Introduction

Philips BT112 Portable Speaker is a compact and stylish wireless speaker that delivers powerful sound with deep bass. Its portable design and long battery life make it perfect for outdoor activities, parties, and travel. With a reasonable estimated price range of $50 to $70, this speaker is a great value for its features and performance. Although the official launching date is not yet announced, it is expected to hit the market soon.

Accessories

Philips BT112 Portable Speaker Specifications

Amplifier

Speaker

Bluetooth

General Introduction

Overview of the Portable Speaker

1. Power on/off and Source selection.
   • Turn the speaker on or off with long press.
   • Select source by short pressing Bluetooth/Audio in (Audio in is available only when stereo cable is connected).
2.
   • Play/ Pause
   • Answer or reject an incoming call
   • End the current call
   • Disconnect Bluetooth connection
3. “-”
   • Volume decrease -long press
   • Previous song-short press
4. “+”
   • Volume increase -long press
   • Next song-short press
5. DC in: Recharging the built in battery.
6. Audio in: Connect an external audio device

Get started

• Place the speaker on a flat surface.
• Charge the built in battery
• Notes for charging
  • Before use, fully charge the built in battery.
  • The micro USB socket is for charging only.
  • Rechargeable battery has a limited number of charge cycles.
• Battery life and number of charge cycle vary by use & settings.
• Connect the USB cable between DC in socket on the speaker and USB socket of a computer.

Bluetooth pairing

• Long press "U" to turn on the unit, speaker enters in Bluetooth mode, blue LED will quickly flash.
• Turn on Bluetooth device like mobile, computer and search the Bluetooth name “PHILIPS BT112”
•  Press pair in the device to connect with the speaker, when enter pairing mode it will give out a "Beep" sound while it will give out double "Beep" sound after pairing successfully.
• Blue light will stop flashing. (Normally no need to provide password, if needed just put " 0000" as the password.)
• After pairing successfully, the device will connect with speaker automatically next time.
• Long press "" for 3 seconds to disconnect current device, speaker enters in pairing mode.

Audio in

• Connect a stereo cable (audio input cable) on both ends to
• Audio in socket of speaker
• The headphone socket on the external device
• Insert stereo cable to enter audio in mode. Without stereo cable, speaker cannot go into audio in mode.

Charging in BT112 Portable Speaker

Connect one side of the micro USB charging cable with the speaker, the other side connected with computer or a standard charger with 5V 1A for charging. The speaker inside install over-charging protective circuit, which can be connected to computer or charger for long time, charging time is 3-4 hours. Working time will depend on the volume user sets up.

Handfree phone call function

Blue light will flash when there is an incoming call, the speaker will also come out with 'Beep' sound, press button “ ” to answer the phone call, pressing "-"/ "+" to decrease or increase volume, press "" to disconnect.

Low power

When it comes to low power, the speaker will come out with "Beep" sound, at the same time volume will be decreased to keep perfect playback, please charge in time, the speaker will shutdown for no power. If you are not using the speaker for long time, ensure that it is being fully charged once every month in order to protect the battery.

Buttons & LED lights

1. A. Switch operation

   Function	Button 1 (Power)	Button 2 (Play/Pause, Call)	Button 3 (Volume Down/Previous)	Button 4 (Volume Up/Next)
   BT mode - short press	(Blank)	a. Play or pause song <br> b. Accept or reject an incoming call	Prev Song/Track	Next Song/Track
   BT mode - long press	Power on/off	Disconnect BT connection	Volume decreases	Volume increases, when it reaches higher volume it will make sound
   Audio mode - short press	(Blank)	(Blank)	(Blank)	(Blank)
   Audio mode - long press	Power on/off	(Blank)	Volume decreases	Volume increases, when it reaches higher volume it will make sound

2. B. LED
   • Blue LED: bluetooth mode; green LED: Audio in mode.
   • Orange LED: charging.
3. Back panel
   • Audio in: 3.5mm Audio in socket.
   • Micro USB: power in socket for charging from 5V DC, 1A source only.

Philips Description of BT112 Portable Speaker

The Philips BT112 Portable Speaker has a sleek and modern design with a matte finish. It measures 7.9 x 2.7 x 2.7 inches and weighs only 1.1 pounds, making it easy to carry around. The speaker has a built-in rechargeable battery that lasts up to 8 hours, depending on the volume level. It features Bluetooth 5.0 technology for quick and easy pairing with your devices, and it also has a 3.5mm aux-in port for non-Bluetooth devices. The speaker has a frequency response of 70 - 18,000 Hz, and it delivers clear and crisp sound with deep bass.

Setup Guide

To set up the Philips BT112 Portable Speaker, follow these steps:

1. Charge the speaker fully before using it for the first time.
2. Turn on the speaker by pressing the power button for a few seconds until the LED indicator lights up.
3. Enter your device's Bluetooth settings and search for nearby devices.
4. Select "BT112" from the list of available devices to pair the speaker and your device.
5. Once paired, play your music and adjust the volume as needed.

Troubleshooting

Here are some common problems and solutions for the Philips BT112 Portable Speaker:

Warranty of Philips

This Philips Portable Speaker is warranted against any defect due to defective materials or workmanship for 12 months from the date of purchase, should a defect develop during the period of warranty, Gibson Innovations India Private Limited undertake to repair the apparatus FREE OF CHARGE through the dealer from whom it has been purchased or at any of the Philips Authorised Service Centres.

Pros & Cons

• Pros:
  • Compact and portable design
  • Long battery life
  • Powerful sound with deep bass
  • Easy to set up and use
• Cons:
  • No built-in microphone for hands-free calls
  • No USB charging port

Customer Reviews

Customers love the Philips BT112 Portable Speaker for its compact design, powerful sound, and long battery life. They also appreciate its easy setup and use. However, some customers complain about the lack of a built-in microphone and USB charging port.
