Introduction

The Black+Decker Hard Surface Sweeper LSW36 is a powerful, cordless cleaning tool designed for quick and efficient debris removal on various surfaces. Featuring a 40V MAX lithium-ion battery, it delivers impressive performance with a maximum air speed of 120 MPH and an airflow volume of 90 CFM. Lightweight and easy to maneuver, this sweeper is ideal for both indoor and outdoor use. The cost of the LSW36 is approximately $150, making it a practical choice for maintaining clean spaces.

Detailed Specifications

• Power Source: Rechargeable Lithium-Ion Battery
• Suction Power: 36V Motor
• Weight: Approximately 7.4 lbs
• Dustbin Capacity: 1.2 L
• Charging Time: Up to 4 Hours
• Runtime: Up to 40 Minutes
• Dimensions: 45.5 x 10.5 x 7.5 inches

The label on your tool may include the following symbols.

• V................volts
• Hz..............hertz
• min............minutes
• ...........direct current
• no...................no load speed
• ...............Class II Construction
• .............safety alert symbol
• A.....................amperes
• W....................watts
• ...................alternating current
• ....................earthing terminal
• .../min..............strokes per minute

Components

1. LSW36 Cordless Sweeper
2. On / Off Switch
3. Battery pack
4. Inner tube
5. Outer tube
6. Power Command

IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CHARGERS

This manual contains important safety instructions for battery chargers.

Before using charger, read all instructions and cautionary markings on charger, battery pack, and product using battery pack.

WARNING: Shock hazard. Do not allow any liquid to get inside charger.

WARNING: Burn hazard. To reduce the risk of injury, charge only designated Black & Decker batteries. Other types of batteries may burst causing personal injury and damage.

CAUTION: Under certain conditions, with the charger plugged in to the power supply, the charger can be shorted by foreign material. Foreign materials of a conductive nature such as, but not limited to, steel wool, aluminum foil, or any buildup of metallic particles should be kept away from charger cavities. Always unplug the charger from the power supply when there is no battery pack in the cavity. Unplug charger before attempting to clean.

WARNING:

• The charger supplied with this product is intended to be plugged in such that it is correctly orientated in a vertical or floor mount position.
• DO NOT attempt to charge the battery pack with any chargers other than the ones in this manual. The charger and battery pack are specifically designed to work together.
• These chargers are not intended for any uses other than charging designated Black & Decker rechargeable batteries. Any other uses may result in risk of fire, electric shock or electrocution.
• An extension cord must have adequate wire size (AWG or American Wire Gauge) for safety. The smaller the gauge number of the wire, the greater the capacity of the cable, that is 16 gauge has more capacity than 18 gauge. When using more than one extension to make up the total length, be sure each individual extension contains at least the minimum wire size.

Recommended Minimum Wire Size for Extension Cords

• Do not expose charger to rain or snow.
• Pull by plug rather than cord when disconnecting charger.
  • This will reduce risk of damage to electric plug and cord.
• Make sure that cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress.
• Do not use an extension cord unless it is absolutely necessary.
  • Use of improper extension cord could result in risk of fire, electric shock, or electrocution.
• Do not place any object on top of charger or place the charger on a soft surface that might block the ventilation slots and result in excessive internal heat. Place the charger in a position away from any heat source.
  • The charger is ventilated through slots in the top and the bottom of the housing.
• Do not mount charger on wall or permanently affix charger to any surface.
  • The charger is intended to use on a flat, stable surface (i.e., table top, bench top).
• Do not use with damaged cord or plug.
  • If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to a service center.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners.
  • Do not run appliance over cord. Keep cord away from heated surfaces.
• Do not operate charger with damaged cord or plug have them replaced immediately.
• Do not operate charger if it has received a sharp blow, been dropped, or otherwise damaged in any way.
  • Take it to an authorized service center.
• Do not disassemble charger;
  • take it to an authorized service center when service or repair is required. Incorrect reassembly may result in a risk of electric shock, electrocution or fire.
• Disconnect the charger from the outlet before attempting any cleaning.
  • This will reduce the risk of electric shock. Removing the battery pack will not reduce this risk.
  • NEVER attempt to connect 2 chargers together.
  • The charger is designed to operate on standard household electrical power (120 Volts). Do not attempt to use it on any other voltage.

SAVE THESE INSTRUCTIONS

Important safety instructions for battery Packs

WARNING: For safe operation, read this manual and manuals originally supplied with tool before using the charger.

The battery pack is not fully charged out of the carton. Before using the battery pack and charger, read the safety instructions below. Then follow charging procedures outlined.

READ ALL INSTRUCTIONS

• Do not incinerate the battery pack even if it is severely damaged or is completely worn out.
  • The battery pack can explode in a fire. Toxic fumes and materials are created when battery packs are burned.
• Do not charge or use battery in explosive atmospheres, such as in the presence of flammable liquids, gases or dust.
  • Inserting or removing the battery from the charger may ignite the dust or fumes.
• If battery contents come into contact with the skin, immediately wash  area with mild soap and water.
  • If battery liquid gets into the eye, rinse waterover the open eye for 15 minutes or until irritation ceases. If medical attention is needed, the battery electrolyte for Li-ion batteries is composed of a mixture of liquid organic carbonates and lithium salts.
• Contents of opened battery cells may cause respiratory irritation.
  • Provide fresh air. If symptoms persist, seek medical attention.
    • WARNING: Burn hazard.
      Battery liquid may be flammable if exposed to spark or flame.
• Charge the battery packs only in Black & Decker chargers.
• DO NOT splash or immerse in water or other liquids.
  • This may cause premature cell failure.
• Do not store or use the tool and battery pack in locations where the temperature may reach or exceed 105°F (40˚C) (such as outside sheds or metal buildings in summer).

WARNING: Never attempt to open the battery pack for any reason. If battery pack case is cracked or damaged, do not insert into charger. Do not crush, drop or damage battery pack. Do not use a battery pack or charger that has received a sharp blow, been dropped, run over or damaged in any way (i.e., pierced with a nail, hit with a hammer, stepped on). Damaged battery packs should be returned to service center for recycling.
WARNING: Fire hazard. Do not store or carry battery so that metal objects can contact exposed battery terminals. For example, do not place battery in aprons, pockets, tool boxes, product kit boxes, drawers, etc., with loose nails, screws, keys, etc. Transporting batteries can possibly cause fires if the battery terminals inadvertently come in contact with conductive materials such as keys, coins, hand tools and the like.
The US Department of Transportation Hazardous Material Regulations (HMR) actually prohibit transporting batteries in commerce or on airplanes (i.e., packed in suitcases and carry-on luggage) UNLESS they are properly protected from short circuits. So when transporting individual batteries, make sure that the battery terminals are protected and well insulated from materials that could contact them and cause a short circuit.

NOTE: LI-ION batteries should not be put in checked baggage.

Storage Recommendations

1. The best storage place is one that is cool and dry away from direct sunlight and excess heat or cold.
2. Long storage will not harm the battery pack or charger.

Description

The Black+Decker LSW36 Hard Surface Sweeper is engineered with a focus on convenience and efficiency. Its ergonomic design ensures comfortable handling during extended cleaning sessions. The sweeper features a pivoting head that allows for smooth navigation around furniture and tight spaces. The easy-empty dustbin and washable pre-filter make maintenance straightforward, extending the product's lifespan.

The LED lights integrated into the sweeper head illuminate hidden debris, ensuring no spot is left uncleaned. Additionally, the adjustable handle height accommodates users of various statures, making it a versatile tool for households with multiple users.

Charging Procedure

The standard charger provided will charge a fully depleted battery in about 2 hours. A 80% charge is available in 1 hour.

1. Plug the charger into an appropriate outlet before inserting the battery pack.
2. Insert the battery pack into the charger as shown in figure A.
3. The green LED (figure A1) will flash indicating that the battery is being charged.

4. The completion of charge is indicated by the green LED (figure A1) remaining on continuously. The pack is fully charged and may be used at this time or left on the charger.



Recharge discharged batteries as soon as possible after use or battery life may be greatly diminished.

CHARGER DIAGNOSTICS

This charger is designed to detect certain problems that can arise with the battery packs or the power source. Problems are indicated by one LED (figure A1) flashing in different patterns.

BAD BATTERY

The charger can detect a weak or damaged battery. The red LED flashes in the pattern indicated on the label. If you see this bad battery blink pattern, do not continue to charge the battery. Return it to a service center or a collection site for recycling.

HOT/COLD PACK DELAY

When the charger detects a battery that is excessively hot or excessively cold, it automatically starts a Hot/Cold Pack Delay, suspending charging until the battery has normalized. After this happens, the charger automatically switches to the Pack Charging mode. This feature ensures maximum battery life. The red LED flashes in the pattern indicated on the label when the hot / cold pack delay is detected.

LEAVING THE BATTERY IN THE CHARGER
The charger and battery pack can be left connected with the green LED glowing indefinitely. The charger will keep the battery pack fresh and fully charged.

Important Charging Notes

1. Longest life and best performance can be obtained if the battery pack is charged when the air temperature is between 60°F and 80°F (16°- 27°C). DO NOT charge the battery pack in an air temperature below +40°F (+4.5°C), or above +105°F (+40.5°C). This is important and will prevent serious damage to the battery pack.
2. The charger and battery pack may become warm to touch while charging. This is a normal condition, and does not indicate a problem. To facilitate the cooling of the battery pack after use, avoid placing the charger or battery pack in a warm environment such as in a metal shed, or an uninsulated trailer.
3. If the battery pack does not charge properly:
   1. Check current at receptacle by plugging in a lamp or other appliance
   2. Check to see if receptacle is connected to a light switch which turns power off when you turn out the lights.
   3. Move charger and battery pack to a location where the surrounding air temperature is approximately 60°F - 80°F (16° - 27°C).
   4. If charging problems persist, take the tool, battery pack and charger to your local service center.
4. The battery pack should be recharged when it fails to produce sufficient power on jobs which were easily done previously. DO NOT CONTINUE to use under these conditions. Follow the charging procedure. You may also charge a partially used pack whenever you desire with no adverse affect on the battery pack.
5. Foreign materials of a conductive nature such as, but not limited to, steel wool, aluminum foil, or any buildup of metallic particles should be kept away from charger cavities. Always unplug the charger from the power supply when there is no battery pack in the cavity. Unplug charger before attempting to clean.
6. Do not freeze or immerse charger in water or any other liquid.

WARNING: Shock hazard. Do not allow any liquid to get inside charger. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or cracks, return to a service center for recycling.

State of charge indicator

(figure B)

The back of the battery is equipped with a state of charge indicator. This can be used to display the current level of charge in the battery during use and during charging. It does not indicate tool functionality and is subject to variation based on product components, temperature and end-user application.

Checking state of charge during use:

• Press the state of charge indicator button (B1).
• The four LED’s (B2) will illuminate indicating the percent of charge in the battery. See chart in figure B.
• If LED light does not lluminate, charge battery.

NOTE: This battery is designed to not operate when a charge below 20% of its capacity is reached. After the battery charge is depleated, the toll will not operate until after the battery has been recharged.

Installing and removing the battery pack

WARNING: Make certain the tool is switched off before removing or installing battery.

TO Install Battery Pack:
Insert battery pack into tool until fully seated and an audible click is heard (figure C). Make sure battery pack is fully seated and fully latched into position.

To remove battery pack:
Depress the battery release button in the back of the battery pack and pull battery pack out of tool.

WARNING: Before assembly, make sure that the tool is switched off and the battery has been removed.

Assembly

NOTE: Ensure the sweeper is switched off and the battery is removed before attaching or removing the sweeper tubes. The tube assembly must be assembled to the housing before use.

TUBE ASSEMBLY:

• To attach the inner tube to the sweeper, line up the tube with the sweeper housing as shown in figure D.
• Push the tube into the sweeper housing until the lock button engages the lock hole in the tube.
• Repeat this process for the outer tube.

Operation

Always wear safety glasses. wear a filter mask if the operation is dusty. use of rubber gloves and substantial footwear is recommended when working outdoors. for household use only.
Warning: cut hazard. When turning the tool off for tube installation or any other reason, wait 10 seconds for the fan to stop rotating before disassembly.

• Always switch off and remove the battery when:
• The power supply cord has become damaged or entangled.
• You leave sweeper unattended.
• Checking, adjusting, cleaning or working on sweeper.

Use sweeper only in daylight or good artificial light.

switching on and off

(figure e)

WARNING: USE BOTH HANDS TO GRIP THE PRODUCT FIRMLY WHEN SWITCHING ON.

• To switch the sweeper on, slide the on/off switch forward.
• To switch the sweeper off, slide the on/off switch back.

CAUTION: Do not point unit discharge at self or bystanders

Power Command Max Power / Max Runtime

(figure f)

The max power / max runtime feature (F1) is located on the tool handle.

• It allows you to optimize the tools performance and boost the power as needed.
• To choose max power, rotate dial to setting 6.
• To maximize runtime rotate dial to setting 1.
• For a combination of both, rotate dial to setting from 2 to 5.

Sweeper Operation

CAUTION: Always wear safety glasses. Wear a filter mask if the operation is dusty. Use of gloves, long pants and substantial footwear is recommended. Keep long hair and loose clothing away from openings and moving parts. THIS SWEEPER IS FOR HOUSEHOLD USE ONLY.
NOTE: Ensure the sweeper is switched off and the battery is removed before attaching or removing the sweeper tubes. The sweeper tube must be assembled to the housing before use. Install battery after assembly just prior to use.

• Hold the sweeper with one hand as shown in figure G and sweep from side to side with the nozzle several inches above the hard surface. Slowly advance keeping the accumulated pile of debris in front of you.



Setup Guide

To operate the Black+Decker LSW36, follow these steps:

1. Assembly: Remove all parts from the packaging and attach the handle to the main body using the provided screws. Ensure all connections are secure.
2. Charging: Place the battery pack into the charging dock and plug it into a power outlet. Allow it to charge for up to 4 hours before first use.
3. Operation: Press the power button to turn on the sweeper and adjust the handle height as needed. Use the pivoting head to navigate different areas of your home.
4. Maintenance: Regularly empty the dustbin and wash the pre-filter to maintain optimal performance.

Maintenance

Cleaning and Storage

WARNING : SHOCK HAZARD . DO NOT POUR OR SPRAY WATER ON THE TOOL IN AN ATTEMPT TO CLEAN.
CAUTION: TURN OFF AND REMOVE BATTERY FROM TOOL.

• Use only mild soap and a damp cloth to clean the tool. Never let any liquid get inside the tool; never immerse any part of the tool into a liquid. Your Sweeper should be stored in a dry place.
• Do not store the tool on or adjacent to fertilizers or chemicals. Such storage can cause rapid corrosion of the metal parts.

SAFETY GUIDELINES

DEFINITIONS
It is important for you to read and understand this manual. The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help you recognize this information.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
NOTICE: Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage.

Important Safety warnings & instructions

WARNING: To reduce risk of injury:

• Before any use, be sure everyone using this unit reads and understands all safety instructions and other information contained in this manual.
• Save these instructions and review them frequently prior to use and in instructing others.
• Do not point unit discharge at self or bystanders.
• Keep long hair and loose clothing away from openings and moving parts.
  WARNING: When using an electric tool, basic safety precautions should always be followed to reduce risk of fire, electric shock, and personal injury, including the following.
  WARNING: Some dust created by this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
  Some examples of these chemicals are:
  • compounds in fertilizers
  • compounds in insecticides, herbicides and pesticides
  • arsenic and chromium from chemically treated lumber

To reduce your exposure to these chemicals, wear approved safety equipment such as dust masks that are specially designed to filter out microscopic particles.
READ All and understand ALL INSTRUCTIONS BEFORE USING.

SAVE THESE INSTRUCTIONS.

Black+Decker LSW36 Troubleshooting

Full three -Year Home Use Warranty

Black & Decker (U.S.) Inc. warrants this product for three years against any defects in material or workmanship. The defective product will be replaced or repaired at no charge in either of two ways. The first is to return the product to the retailer from whom it was purchased (provided that the store is a participating retailer). Returns should be made within the time period of the retailer’s policy for exchanges (usually 30 to 90 days after the sale).

Black+Decker Hard Surface Sweeper Pros & Cons

Pros

• Lightweight Design: Easy to maneuver and transport.
• Powerful Suction: Effective at picking up debris from hard surfaces.
• Adjustable Handle: Accommodates users of different heights.
• Illuminates hidden dirt and debris.

Cons

• Battery Life: Runtime can be limited for larger areas or heavy-duty cleaning.
• No Additional Attachments: Limited versatility compared to more advanced vacuum cleaners.
• Noisy Operation: Some users may find the motor noise bothersome.

Customer Reviews

Customers have generally praised the Black+Decker LSW36 for its ease of use and effectiveness on hard surfaces. Many users appreciate its lightweight design and the convenience of the rechargeable battery. However, some have noted that the battery life could be longer and that additional attachments would enhance its functionality.

Common complaints include issues with suction power over time and occasional difficulties with assembly. Despite these minor drawbacks, the product remains highly rated for its value and performance.
