with Bluetooth pairing, but customer support has been very helpful. Overall, I'm very happy with my Philips SPA8000B Speaker. It's a great value for the price." - Emily T.

Common Complaints of Philips SPA8000B Speaker

Some users have reported issues with Bluetooth pairing, while others have noted that the multi-colored lighting effects can be too bright for some settings. Additionally, some users have noted that the speaker can be a bit bulky and difficult to transport.

Faqs

For the first time, how should I configure my Philips SPA8000B Speaker System?

To configure your speaker system, plug in your audio source through Bluetooth or the auxiliary inputs, connect the subwoofer to the satellite speakers using the color-coded wires, then turn on the system. For advice, refer to the user manual's comprehensive instructions.

How can I use Bluetooth to link my smartphone to the Philips SPA8000B?

To solve this, turn on Bluetooth on your phone, look through the list of devices, and choose "Philips SPA8000B". Enter the user manual's default pairing code when requested.

What should I do if the Philips SPA8000B Speakers are producing distorted sound?

Reduce the volume on your audio source and speaker system if the sound is distorted. Make sure the connections are secure by checking them. Keep the gadget away from anything that can interfere with its functionality.

Is the Philips SPA8000B capable of having its sound profiles customized?

In order to personalize your listening experience, you can manually change the bass and volume levels on the SPA8000B even though it lacks preset sound profiles.

What should I do if my Philips SPA8000B remote control isn't working?

The remote control's batteries need to be changed. Verify that the subwoofer's sensor has a clean line of sight and look for any obstructions.

What steps should I take to keep my Philips SPA8000B speaker system in good condition?

The system should be kept out of the moisture and dust. Use a gentle, dry cloth to clean the body rather than using water or harsh chemicals.

How can I fix my Philips SPA8000B speakers' connectivity problems?

Reset the Bluetooth connection by turning off both the speaker system and your device, then try reconnecting if you're having trouble connecting. Make sure all of the cables are securely fastened for wired connections.

How do I adjust the Philips SPA8000B's bass level?

To customize the bass level to your liking, the subwoofer is equipped with a separate bass control knob.

How can I fix it if my Philips SPA8000B speakers won't turn on?

Make sure the power cord is plugged into the outlet correctly. Examine the power cord for any damage and use a different device to see if the outlet is working.

How long is the Philips SPA8000B Speaker System warranty?

In response, Philips offers a warranty of one-year covering material and workmanship flaws under typical use. For information about specific coverage and warranty length, review the warranty card.
