Lifelong Inferno Induction Cooktop VX-LLIC10 Introduction

The Lifelong Inferno Induction Cooktop VX-LLIC10 is a high-quality and efficient cooking appliance that is perfect for modern kitchens. It has a sleek and compact design, making it a great option for those with limited counter space. The cooktop is easy to use, easy to clean, and is equipped with advanced safety features. The estimated price of the Lifelong Inferno Induction Cooktop VX-LLIC10 is around $150, and it was launched in the year 2021.

KNOW YOUR INDUCTION

ATTENTION: Before use, please check for the plug and socket are in good condition. Before positioning the pot, please clear off marks/dirt from pot surface & glass panel. Put pot at the centre& never put empty pot on glass panel.

PRODUCT FEATURES

Air Vent
Power Cord
Glass Top
Cooking area
Control panel
7 segment display

FEATURES	Inferno Induction
Reliable Tact Switch operation	Yes
Auto Detection	Yes
Auto Cool Function	Yes
Under Voltage & Over voltage protection	Yes
Anti Magnetic Glass plate	Yes
Variable Heat level for customized Indian cooking	7 levels
Intelligent preset functions	Yes
Digital Timer Display	Yes
Input Voltage Display	Yes
Electricity Reading	Yes

NOTE: DESIGNS & SPECIFICATIONS ARE SUBJECTED TO CHANGE WITHOUT PRIOR NOTICE.

COLOURS	BLUE	GREY
Rated Power (W)	2000 W	2000 W
Voltage/ Frequency	220-240 VAC / 50 Hz	220-240 VAC / 50 Hz

Detailed Specifications

The Lifelong Inferno Induction Cooktop VX-LLIC10 has the following key features:

9-inch cooking surface
10 power levels (100W-2200W)
8 temperature levels (140°F-460°F)
LED display
Timer function with auto shut-off
Child safety lock
Overheat protection
Auto-pan detection
Weight sensors

Description

With its strong and effective design, the Lifelong Inferno Induction Cooktop VX-LLIC10 is a culinary tool that makes cooking a breeze. With its 9-inch cooking surface, you can prepare a wide range of dishes with plenty of room, and its 10 power settings let you cook food to absolute perfection. The LED display offers precise and lucid information about the cooking process, and the eight temperature settings make it simple to maintain the ideal temperature for your recipes. In addition to the child safety lock and overheat prevention, the timer feature with auto shut-off guarantees that your food doesn't overcook.

Instruction

POWER & FUNCTION SELECTION

Plug in induction cooktop into power supply into supply and switch on. Short sound is heard & Mains voltage is displayed as eg U 230. This is standby mode.
Press "ON/OFF" switch and unit will switch on to "MANUAL" mode by default. Press "MENU" switch repeatedly for desired cooking options. Once desired cooking function is selected unit will start to operate on set cooking functions.

TEMPERATURE/POWER ADJUSTMENT

If, after selection of a function, to adjust power, press " + " or " - " key.
Individual function may be & limited in power adjustment because of effect on cooking.
For some functions, the induction cooktop can, during heating, control its temperature automatically based on cooking effect.

TIMER ADJUSTMENT

If no timing is conducted or there is no such function the induction cooktop will heat based on default cooking time.(for detailed time duration, refer to "Cooking mode instructions")
To adjust the cooking time press "Time/Preset" switch, after the numbers on the display screen flash, press switch to carry out the timing adjustment.
When adjustment is finished, the number on the display will be shown after blinking for 5 secs.The induction cooktop will start counting down.
After work time elapses, the cooktop will shut down automatically. To shut down ahead of time; press "ON/OFF" switch.

TEMPERATURE AND TIME CAN BE ADJUSTED

After work time elapses, the cooktop will shut down automatically. To shut down ahead of time; press "ON/OFF" switch. Preset time adjustment When the unit is connected to main supply, a short audible signal is heard and led for "ON/OFF" switch glows.
For the purpose of delay start, press "timer/preset" switch "0000" will start blinking.
Press "" or "" switch to adjust timings. Timing can be adjusted from 1Min to 23Hrs 59Min.
After the adjustment of desired timing, set timing will blink for 5sec & the time will be registered.
After the time adjustment, default manual mode is selected. To change, press desired cooking function to be used as per requirement. After the countdown time elapses the induction cooker will resume heating automatically.

Setup Guide

Follow these instructions to set up the Lifelong Inferno Induction Cooktop VX-LLIC10:

Set the stove down on a level, sturdy surface.
Turn on the stovetop by plugging it in.
Decide on the temperature and power level you want.
Put the pan on the stovetop.
As needed, use the controls to change the temperature and power.

MAINTENANCE

Clean after every use Before cleaning, disconnect Plug and wait till the cooktop cools down completely.
Clean the outside body of cooktop and the control panel with a damp cloth.
Do not wash or immerse Cooktop in water
Use clean Pots Nessels to avoid discolouration or stains on the ceramic Plate.
To Clean the ceramic plate, first wipe it with a wet cloth or sponge using water & mild detergent Finally wipe it dry with a soft damp cloth.
When not in use for a long time, please unplug the unit and protect against dust & insects.

COOKWARE KNOWLEDGE

Use the Recommended Cookware for efficient cooking.

Min Diameter of Pan/Pot - 120 mm, Max Diameter of Pan/Pot - 200 mm.
Material - Iron, SUS304,SUS430

Do not use

OPERATION FUNCTIONS

FUNCTION	PROCEDURE
MANUAL (Default Function)	When "Manual" is selected, "1600" indicating the wattage is displayed. Wattage adjustment can be done from 200W to 2000W by using M or' key. Cooking time can be adjusted from 1 min to 3Hr.Default cooking time is 2Hr.
FRY	When the "Fry" function is selected, "270°C" indicating the wattage is displayed. Temperature adjustment can be done from "60°C" to "270°C". Cooking time can be adjusted from 1 minute to 3Hr.Default cooking time is 2Hr.
ROTI/DOSA	When the "Roti/Dosa" function is selected, "200°C" indicating the temperature is displayed.Temperature adjustment can be done from "60°C" to "270°C". Cooking time can be adjusted from 1 minuteto 3Hr.Default cooking time is 2Hr.
CURRY/SABJI	When the "Curry/Sabji" function is selected, "2000" indicating the wattage is displayed. Wattage adjustment can be done from "200W" to "2000W". Cooking time can be adjusted from

	1 min to 3Hrs.Delayed timer setting can be done for 1,in to 23:59Hrs. Default cooking time is 25min continue,95min ON/OFF.
NOODLES	When the "Noodles" function is selected, "1800" indicating the wattage is displayed. Wattage adjustment can be done from "200W" to "2000W".Cooking time can be adjusted from 1 minute to 3Hrs.Default cooking time is 15min.
MILK/TEA	When the "Milk/Tea" function is selected, "1600" indicating the wattage is displayed. Wattage adjustment can be done from "200W" to "2000W".Cooking time can be adjusted from 1 min to 3Hrs.Default cooking time is 12min continue,23min ON/OFF.

TROUBLESHOOTING

SYMPTOM	ERROR
Vessel size is not suitable or no vessel	E0
Input voltage is low (125±10V)	E1
Input voltage is high (270±10V)	E2
Temperature under the glass is high	E3
IGBT temperature is high	E4
Sensor under IGBT is open / short	E5
Sensor under glass is open / short	E6

Problem	Possible cause
There is audible signal & display shows "EO" blinking	Please check if pot is kept on cooktop or Non induction compatible pot is placed or Pot is placed at centre of cooktop plate
Stops heating during use	Please check if surrounding temperature is very high. Check if the air inlet/outlet is covered. Set time/default time has lapsed.
No response from switch/key	Please check if the plug is properly plugged.
Abnormal noise during use	Please check if noise is from cooling fan.

The above are indicators of common failures. If the problem persists call customer care. Please do not disassemble the unit to avoid any danger and damage to the induction cooktop.

IMPORTANT SAFEGUARDS

Read the Instruction Manual carefully before use.
Close supervision is necessary when appliances are near children.
Operate carefully in accordance with the requirements.
Such operation is not allowed.
Be sure to operate like this.

Never have a child to operate this unit alone so as to avoid any dangers such as scalding.

A person wearing a heart pacemaker shall consult a doctor before using this product.

Avoid using great force to strike the ceramic panel as this may cause damage. In the event of damage, please stop using, and send it to a service facility for repair.

IMPORTANT SAFEGUARDS

CAUTION: Do not use this unit on a carpet, table cloth or tissue, as this may block the air entry and air vent and affect radiation caution from the cavity.
WARNING: This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. concerning use of the appliance by a person responsible for their safety.
WARNING: The adult should supervise the children in order to make surethe children can Warning not play with the appliance.
WARNING: Metal objects such as knife, fork, spoon and lid should not be placed on the surface of glass panel, because they may Warning become hot.
WARNING: This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices Warning and other working environments; -farm houses;-by clients in hotels, motels and other residential type environments; bed and breakfast-type environments.
WARNING: If the supply cord is damaged, it must be replaced by a special cord or assembly Warning available from the manufacture or its service agent.

SPECIAL ATTENTION

During and after using the induction cooktop, keep it clean. Prevent the machine from insects, dust and damp and stop black beetles from entering and causing short circuit; when not in use for a long time, it is recommended to be stored in a plastic bag after cleaning.
Never splash water or soup into the induction cooktop to prevent the circuit board from shorting.
After using, unplug the unit to avoid damage to electronic elements or even fire due to long-term on-position. After the ceramic panel cools, clean it with soft cloth dipped with little detergent rather than water.
It is recommended to use a high-power socket rather than a defective one. Do not share a socket with high-power appliances such as air conditioners and electric stoves to avoid over-current from causing fire.
Never use this induction cooktop on a table or bottom plate made of iron or stainless steel, as this may cause burning of the unit.
Because the bearing of the ceramic panel for the induction cooktop is limited, never put too heavy objects on the ceramic panel, as this may cause damage to the plastic lid and ceramic panel.
In use, never leave it unattended for a long time. If leaving is necessary, make sure that water inside the pot can prevent dry-burning due to excessively little water from damage to the pot.
Never use the induction cooktop in narrow space, and do not have foreign objects to block the air entry and air vent, as this may affect radiation.

Inferno Induction Cooktop VX-LLIC10 Pros & Cons

Pros

Easy to use and clean
Energy-efficient
Advanced safety features
Sleek and compact design

Cons

May not be compatible with all pans
May be expensive for some users

Lifelong Warranty

The manufacturer offers a 1-year guarantee with the Lifelong Inferno Induction Cooktop VX-LLIC10. Claims damaged and/or missing parts (accessories) after 7 days from the original date of goods received.

Customer Reviews

Customers love the Lifelong Inferno Induction Cooktop VX-LLIC10 for its ease of use, energy efficiency, and advanced safety features. Some common complaints include the limited compatibility with pans and the high price point. However, overall, customers are happy with their purchase and would recommend the cooktop to others.
